Summary of Contents for Vari Lite VL500

  • Page 2 ® VARI❋LITE is a trademark owned by Genlyte Thomas Group LLC and is registered in the United States and other countries. VL500™ (and the individual product designations), VL1000™, VL2000™, VL2201™, VL2202™, VL2400™ (and the individual product designations), ™ ™ ™...
  • Page 3 OREWORD How To Obtain Warranty Service A copy of the Vari-Lite Limited Warranty was included in the shipping package for this VARI❋LITE® product. To obtain warranty service, please contact customer service at 1-877-VARI-LITE (1-877-827-4548), +1-214-647-7880, or customerservice@genlytecontrols.com and request a Return Material Authorization (RMA) for warranty service.

  • Page 4: Declaration Of Conformity

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Compliance Notice This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment.

  • Page 5: Safety Notice

    FIRE, EXPOSURE TO EXCESSIVE UV RADIATION, AND INJURY TO PERSONS CAN BE FOUND BELOW. WARNING: INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST FIRE 1. VARI❋LITE® luminaires have been designed for use with specific lamp types. The VL500 wash luminaire requires a certain type of lamp (see “Replacement Items/Accessories” on page 6 for all Series 500 wash lamps).
  • Page 6 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL WARNING: INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST EXCESSIVE EXPOSURE TO UV RADIATION 1. Many VARI❋LITE® luminaires use a lamp that produces UV radiation. DO NOT look directly at lamp. 2. It is hazardous to operate luminaires without lens or shield. Shields, lenses, or ultraviolet screens shall be changed if they have become visibly damaged to such an extent that their effectiveness is impaired.
  • Page 7 OREWORD Sicherheitshinweise Es ist äußerst wichtig, ALLE Sicherheitsinformationen und -hinweise in diesem Handbuch und dem beiliegenden Informationsmaterial zu lesen, bevor Sie die hierin beschriebenen Produkte installieren bzw. bedienen. Halten Sie bei der Installation und dem Einsatz dieses Produkts alle Warnhinweise und Vorsichtsmaßnahmen ein.
  • Page 8 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL WARNUNG: HINWEISE ZUM SCHUTZ GEGEN ÜBERHÖHTE UV-STRAHLUNG 1. Viele VARI❋LITE®-Scheinwerfer verwenden die Lampentyp, der UV-Strahlen abgibt. SCHAUEN SIE NICHT direkt in die Lampe. 2. Es ist gefährlich, Leuchten ohne Linsen oder Blenden zu bedienen. Blenden, Linsen oder Ultraviolettschirme müssen ausgetauscht werden, sofern deren Schutzwirkung durch sichtbare...
  • Page 9 OREWORD Notes de sécurité Avant de procéder à l’installation des produits décrits dans ce guide et de les mettre en marche, il est extrêmement important de lire TOUS les renseignements et TOUTES les directives de sécurité contenues dans ce guide ainsi que toute documentation jointe. Tenir compte de tous les avertissements et suivre toutes les précautions pendant l’installation et l’utilisation de cet appareil.
  • Page 10 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL AVERTISSEMENT: DIRECTIVES POUR SE PROTÉGER CONTRE UNE EXPOSITION EXCESSIVE AUX RAYONS UV 1. Plusieurs luminaires VARI❋LITE® utilisent une lampe qui produit des rayons UV. NE PAS fixer son regard sur la lampe.
  • Page 11 OREWORD Aviso sobre Seguridad Es muy importante leer TODA la información e instrucciones sobre seguridad que se indica en este manual así como en los documentos adjuntos antes de instalar y operar los productos descritos. Se debe prestar atención a todos los avisos y advertencias durante la instalación y uso de este producto. Los símbolos de seguridad usados en este manual son los siguientes: CUIDADO, indica posibles daños al producto.
  • Page 12 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL ADVERTENCIA: INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA LA EXPOSICIÓN EXCESIVA DE RADIACIÓN ULTRA VIOLETA 1. Muchas luminarias VARI❋LITE® usan un tipo de lámpara que produce radiación UV. NO mire directamente a la lámpara.
  • Page 13 OREWORD 02.9 685.00 01 0 01-March-2006...
  • Page 14 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL 01-March-2006 0 2.9685 .0001 0...

