ELECTRO-OPTICS KILO2400ABS Owner's Manual

7x25mm digital ballistic laser rangefinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ELECTRO-OPTICS
KILO
®
KILO2400ABS™ 7x25mm DIGITAL BALLISTIC LASER RANGEFINDER
OWNERS MANUAL
16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 1
10/28/16 10:06 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KILO2400ABS and is the answer not in the manual?

Questions and answers

Related Manuals for ELECTRO-OPTICS KILO2400ABS

Summary of Contents for ELECTRO-OPTICS KILO2400ABS

  • Page 1 ELECTRO-OPTICS KILO ® KILO2400ABS™ 7x25mm DIGITAL BALLISTIC LASER RANGEFINDER OWNERS MANUAL 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 1 10/28/16 10:06 AM...

  • Page 2: Table Of Contents

    Specifications ..........64 SIG SAUER Electro-Optics Infinite Guarantee™ ......68 SIG SAUER Electronic &...

  • Page 3: Introduction

    Molle bag, nylon carry bag, lanyard and 3 spare batteries to get you up and running for long range precision target shooting and hunting. The KILO2400ABS also features an improved laser with tighter beam divergence and a molded, glass asphere for the transmitter channel which provides consistent ranging performance across all temperatures.
  • Page 4 Scan mode refreshes at ultra-fast 4x/second Diopter Adjustment Ring Multi-position twist-up eyecup for individualized custom fit Compact form factor easily fits in pocket Rear-loading CR2 Battery 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 4 10/28/16 10:06 AM...

  • Page 5: Contents

    CONTENTS: • KILO2400ABS™ 7x25mm Digital Ballistic Laser Rangefinder with Bluetooth • Padded Ballistic Nylon Case • Flat Dark Earth, Water Resistant Molle Gear Bag • WeatherFlow WindMETER • One Piece CNC Billet Aluminum Tripod Adapter • (3) CR2 Primary Lithium Batteries •...

  • Page 6: Key Features

    KEY FEATURES: • 7x25mm monocular with SpectraCoat™ anti-reflection coatings for superior light transmission and optical clarify. • Revolutionary LightWave DSP™ Technology for the fastest and longest distance rangefinder engine. • HyperScan™ Technology provides 4 range updates per second in scan mode while RangeLock™ reports the last range result when ranging distant targets.
  • Page 7 sigoptics.com • Advanced OLED display provides a smaller, more accurate center aiming circle along with milling features and ballistic information including holdover, angle, wind direction, wind speed, target mode, density altitude and shot angle. • Line of Sight or Angle Modified range in addition to full ballistic holdover results in MIL or MOA. •...

  • Page 8: Product Identification

    PRODUCT IDENTIFICATION: A- Power/Range Button B- Diopter Focus Adjustment C- Eyecup D- Mode Button E- Battery Compartment 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 8 10/28/16 10:06 AM...

  • Page 9: Warning - Safety And Operation Procedures

    W WARNING Safety and Operation Procedures The KILO2400ABS is classified as a Class 3R product. There are a few precautions that are important to remember: • Do not depress the RANGE button while aiming at the human eye or while looking into the transmitting optics on the objective side •...

  • Page 10: Setup

    SET UP Installing the Battery Remove the battery cap by turning the cap in a counter-clockwise direction. Insert (1) CR2 Primary Lithium battery (+) terminal side first. The (-) terminal should be facing out. Place the cap onto the (-) battery terminal and reinstall the battery cap by turning the cap in the clockwise direction.
  • Page 11 After installation of the battery and depressing the RANGE button, the status of the KILO2400ABS is displayed: - - - - - BEST Installing the Lanyard Install the lanyard loop through the lanyard attachment point. Pass the lanyard back through the loop for secure attachment.

  • Page 12: Diopter Adjustment

    Diopter Adjustment The diopter or focus adjustment is located just inside of the eyecup. The focus adjustment is used to bring the OLED display into sharp focus along with the target image. The diopter adjustment can turn clockwise or counter-clockwise depending upon the user’s prescription.

