Campbell Hausfeld TL053589 Operating Instructions Manual

See Warranty on page 4 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
RegisteR youR pRoduct online now!
Description
Professional air powered cut-off tools
are air tools designed for a variety of
cutting applications, and can be used
on many metals. Used for cutting
rusted exhaust bolts, auto panels and
various home projects.
Unpacking
When unpacking this product, carefully
inspect for any damage that may have
occurred during transit.

General Safety

Information
CaLIfOrnIa prOpOSITIOn 65
You can create dust when you
cut, sand, drill or grind
materials such as wood, paint,
metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
This product is part of a high pressure
system and the following safety
precautions must be followed at all
times along with any other existing
safety rules.
1. Read all manuals included
with this product care-
fully. Be thoroughly
familiar with the controls
and the proper use of the
equipment.
2. Only persons well acquainted with
these rules of safe operation should
be allowed to use the air tool.
Do not exceed the
maximum oper-
ating pressure of the air tool (90 psi).
This can reduce the life of the tool.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2012 Campbell Hausfeld/Scott Fetzer
3. Do not exceed any pressure rating
of any component in the system.
Maximum operating pressure of 90
psi is measured at the tool inlet
while the tool is running. The
pressure drop between the
compressor and tool needs to be
compensated for at the compressor.
4. Disconnect the air tool from air
supply before changing tools or
attachments, servicing and during
non-operation.
Safety glasses and ear
protection must be worn
during operation.
5. Do not wear loose fitting clothing,
scarves, neck ties or jewelry when
operating any tool. Loose clothing
or jewelry may become caught in
moving parts and result in serious
personal injury.
6. Do not depress trigger when
connecting the air supply hose.
7. Always use attachments designed
for use with air powered tools. Do
not use damaged or worn
attachments.
8. Never trigger the tool when not
applied to a work object. Attach-
ments must be securely attached.
Loose attachments can cause serious
MANUAL
injury.
9. Protect air lines from damage or
puncture.
10. Never point an air tool at oneself or
any other person. Serious injury
could occur.
11. Check air hoses for weak or worn
condition before each use. Make
sure all connections are secure.
For parts, product & service information
visit www.chpower.com
air Cut-Off Tool
http://www.chpower.net/reg
Release all pressure from the
system before attempting to
install, service, relocate or
perform any maintenance.
12. Keep all nuts, bolts and screws tight
13. Do not put hands near or
14. Always secure workpiece in a vise or
exposure to vibration, work in
awkward positions and repetitive work
motions can cause injury to hands and
arms. Stop using any tool if discomfort,
numbness, tingling or pain occur, and
consult a physician.
assembly
SySTem SeTUp
PLEASE REFER TO AIR TOOL AND SPRAY
GUN SET-UP (IN170102AV) FOR AIR
SYSTEM HOOK-UP INSTRUCTIONS.
triggering of tool when pressurized air
is connected to system.
Using fittings or air hoses which are too
small can create a pressure drop which
will result in a loss of power in tool.
nOTe: Do not install a quick coupler set
between tool and whip hose.
aIr TOOL SeTUp
hose to move tool or a compressor.
Keep hoses away from heat, oil and
sharp edges. Replace any hose that is
damaged, weak or worn.
TL053589
and ensure equipment is in safe
working condition.
under moving parts. Keep
hands off guard when
operating. Do not operate tool
without guard properly secured.
clamp.
Do not misuse this
product. Excessive
Use of a whip hose
prevents accidental
Never carry a tool
by the hose or pull
IN738100AV 1/12