  • Page 15: Table Of Contents

    Transporting Pack Up Cue....................... 21 Chapter 3. Operation Color Control CYM Crossfade Color Mixing................... 24 DMX Operation VL500 Wash Channel Mapping................. 25 DMX Mapping CYM Crossfade Color Mixing and Dimming............26 Beam Control ......................26 02.9 685.00 01 0 01-March-2006...
  • Page 16 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Luminaire Timing Luminaire Timing Channel Information ..............27 Control Channel Functions ..................34 Updating Software Reprogramming Luminaires ..................35 Components Overview ..................35 Reprogramming Procedure.................. 36 Transferring Software From Luminaire to Luminaire ..........38 Chapter 4.

  • Page 17: About This Manual

    About This Manual This manual provides necessary information regarding safety, installation, operation and routine maintenance for VARI❋LITE® VL500™ Wash Luminaires. Familiarizing yourself with this information will help you to get the most out of your product. WARNING: It is important to read ALL accompanying safety and installation instructions to avoid damage to the product and potential injury to yourself or others.

  • Page 18: Text Conventions

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL DMX512 is included.) USITT Inc. 6443 Ridings Road Syracuse, New York 13206-1111 USA Tel: (800) 938-7488 Fax: (866) 398-7488 / www.usitt.org Text Conventions The following styles and meanings are used throughout this manual:...

  • Page 19: Chapter 1. Description

    HAPTER Description This chapter contains descriptions of luminaire features and components, along with a list of accessories which are available. • Features • Components 02 .9685 .0001 0 01-March-2006...

  • Page 20: Features

    The color system is available in standard and pastel colors. • Variable Beam Angle: •VL500: 12.5° to 20° (dependant upon lens type). •VL500D: 12.5° to 20° (dependant upon lens type). •VL500A: 7.5° to 16.5° (dependant upon lens type). •...

  • Page 21: Components

    Ballast to Fixture Lamp Cable Product Registration Product Support Sheet VL500 and VL500D Wash Models Unconnectorized Lamp Power Cable (VL500 Only) IGBT Dimmer VL500 Wash Luminaire VL500D Wash Luminaire Figure 1-1: VL500 Wash Luminaire Included Items 02.9 685.00 01 0 01-March-2006...

  • Page 22: Replacement Items/Accessories

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Replacement Items/Accessories The following optional and/or replacement items can be ordered directly from your Authorized VARI❋LITE Dealer or Vari-Lite. When ordering, please order by the Vari-Lite part number. ® Vari-Lite Part No.

  • Page 23: Chapter 2. Installation

    HAPTER Installation This chapter contains instructions for installation of the luminaire. It includes connecting power and data, along with instructions for powering up the luminaire for the first time and addressing it within your system. • Power and Data Cabling Requirements •...

  • Page 24: Power And Data Cabling Requirements

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Power and Data Cabling Requirements Power The luminaire requires standard AC power distribution from 100-240 VAC, 50/60 Hz. Three amps to twelve amps will be required depending on the AC supply voltage and product model.

  • Page 25: Current Vs. Voltage

    The following tables provide the luminaire’s current draw at specific voltages. Total Luminaire Current is calculated with the lamp on and all motors sequencing. Table 2-1: VL500 Wash Luminaire - Current vs. Voltage (120V/1200W Lamp) Total Luminaire Voltage @ 60Hz...
  • Page 26 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Voltage @ 60Hz Current 230V 5.4A 240V 5.2A Table 2-5: VL500A Wash Luminaire - Current vs. Voltage (575W Arc Lamp - Turbo Mode) Voltage @ 60Hz Current 8.6A 100V 7.8A 110V 7.1A...