  • Page 13: General Operation

    GENERAL OPERATION a. The KILO2400ABS is setup to work out of the box in its most simple configuration. There are only two buttons located on the rangefinder: RANGE and MODE. The RANGE button is used to turn on the rangefinder and for ranging targets.
  • Page 14 HyperScan MODE While the KILO2400ABS supports single button push ranging operation, it is highly recommended that you push and hold the RANGE button down to activate HyperScan mode. This mode allows you to scan targets at 4x/second which significantly improves ranging performance at extreme distances. As the ranging distances are updated very quickly in HyperScan mode, once you release the RANGE button the last acquired distance will be displayed.
  • Page 15 LUMATIC™ OLED DISPLAY The KILO2400ABS has the most advanced display on the market. Our OLED display has the largest dynamic range providing for high brightness in bright sunlight or snow conditions, yet will dim down to near night vision levels at dusk and dawn. No other display offers this adaptive ability to prevent your pupil from constricting in low light causing you to no longer be able to see your target.
  • Page 16 A - Elevation Hold Direction B - Wind Hold Direction C - Milling Grid (Dots = 5 MRAD / Ticks = 10 MRAD) D - Center Aiming Circle (3 MRAD OD / 2.4 MRAD ID) E - 5 Character Alphanumeric Display F - Wind Speed Unit of Measure G - Range Unit of Measure H - Holdover Unit of Measure...
  • Page 17 sigoptics.com WS L R WD U D BEST BEST 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 17 10/28/16 10:06 AM...

  • Page 18: Advanced Operation - Los And Amr Without Ballistics

    ADVANCED OPERATION KILO2400ABS Summary Flow Chart Rangefinder is ON Press and hold MODE for 3 seconds The KILO2400ABS features an Yards or Meters advanced programming menu unit of measure OLED Brightness Se ng AMR Selected for configuration. There are three...
  • Page 19 sigoptics.com Meters DA is OFF by Default in AMR mode asure Bluetooth Density Al tude Ready to ON or OFF ON or OFF Range LE Bluetooth ON or OFF Wind MOA or Yards or Bluetooth Ready to BEST or LAST AUTO, or 1-9 Re cle Select peed...
  • Page 20 ADVANCED OPERATION (continued) In each path you can configure the following common features: 1. Target Mode – BEST target will be used in most cases, however, if you are ranging through tall grass or foliage LAST target mode will suppress close range results and provide the farthest range result. 2.
  • Page 21 This feature was implemented to prevent different smartphones from pairing multiple times to different KILO2400ABS in case there are multiple units in close proximity. Note – at this time the KILO2400ABS will NOT pair with a Kestrel with Bluetooth.
  • Page 22 2. Press and hold the MODE button down for at least 2 seconds to enter programming mode. LOS or AMR will begin flashing (AMR is default). Release the MODE button. You can toggle between LOS and AMR by pressing and releasing the RANGE button. Your selection will be flashing LOS or AMR.
  • Page 23 sigoptics.com 3. If you selected AMR and pressed and released the MODE button, then the rangefinder will index to Target Mode. BEST or LAST will be flashing. You can toggle between BEST or LAST by pressing and releasing the RANGE button. Confirm and save your selection by pressing and releasing the MODE button to index to the next programming mode.
  • Page 24 4. At this point you have selected AMR and Target Mode. You will now set the display brightness. AUTO is default and will be flashing. You can switch between 9 fixed settings (LOW 1 – 3, MED 1 – 3, HI 1 – 3 or AUTO) by pressing and releasing the RANGE button to index through the brightness selection.
  • Page 25 sigoptics.com 5. At this point you have selected AMR and set Target Mode and Display Brightness. You will now select an aiming reticle. Circle only is default and will be flashing. You can choose between three reticles by pressing and releasing the RANGE button to index through the reticles. Confirm and save your selection by pressing and releasing the MODE button to index to the next programming mode.
  • Page 26 6. At this point you have selected AMR, set Target Mode, Display Brightness and selected an aiming reticle. You will now choose a unit of measure – Yards or Meters. Y for yards is default and will be flashing. Select a unit of measure by pressing and releasing the RANGE button to toggle back and forth.
  • Page 27 sigoptics.com 7. At this point you have selected AMR, set Target Mode, Display Brightness, selected an aiming reticle and set the unit of measure. You can now turn Bluetooth ON or OFF. Bluetooth is on by default and will be flashing. Turn ON or OFF by pressing and releasing the RANGE button to toggle back and forth. Confirm and save your selection by pressing and releasing the MODE button to index to the next programming mode.
  • Page 28 8. At this point you have selected AMR, set Target Mode, Display Brightness, selected an aiming reticle, set the unit of measure and turned Bluetooth on or off. You can now turn Density Altitude ON or OFF. DA is OFF by default and will be flashing. Turn ON or OFF by pressing and releasing the RANGE button to toggle back and forth.
  • Page 29 sigoptics.com 9. Looking back to Step 2, if you selected LOS and pressed and released the MODE button, then the rangefinder will index to Profile Selection. NoPro, Pro 1, Pro 2, Pro 3 or Pro 4 will be flashing. You can toggle between profiles by pressing and releasing the RANGE button.

