Page 1: Outdoor Refrigerator
Outdoor Refrigerator Be sure unit is standing upright 24 hours prior to plug-in. Model: BLZ-SSRF-50DH... -
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS Read all instructions before using this appliance. Use this appliance only for its intended purpose as described in this instruction manual. Always exercise basic safety precautions, as described below. After reading the instruction manual, store it in an accessible place where the user(s) of this product can easily find it. The purpose of these safety precautions is to ensure safe and correct use of the product to minimize risks that could cause serious damage and injury to you or others. - Page 3 lightning rod. It cannot be replaced with the neutral wire of single-phase power. In addition to the ground wire, an electrical leakage circuit breaker is also required. 8. Use an electrician installed ground fault circuit interrupter (GFCI) electrical outlet. If no GFCI is installed, electrical shock could result. 9.
-
Page 4: Table Of Contents
10. Condenser water from evaporator drains into a hole in the floor of the storage compartment and is channeled into a drain pan located at the back of the unit on the compressor. Heat transferred from the compressor evaporates any water that has collected in the pan. -
Page 5: Location Of Parts
Location of Parts ight Door Shelves Light switch Vents Leveling legs Vents Vents Vents Technical Specifications Model Number: BLZ-SSRF-50DH Description: Outdoor Refrigerator Electrical Input: 115VAC ~ 60Hz Current Rating: 1.8A 23⅝”W x 23 ”D x 33½”H Unit Dimensions: Unit Weight: 93 lbs Ambient Temperature Range: 50ºF - 100ºF... -
Page 6: Energy-Saving Tips
Control Panel Energy-Saving Tips Do not place the unit next to a heating vent, a range or in direct sunlight. Keep the door closed as much as possible, especially in hot, humid weather. Cover foods to reduce moisture buildup inside the appliance. Installation Remove the exterior and interior packaging. - Page 7 Reversing the Door Swing Tools needed: Flathead screwdriver, Phillips screwdriver IMPORTANT: Before you begin, unplug the refrigerator or disconnect power. To remove door from hinges: 1. Using a flathead screwdriver, separate the hinge axis from Hinge 1. Set aside. 2. Open the door about 20°around the axis of Bottom Hinge 2, then lift the door off Bottom Hinge 2 and set door aside.
- Page 8 See Figure below. Electrical Connection Important! For your personal safety, this appliance must be properly grounded. In the event of an electrical short circuit, grounding reduces the risk of shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug.
-
Page 9: Operating Your Refrigerator
Failure to do so may result in the unit working improperly. Compartment Design This Blaze Refrigerator has a capacity of 175 cans. The unit has 3 adjustable chrome-plated flat wire shelves to hold cans and bottles of beverages such as beer, water and soft drinks. - Page 10 0 to 6 Fahrenheit degrees. When fully loaded with room temperature product, the BLZ-SSRF-50DH will operate continuously for as long as 24 hours to reduce the temperature inside the cabinet to the desired point.
-
Page 11: Cleaning And Maintenance
In ALARM mode, the unit will make a beeping sound and display an alarm message. If the control panel displays any of the following messages: EI, HI or LI, consult the Troubleshooting section of this manual. Interior Light The interior light can be turned On or Off automatically with the opening or closing of the door. -
Page 12: Troubleshooting
Extended Non-Use VACATION/HOLIDAY, PROLONGED SHUTDOWN The following steps are recommended for periods of extended non-use: 1. Remove all customable content from the unit. 2. Disconnect the power cord from its outlet/socket and leave it disconnected until the unit is returned to service. 3. - Page 13 Temperature Window displays “LI” This message is an ALARM MODE indication. It indicates that the actual temperature is much lower than your set temperature. Temperature Window displays “HI” This message is an ALARM MODE indication. It indicates that the actual temperature is much higher than your set temperature.
-
Page 14: Warranty
Limited Warranty Manufacturer warrants to the original purchaser at the original site of delivery with proof of purchase of each Refrigerator that when subject to normal residential use, it is free from defects in workmanship and material for the periods specified below. This warranty excludes refrigerators used in rental or commercial applications.