  • Page 27: Data Cables

    NSTALLATION OWER AND ABLING EQUIREMENTS Data Cables The luminaire is equipped with two, 5-pin XLR connectors for DATA IN and DATA THRU (out) applications. DATA IN requires a 5-pin, female XLR connector and DATA THRU requires a 5-pin, male XLR connector. When purchasing or constructing data cables, it is important that not only the correct cable type be used, but also quality cable to ensure a reliable DMX512 system.

  • Page 28: Recommended Cable Types/Manufacturers

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Recommended Cable Types/Manufacturers These are only a few of the suitable cable types. Any quality EIA485, twisted pair, 120 ohm, shielded cable will also work. ∗ Type Pairs Jacket Temp (F) ZΩ...

  • Page 29: Termination Connector

    NSTALLATION OWER AND ABLING EQUIREMENTS Termination Connector A XLR termination connector is required at the last luminaire (or "far end of the line") to prevent signal reflections. Signal reflections may cancel out the signal at certain line lengths, resulting in errors. The terminator is also necessary for software downloads and running tests on multiple luminaires.

  • Page 30: Installation Procedures

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Installation Procedures Installing Lamp In the event the lamp was packed separately during shipment, it will be necessary to install in the luminaire before use. WARNING: Ensure that power is removed from luminaire when installing lamp.

  • Page 31: Hanging The Luminaire

    ROCEDURES Hanging the Luminaire The VL500 wash luminaire can be hung horizontally or vertically from any structure designed to work with the type of load created by this moving luminaire. Two mounting truss hooks or other mounting hardware are required. Many compatible truss hooks are available from different manufacturers for your particular needs.
  • Page 32 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Installing in Truss: Step 1. Using two people, lift luminaire into mounting position. Base Step 2. Secure in place with truss hook. Ensure truss hook (Foot) hardware that locks hook in place (e.g. wing bolt) is properly tightened and that luminaire is fully supported.

  • Page 33: Floor Mounting The Luminaire

    Figure 2-4: Hanging Dimensions and Clearances Floor Mounting the Luminaire VL500 wash luminaires are not designed nor sufficient to sit directly on its base (foot) in a floor installation application without a suitable floor mount plate. When used in this type of application, attach a floor mounting plate to the base and make sure the mounting surface is flat and sturdy.
  • Page 34 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Step 3. At last luminaire in link, install male termination connector at DATA THRU connector. (Luminaires and other devices on the same DMX chain may not function properly without termination.) AC In...

  • Page 35: Powering Up

    NSTALLATION OWERING Powering Up Power-Up Procedure All Models Since Lamp On is the default state, the lamp will come on (tungsten models) or strike (arc models) when the luminaire is powered up for the first time. When AC power is applied, the luminaire will immediately begin a calibration sequence that steps it through full pan and tilt movements.

  • Page 36: Addressing

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Addressing Program Starting Address The address setting for DMX console controlled systems is entered using the Menu Display (refer to “Menu Operation” on page 42). The luminaire retains the DMX address even if power is removed.

  • Page 37: Transporting

    When shipping or transporting a VL500 wash luminaire, certain settings should be used to minimize the possibility of damaging internal components. Because of the complexity and delicate nature of the 64 panes of dichroic glass filters used in the VL500 wash luminaire, extra care should be observed to minimize damage.
  • Page 38 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Notes 01-March-2006 0 2.9685 .0001 0...

  • Page 39: Chapter 3. Operation

    HAPTER Operation This chapter contains instructions for operating the luminaire using DMX control and for updating the internal software. • Color Control • DMX Operation • DMX Mapping • Luminaire Timing • Updating Software 02 .9685 .0001 0 01-March-2006...

  • Page 40: Color Control

    Color Control The VL500 Wash Luminaire’s color system is composed of the patented DICRO❋TUNE CYM, color mixing mechanism. The following sections describe the various components of the VL500 wash luminaire. CYM Crossfade Color Mixing The color mixing mechanism is made up of two individual color bulkheads that contain Cyan, Yellow, and Magenta (CYM).