  • Page 30: Advanced Ballistic Operation - Ballistic Profiles And Holdover

    ADVANCED BALLISTIC OPERATION – Installing the app and downloading profiles The KILO2400ABS was designed for long range shooters and hunters with onboard environmental sensors and an embedded ballistics calculator for greater precision at long distances. To get the most out of your rangefinder, download the Sig Ballistic App and synchronize your smartphone with your rangefinder.
  • Page 31 RANGE button. Your KILO2400ABS should appear as a nearby device – select your rangefinder and you are now paired. Once you have formally paired your Android smartphone with your KILO2400ABS, you will need to select the rangefinder from within the Home screen of the Sig Ballistic App. See images below.
  • Page 32 From the Home Screen touch the screen to the right of the Bluetooth icon. Your rangefinder should be listed if previously paired. 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 32 10/28/16 10:06 AM...
  • Page 33 sigoptics.com 3. Within the GUN PROFILE menu, touch or select the + button to select a bullet to begin configuring your profile. Next, select a unique caliber then select a unique bullet. Once an exact bullet is selected you will be prompted to choose which drag curve to use: G1, G7 or Custom. If a Custom Drag curve is available it is recommended that you select the Custom Drag curve since this bullet will have exact BC 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 33 10/28/16 10:06 AM...
  • Page 34 data for super, sub and transonic flight. Note – you can customize virtually any bullet characteristic that is in white (not greyed out). This is useful for those customers that hand load their ammunition or have characterized the rifle for such parameters such as muzzle velocity, sight height, bullet weight and zero range.
  • Page 35 sigoptics.com 4. At this point you should have at least one profile listed in the GUN PROFILES menu. The smartphone display should look similar to either image below. Note that the smartphone is not connected to your rangefinder if the rangefinder has timed out and turned off. 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 35 10/28/16 10:06 AM...
  • Page 36 5. Now that you have one or more profiles created, you need to select which profiles are to be downloaded to your rangefinder. Press the grey circle next to the profile to select up to 4 profiles for synchronizing with your rangefinder. In this example 2 out of 3 profiles are set for synchronization: 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 36 10/28/16 10:06 AM...
  • Page 37 sigoptics.com Make sure your rangefinder is active or on by pressing and releasing the RANGE button. You should see the word “CONNECTED” on the app. Touch or select the “SYNC” button in the upper right hand side of the screen and watch for the dialog box to show that the app and rangefinder are syncing.
  • Page 38 6. The next step is to enable a synchronized profile on your rangefinder by turning the rangefinder on by pressing and releasing the RANGE button. At the status display screen press and hold the MODE button for at least 2 seconds. Once in programming mode release the MODE button and follow the flowchart from page 13 by selecting LOS, advancing to Profile Selection (press and release the MODE button) and selecting Pro 1 (or Pro 2, 3 or 4) by pressing and releasing the RANGE button.
  • Page 39 sigoptics.com ADVANCED BALLISTIC OPERATION – Configuring wind and elevation holdover 1. For this section you will want to have your rangefinder in Programming Mode. Press and release the RANGE button to wake up the rangefinder. While looking at the status display on the rangefinder, press and hold the MODE button for more than 2 seconds to enter programming mode –...
  • Page 40 You will now see “WD” with “12:00” flashing. You can set your Wind Direction by pressing and releasing the RANGE button. The direction will change by 1:00 increments and represents the direction that the wind is coming from. Once set press the MODE button to save your wind direction and index to Wind Speed Unit of Measure.
  • Page 41 sigoptics.com 2. You have set your Wind Direction and now need to choose a Wind Speed Unit of Measure. The default setting is M/H (miles per hour or mph). Your display should show “WS” and “M/H” will be flashing. You can switch between M/H and M/S (meters per second) by pressing and releasing the RANGE button.
  • Page 42 3. You have set your Wind Direction, Wind Speed Unit of Measure (UoM) and now need to set the Wind Velocity. The default setting is 0. Your display should show “WS”, “M/H” or “M/S” and “0” will be flashing. You can increment the wind velocity by 1 unit by pressing and releasing the RANGE button. If you press and hold the RANGE button down you can increase the digits faster up to a maximum of 40.
  • Page 43 sigoptics.com 4. You have set Wind Direction Heading, Wind Speed UoM and Wind Speed Velocity. You will now choose your Holdover Unit of Measure. The default setting is “MOA” and will be flashing. You can toggle between MOA and MIL pressing and releasing the RANGE button. Once your selection is set and flashing, press and release the MODE button to save your setting and index to set the common settings such as Target Mode, Display Brightness, Reticle Selection and other common features as described earlier in the manual.
  • Page 44 Aiming your rangefinder at a distant target, press the range button to determine the line of sight range to your target. The LOS range will be displayed for 2 seconds, then your elevation holdover and finally your wind hold. These will repeat every 2 seconds for 30 seconds. A typical sequence is shown below where the range is “1347 m”, the elevation hold is “UP 15.50 MIL”...

