CG102IR
ZIGBEE IR TRANSMITTER
U
M
SER
ANUAL
CG102IR
ZigBee IR Transmitter
V
0.1
ERSION
16 J
, 2015
ANUARY
Disclaimers and Copyright
Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the
manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as
insuring anyone against liability for infringement of letters patent.
Efforts have been made to ensure the accuracy and reliability of the data contained in this publication; however,
Citygrow Energy Systems Limited. makes no representation, warranty, or guarantee in connection with this
publication and hereby expressly disclaims any liability or responsibility for loss or damage resulting from its use or
from the use of any product or methodology described herein; for any violation of any federal, state, or municipal
regulation with which this publication may conflict; or for the infringement of any patent from the use of this
publication. Nothing contained in this publication should be viewed as an endorsement by Citygrow Energy Systems
Limited. of any particular manufacturer's products.
i
Advertisement
Table of Contents
Related Manuals for CityGrow CG102IR
Summary of Contents for CityGrow CG102IR
- Page 1 Nothing contained in this publication should be viewed as an endorsement by Citygrow Energy Systems Limited. of any particular manufacturer’s products.
-
Page 2: Important Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Table Of Contents
Table of content Introduction ....................1 Understanding of the product ............... 2 Dimensions ....................3 IR Learning ....................4 Installation ....................6 5.1. Case 1: Control the Split type air-conditioner ........6 5.2. Case 2: Table stand ................9 5.3. Case 2: Ceiling mount .............. -
Page 4: Introduction
1. Introduction Thank you for buying Citygrow’s product. CG102IR ZigBee IR Transmitter is both powerful and easy to use and install. The learning IR function allows you to learn most of the IR commands, for example the air-conditionar, the audio or video equipment. -
Page 5: Understanding Of The Product
2. Understanding of the product Face cover IR lens Main unit (Rear view) Main unit (Front view) IR Learn LED Reset Wall mounting DC Jack hole IR TX LED Function (Test) IR extension cable Programming connector connector Stand Mounting hole for ceiling mount... -
Page 6: Dimensions
3. Dimensions Main unit 87mm 87mm 22mm Stand 28mm 100mm... -
Page 7: Ir Learning
4. IR Learning Before installing the CG102IR, it is advised to learn the IR codes from the original remote of your appliances to the CG102IR first. Step 1: Remove the front cover of CG102IR, you will see the IR learning head. - Page 8 Step 3: Inside the PC user interface, select “connect” and so PC is connected to CG102IR. Step 4: Place the original IR remote in front of the CG102IR IR learning head, the best distance is 50mm from the IR learning head.
-
Page 9: Installation
WARNING! Install in accordance with all national and local electrical codes. IMPORTANT! Citygrow® is not liable for any damage incurred with the misuse of this product. IMPORTANT! Pre-setup can only be done by a professional worker or manufacturer agent. - Page 10 STEP 1: IMPORTANT! Turn off main power at the main switch board. STEP 2: Connect the main power cable from the wall box to the Live and Neutral wires of the CG101AD Mini Power Supply (purchase separately). Make sure the Live is connected to the Brown wire (Live) and Neutral is connected to Blue wire (neutral) of CG101AD.
- Page 11 STEP 4: Plug the DC plug into the DC jack input of CG102IR, then plug the IR extension cable into the rear of CG102IR. Then, install CG102IR by fastening the two screws onto the wall box. See following….. Wall box installation diagram...
-
Page 12: Case 2: Table Stand
5.2. Case 2: Table stand STEP 1: Select a location to place your CG102IR, the best location will be maximum 8 meters away from the appliances and the IR angle coverage is +/-60 degree. Secondly, it is recommended to locate the product at a location that the IR transmission will not be blocked by objects or human. -
Page 13: Case 2: Ceiling Mount
5.3. Case 2: Ceiling mount STEP 1: Select a location to place your CG102IR, the maximum distance will be maximum 8 meters away from the appliances and the IR angle coverage is +/-60 degree. IR angle +/- 60 deg STEP 2: Power up the CG102IR by provided power adaptor or CG101AD mini power supply (purchase separately). - Page 14 Make sure the Live is connected to the Brown wire (Live) and Neutral is connected to Blue wire (neutral) of CG101AD. Live (Brown) CG101AD DC6V output AC input Mini power “+” Red 100 to 240V supply “-“ Bl;ack Neutral (Blue) Make sure the DC output from CG101AD, red wire (positive) and black wire ...
-
Page 15: Adding The Product To Your Home Wireless Zigbee Network
USB end of the CG101UTC cable. STEP 3 Plug the CG101UTC cable into the USB port of a PC that is installed with Citygrow’s HomeNET Planner Software. STEP 4 Refer to the user manual of “HomeNET Planner” Software to program and set the address of the product. -
Page 16: Clear Memory
7. Clear Memory Clearing the memory inside of the product will result in: 1. The product will no longer reply to any Panels that it had previously bound to. 2. The product will no longer reply to any Remotes that it had previously bound to. In order to perform the Clear Memory function, please follow the below steps: STEP 1 Reset... - Page 17 STEP 4 Press and release the Func Button again to stop blinking. STEP 5 Press and release the Reset Button. The memory inside of the product has now been cleared.
-
Page 18: Specification
8. Specification Item Specification Power Supply AC adaptor Output DC6V 500mA IR transmission range IR transmission angle +/- 60 degree Best IR learning distance 15 to 80mm from the IR learn LED Maximum storage for IR 60 codes learning code RF frequency 2.4GHZ RF control distance (M, line...