  • Page 41: Dmx Operation

    Focus timing: Pan and Tilt Color Timing: Cyan, Yellow, and Magenta. In VL500 Arc Units: Intensity Timing is LUMINAIRE TIMING and VL500A Arc Units still use 13 channels although it does not have a diffuser mechanism and Intensity Timing in place of Beam Timing.

  • Page 42: Dmx Mapping

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL DMX Mapping CYM Crossfade Color Mixing and Dimming CYM Crossfade Color Mixing Table 3-1: DMX Map For CYM Crossfade Color Mixing % Value DMX Value Action Open (White) Closed (Full Saturation)

  • Page 43: Luminaire Timing

    PERATION UMINAIRE IMING Luminaire Timing Luminaire Timing Channel Information Timing channel control improves the timed moves of certain groups of parameters. Three timing channels are provided, one for Pan and Tilt, one for color parameters and one for beam parameters. Timing channels support time values of up to six minutes.
  • Page 44 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Table 3-5: Timing Channels Map % Value = Seconds Full Speed 01-March-2006 0 2.9685 .0001 0...
  • Page 45 PERATION UMINAIRE IMING Table 3-5: Timing Channels Map (Continued) % Value = Seconds 10.2 10.4 10.6 02.9 685.00 01 0 01-March-2006...
  • Page 46 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Table 3-5: Timing Channels Map (Continued) % Value = Seconds 01-March-2006 0 2.9685 .0001 0...
  • Page 47 PERATION UMINAIRE IMING Table 3-5: Timing Channels Map (Continued) % Value = Seconds 02.9 685.00 01 0 01-March-2006...
  • Page 48 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Table 3-5: Timing Channels Map (Continued) % Value = Seconds 01-March-2006 0 2.9685 .0001 0...
  • Page 49 PERATION UMINAIRE IMING Table 3-5: Timing Channels Map (Continued) % Value = Seconds 02.9 685.00 01 0 01-March-2006...

  • Page 50: Control Channel Functions

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Table 3-5: Timing Channels Map (Continued) % Value = Seconds Follows Cue Data Control Channel Functions The following control actions must be accomplished with zero time transition or with timing disabled.

  • Page 51: Updating Software

    PERATION PDATING OFTWARE Updating Software Reprogramming Luminaires In some cases, it may be desirable to upgrade the luminaire’s operating software. This process requires a PC, VLDownload.exe, .bin files and the Luminaire Programming Kit (28.9661.0054). Components Overview Computer Requirements • PC running Windows 95/98, Windows NT (4.0 or higher), Windows 2000, or Windows XP. (Program is not compatible with Macintosh computers.) •...

  • Page 52: Reprogramming Procedure

    Download All. (Software version is identified by the date and time: MM/DD/YY and HH:MM.) The buttons function as follows: VL500 button downloads the software to all VL500 luminaires. Download All button is the equivalent of executing all of the specific software version buttons shown in the window (if applicable).
  • Page 53 PERATION PDATING OFTWARE Note: Version dates shown in this graphic are for illustration purposes only and may not correspond to the version you are downloading. Click to download all Click to download specific software listed software versions version to connected luminaire(s) to connected luminaire(s) Lists the specific versions of software that have been...

  • Page 54: Transferring Software From Luminaire To Luminaire

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Verify software version at luminaire: Step 1. At Menu Display, press [Menu]. Step 2. Press [Up] / [Down] arrows until Fixture appears. Press [Enter]. Step 3. Press [Up] / [Down] arrows until Version appears. Press [Enter].
  • Page 55 PERATION PDATING OFTWARE Step 4. Press [Up] / [Down] arrows until Download appears. Press [Enter]. Step 5. OK? will be displayed. Press [Enter] to accept. Step 6. Download will proceed. (Download will take 4-5 seconds.) The number of blocks displayed will be less in a luminaire-to-luminaire download than in a PC-to-luminaire download for the same software version.
  • Page 56 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Notes 01-March-2006 0 2.9685 .0001 0...

  • Page 57: Chapter 4. Menu System

    HAPTER Menu System This chapter contains instructions for operating the luminaire using the Menu Display feature. • Menu Operation • Self Tests 02 .9685 .0001 0 01-March-2006...