  • Page 45: Sig Ballistic App Operation

    G1, G7 and Custom Drag Curves. When used with the KILO2400ABS you will be able to compute real time ballistic solutions in virtually any environment. The SBA will work remotely providing an ability to mount the rangefinder on a tripod and range targets all from within the HUD on the app.
  • Page 46 1. Touch or select the SIG app on your smartphone. You will come to the Home screen on the app which has 4 sub menus. Relevant information is shown below: Settings Connection Status Heads Up Display Displays real time range, hold and environmental information including the ability to remotely fire the rangefinder.
  • Page 47 Note – if you are struggling to keep the KILO2400ABS awake during programming or ranging you can adjust the sleep time to a maximum of 180 seconds. When you are finished configuring your settings just press the SIG button in the upper left hand corner to return to the Home screen.
  • Page 48 3. Heads Up Display – The HUD is configured to display real-time information from the paired rangefinder when ranging. Range, holdover and environmental information from the rangefinder is relayed over Bluetooth and displayed on the HUD. One of the most useful features is the remote RANGE button. During an active ranging session you can fire your rangefinder remotely by using this onscreen button.
  • Page 49 sigoptics.com When actively ranging targets while connected to your KILO, you can update the wind speed directly from the HUD display screen. Press the round SYNC button in the upper right hand corner of the display to re-sync your wind setting without having to return to the Environment submenu. 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 49 10/28/16 10:06 AM...
  • Page 50 4. Gun Profiles – Creating, configuring, saving and syncing custom profiles were detailed earlier in the manual. In most cases you can modify virtually any parameter within the app where the text is shown in white color. In the example below the muzzle velocity for the 338 Lapua profile was updated to 3200 fps. Once edited press the SAVE button to return to the GUN PROFILE sub menu.
  • Page 51 sigoptics.com Within the GUN PROFILES sub menu you can better calibrate your muzzle velocity as a function of ambient temperature by inputting measured data into the MV-TEMP table within the PROFILE EDITOR. The rule of thumb is about 1 fps of muzzle velocity for each additional degree of temperature. You can also determine this with a temperature sensor and chronograph by recording muzzle velocity at different temperatures.
  • Page 52 One additional feature provided within the Sig Ballistic App is the ability to calculate and set your muzzle velocity and drop scale factor empirically by using actual bullet drop at known ranges. The suggested ranges are based on your bullet selection. In this case select GUN PROFILES, then select a CUSTOM PROFILE (223 Sierra FMJ shown) and then press the CALIBRATE button at the top right hand side of the screen: 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 52 10/28/16 10:06 AM...
  • Page 53 sigoptics.com Within the CALIBRATION sub menu you will now enter your known target ranges and drop at each range. Once this information is input press the CALCULATE button and your results will appear similar to what you see below. You will note that the default MV for this bullet was 2600 fps but the measured MV was calculated to be 2624.
  • Page 54 5. Environment – From this screen you can adjust your Wind Direction. Wind Direction is the direction that the wind is coming from. You can override the rangefinder onboard sensors by touching on the Temperature, Pressure or Humidity data coming from the rangefinder and update any setting. Be sure that your connection is active and press the SYNC button to synchronize your settings with your rangefinder.
  • Page 55 Note - The WeatherFlow WindMETER is included with the KILO2400ABS. For some smartphones, the WindMETER will not function properly due to incompatibilities from smartphone to smartphone. This is caused by insufficient drive current through the audio jack. Some newer smartphones no longer have an audio jack.
  • Page 56 6. Target – Use the Target sub menu if you are shooting moving targets. Heading, Inclination and Latitude all are pulled from the rangefinder. Target Speed and Target Direction are manual inputs. In the example below the Heading is 215’, the target is at a decline of 16’, the Latitude is 40.0’ and the Target Speed has been input as 10 mph moving Right to Left.
  • Page 57 7. Compass Calibration – While using the KILO2400ABS you may notice that your compass heading may be off while viewing the Target submenu. Using a known compass while synced with your KILO, check the Target menu to determine if your compass heading is accurate (i.e.