  • Page 58: Menu Operation

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Menu Operation What Is the Menu System? The menu system is controlled by four buttons. These buttons function as follows: Series 500 Menu Display LCD Display Menu Display Softkeys - The menu has four softkey buttons that change to accommodate menu selection.

  • Page 59: Default State

    YSTEM PERATION The menu system is a programmable set of commands used to configure, address, operate, and test the luminaire. The menu system is controlled at the Menu Display available at the enclosure input panel. The menu system has seven main functions which are referred to as “1st level.” Within these main functions, there can be up to four additional sub-functions (levels 2 thru 5), making five total levels.

  • Page 60: Lamp Hours Progress Bar (Arc Models Only)

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Lamp Hours Progress Bar (Arc Models Only) For arc models, there is a Lamp Hours Progress Bar representing lamp hours used on the lamp. It is tied directly to the lamp hours within the MCB. The bar, when fully extended across the full width of...

  • Page 61: Menu System Overview

    YSTEM PERATION Menu System Overview The following is a graphic representation of the entire menu system. value (1 thru 512) Address Setup Lamp Manual value 575W Lamp? CNFRM 575? Type Tilt value Set Level Normal Dimmer value Turbo Diffuser value Lamp Saver 700W Lamp? CNFRM 700?

  • Page 62: Menu System Functions

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Menu System Functions Table 4-1: Menu System Chart 1st Level 2nd Level 3rd Level 4th Level 5thLevel Address XXX Address value DMX Address SetUp Lamp Type 575W LAMP? / Normal Luminaire Set Up...
  • Page 63 YSTEM PERATION Table 4-1: Menu System Chart (Continued) 1st Level 2nd Level 3rd Level 4th Level 5thLevel Configure Lamp Lamp Options Power * Lamp Power ON * (default) System Configuration * These lamp options are inactive (disabled) if external dimmer is Power Up * Lamp Power-up Lamp ON * Lamp On selected in SetUp.
  • Page 64 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Table 4-1: Menu System Chart (Continued) 1st Level 2nd Level 3rd Level 4th Level 5thLevel Mode Extended Operates in DMX Data and extended 16 bit mode Pan/Tilt 16 Bit Operates in standard...
  • Page 65 YSTEM PERATION Table 4-1: Menu System Chart (Continued) 1st Level 2nd Level 3rd Level 4th Level 5thLevel Test ** ALL SEQ Sequence Through All RunTest Press [Menu] to stop tests System Test Tests Pan/Tilt Pan/Tilt RunTest Pan Pan Pan 1 Pan 2 Tilt Tilt Tilt 1...

  • Page 66: Function Definitions

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Function Definitions Each menu item is listed in the first column by its display abbreviation. The abbreviations appear in alphabetical order as opposed to their position in the menu display sequence for easy reference.
  • Page 67 YSTEM PERATION Table 4-2: Menu Function Definitions (Continued) Display Definition Purpose Accesses functions for setting DMX mode or pan/tilt options. Download Download Downloads program to luminaires. Enable Enable Enables a function. Encoders Accesses pan or tilt encoder for diagnostic testing ( Test ). Encoder External External Dimmer...
  • Page 68 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Table 4-2: Menu Function Definitions (Continued) Display Definition Purpose On Indefinitely Sets Menu Display to stay on until programmed otherwise ( Display ), turns on a function, or turns on a menu item.

  • Page 69: Self Tests

    Note: There is a known issue with all versions of code for the VL500™ wash luminaires concerning the “Test” menu options. Issues arose when running a test from one VL500™ wash luminaire to multiple VL500™...

  • Page 70: Diagnostic Tests

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Movement Disable The Movement option allows pan and tilt to be disabled so that the luminaire can be placed in any position for testing without movement occurring. In order to regain full control of the luminaire, Movement will need to be enabled after testing.

  • Page 71: Appendix A. Maintenance

    PPENDIX Maintenance This appendix provides instructions for performing routine maintenance which may be necessary during the life of the luminaire. • Routine Maintenance WARNING: All maintenance procedures are to be performed with power removed from the luminaire. Never remove covers or open front lens or backcap assemblies while lamp is in operation.

  • Page 72: Routine Maintenance

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Routine Maintenance Lamp Replacement WARNING: Remove power from luminaire before performing maintenance. To remove and replace lamp: Step 1. Remove power from luminaire. WARNING: Lamps will be extremely HOT after operation. Allow lamp to cool before replacing.
  • Page 73 ROUBLESHOOTING AND AINTENANCE Step 7. Install lamp by pressing firmly into socket. Ensure lamp is fully seated in socket with base of lamp against socket base. Step 8. Install lamp into lamp socket taking care not to touch lamp glass. Step 9.

  • Page 74: Front Glass Replacement

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Front Glass Replacement WARNING: Remove power from luminaire before performing maintenance. Parts: as needed: GLASS, FRONT, CLEAR (Vari-Lite part: 42.9685.0201) GLASS, FRONT, STIPPLE (Vari-Lite part: 42.9685.0207) GLASS, FRONT, MED. FLOOD 8-ROW LENT. (Vari-Lite part: 42.9685.0203) GLASS, FRONT, MED.
  • Page 75 AINTENANCE WARNING: When installing a new or replacement lens in a VL500A (ARC) Wash, all lens types must be installed curve out (convex). In tungsten fixtures (VL500 , VL500D , and VL500 80V Wash), Clear and Stipple lenses may be installed curve in (concave) and all Lenticular (8-Row, 10- Row, and 12-Row) and Buxom lenses must be installed curve out (convex).

  • Page 76: Cleaning Optical Lenses And Filters

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Cleaning Optical Lenses and Filters WARNING: Remove power from luminaire before performing maintenance. The front lens, optics/color filters, and reflector may require cleaning after extended use. • FRONT LENS : Use a common glass cleaner along with a soft, lint-free cloth to clean the front lens.

  • Page 77: Appendix B. Technical Specifications

    Pastel (Dichroic Glass) Option: As an option, all versions of the VL500 wash luminaire are available with “pastel” or lighter colored blue and magenta color filters. VL500 wash luminaires fitted with pastel- colored dichroic glass maintain the electrical specifications of the standard version of the VL500 wash.

  • Page 78: Optical

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Optical Source Model Lamp Color Temperature VL500 (120V) Tungsten, 120V, 1200W 3200 VL500 (230V) Tungsten, 230V, 1000W 3200 VL500D (120V) Tungsten, 120V, 1200W 3200 VL500D (230V) Tungsten, 230V, 1000W 3200 VL500A (575W)

  • Page 79: Operational

    Arc, 700W 90 - 264VAC, 50/60Hz Note: • Current draw depends on input voltage. For specific current draw, please refer to the VL500 wash page 9 "Current vs. Voltage" tables starting on Operational Temperature -20° to 122°F (-29° to 50°C)

  • Page 80: Photometric

    ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Photometric 1200W, 120V Tungsten Lamp (3200K Color Temperature) Foot Candles CANDELA Beam Angle Field Angle Lens Lumens (measured at 124 (measured at 3.149 (cd) (degrees) (degrees) inches) meters) Clear 7,241 352,139...
  • Page 81 ECHNICAL PECIFICATIONS Photometric (continued) 700W, Arc Lamp (7200K Color Temperature) Foot Candles CANDELA Beam Angle Field Angle Lens Lumens (measured at 124 (measured at 3.149 (cd) (degrees) (degrees) inches) meters) Clear 15,441 1,941,035 18,190 195,724 Stipple 14,402 694,467 6,510 70,047 16.5 02.9 685.00 01 0 01-March-2006...
  • Page 82 ❋ VARI LITE® - VL500™ W ’ UMINAIRE ANUAL Notes 01-March-2006 0 2.9685 .0001 0...
  • Page 84 Vari-Lite 10911 Petal Street Dallas, Texas 75238 1-877-VARI-LITE 1-214-647-7880 www.vari-lite.com ©2006 Genlyte Group LLC. All rights reserved.