  • Page 58: Frequently Asked Questions (Faq)

    FREQUENTLY ASKED QUESTIONS (FAQ): Q: I am pressing the RANGE button and nothing happens? A: Check to make sure you have a fresh CR2 battery installed. If the battery is new, try loosening and tightening the battery cap until the cap is snug. If this doesn’t fix the problem you may have switched the rangefinder into one of the low brightness settings for the OLED display.
  • Page 59 A: Most commercial rangefinders will provide over 4000 individual range calculations using a fresh CR2 primary lithium battery. The KILO2400ABS has additional sensors and Bluetooth which consume more battery power. The rangefinder exceeds 4000 ranges on a fresh battery, however, when heavily using SCAN mode this will cause the battery to drain much faster as the range processor remains active at all times and you will quickly exceed 4000 range calculations due to the HyperScan mode.
  • Page 60 Q: My Bluetooth link between my smartphone and my rangefinder keeps disconnecting? A: You can update your Settings / Preferences from the home screen on your app. Click on the Settings / Preferences button in the upper right hand corner of the screen and then change the KILO Timeout setting to 30, 60 or 180 seconds.
  • Page 61 sigoptics.com Q: My rangefinder is not calculating elevation and wind holds – no holds are showing up on the OLED display or in the HUD on the app? A: Your rangefinder is probably set to AMR (Angle Modified Range). In AMR mode only the angle modified range is displayed on the HUD and on the OLED display.
  • Page 62 Q: I’ve plugged the WindMETER into my smartphone jack and I still do not get a wind reading. A: On some versions of Android, your smartphone may not be able to provide enough current to the WindMETER to obtain an accurate wind reading. In this case you may be better off downloading the WeatherFlow wind meter app and using this app to obtain a wind reading.
  • Page 63 sigoptics.com 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 63 10/28/16 10:06 AM...

  • Page 64: Specifications

    KILO2400ABS SPECIFICATIONS Magnification Objective Clear Aperture 25mm Exit Pupil 3.6mm Eye Relief 15mm Angular (FOV) 6.78° FOV @ 100yds 35.67 ft Laser Divergence 1.3 mrad Range Response Time .25 sec Scanning Range Accuracy Under 100 yds .1 yds Max Range...
  • Page 65 sigoptics.com A – 3 in / 76mm B – 4.2 in / 107mm C – 1.3 in / 33mm 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 65 10/28/16 10:06 AM...
  • Page 66 W DANGER CLASS 3R LASER PRODUCT INVISIBLE LASER RADIATION - AVOID DIRECT EYE EXPOSURE This product complies with IEC 60825-1: 2014-05 Ed 3.0 and complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007. λ...
  • Page 67 sigoptics.com Shielded interference cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules. Specifications and designs are subject to change without any notice or obligation on the part of the manufacturer.

  • Page 68: Sig Sauer Electro-Optics Infinite Guarantee

    We understand the importance of quality in the line of fire, at the shooting range or on your next hunt. SIG SAUER Electro-Optics had to earn the right to wear that badge and the Infinite Guarantee has your back, forever. Period.

  • Page 69: Sig Sauer Electronic & Tritium Component Limited 5-Year Warranty

    sigoptics.com If you ever have a problem, no matter the cause, we promise to take care of you when it counts. Please note that our Infinite Guarantee does not provide coverage for intentional damage, misuse, cosmetic damage that does not affect the performance of the optic, loss, theft or unauthorized repair or modification.
  • Page 70 NOTES: 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 70 10/28/16 10:06 AM...
  • Page 71 sigoptics.com NOTES: 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 71 10/28/16 10:06 AM...
  • Page 72 FOR PRODUCT SERVICE ON THIS MODEL, PLEASE CALL 603-610-3000 19861 SW 95th Avenue, Portland, OR 97062 USA sigoptics.com P/N 7400372-01 R00 16SIG2013_KILO2400ABS_Manual 7400372-01 R00.indd 72 10/28/16 10:06 AM...
