10. Keep clothes, jewelry or loose items away from moving parts. NOTE: Maximum weight capacity for the PhysioStep HXT is 330 lbs (150 kgs) WARNING BEFORE BEGINNING ANY EXERCISE PROGRAM CONSULT YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 AND PEOPLE WITH PRE-EXISTING HEALTH PROBLEMS.
PARTS LIST Description Description Main Frame 30 DC Motor Computer 31 Rear Leg Wheel Magnetic Flywheel 32 Hexagonal Bolt M8*15L Pedal Axle 33 Washer OD26*ID8.5*2T Pulley 34 Screw M4*10L Mushroom Screw-M6*15L 35 Screw M5*15L Nylon Nut (M6) 36 Stick of Number 37 Tube Cover∮...
Page 5
Description Description 90 Upper Computer Sensor Wire 59 Seat 91 Computer Sensor Wire 60 Seat Moving Set 92 Power inlet 61 Hand fixed block 93 Rubber Cover 62 Dipping Handle 94 C-Ring-S35 63 Pin 95 C-Ring-S42 64 Spring 96 Mushroom Screw ST4.5*50L 65 Knob 66 Shaft for PU Wheel 97 Curved Washer M8...
Dear Valued Customer, Thank you for your recent purchase of the PhysioStep HXT from HCI Fitness. Prior to using your new PhysioStep HXT please review the owner’s manual as well as the product tips to maximize your workout experience. We wish you the best of luck in reaching your health and...
Page 7
ASSEMBLY Step 1 Assembling Seat Back Remove Bolts (No.32) from the seat back (No.75). Attach seat back (No.75) to seat back support (No.70) using bolts (No.32). Secure bolts tightly. Check tightness periodically. Step 2 Wire Connection Connect Upper Display Sensor Wire (90, Lower Display Sensor Wire (91), Upper HR Sensor Wire (88) and Lower HR Sensor Wire (89).
Page 8
ASSEMBLY Step 4 Connect Lower Arm Assembly Insert the Rubber Cover (93) in to the Moving Handle Set ( R ) (24) and fix the Moving Handle Set ( R ) (24) to the Moving Handle Set (28) using the bolt (32). Step 5 Handle Grip Assembly Insert the Moving Handle Set (26) to the...
Page 9
ASSEMBLY Step 7 Attaching the Joint Cover Attaching the Connecting Tube Cover (29) to the joint from the Moving Handle Set (28) and the Connecting Parts (22) using the screws (96). Step 8 Connect Power Put the end of the Adapter (No.46) in the input socket (No.45) on the back of the Main frame (No.1), then put the another end of the adapter (No.46) to connect with the power...
Page 10
MANUAL: PHYSIOSTEP HXT DISPLAY CONSOLE Key Functions Displays Operating Ranges Notice Before Exercise Operation Instructions Key Functions There are total 6 keys labled UP, DOWN, ENTER, START/STOP, PULSE AND MODE. A. UP (▲): Selects or increases the values of PROGRAMS, GENDER, TIME, HEIGHT, WEIGHT, WATT, CALORIES, TARGET HEART RATE, AGE, DISTANCE and 10 columns.
Page 11
D. LEVEL: Indicates the level of loading selected from LEVEL 1 to LEVEL 16. E. GENDER: Indicates the gender (Male or Female) selected. F. TIME/HEIGHT/WEIGHT Display: Indicates only one value of TIME, HEIGHT, or WEIGHT displayed depending on the programs. G.
Page 12
Operating Ranges Values Range (Count up) Count down Preset Increment (Decrement) PROGRAM 1 ~ 17 17 ~ 1 LEVEL 1 ~ 16 16 ~ 1 GENDER Male, Female Male TIME 0:00 ~ 99:59 99:00 ~ 5:00 0:00 1:00 HEIGHT (cm) 110.0 ~ 199.5 199.5 ~ 110.0 175.0...
Page 13
Program 1 (Manual) Program 2 (Rolling) Program 3 (Valley) Program 4 (Fat Burn) Program 5 (Ramp) Program 6 (Mountain) Program 7 (Intervals) Program 8 (Body Fat) Program 9 (Target H.R.) Program 10 (60% H.R.C.) Program 11 (75% H.R.C.) Program 12 (85% H.R.C.) Program 13 (User Setting) Program 14 (User Setting) Program 15 (User Setting)
Page 14
Program 17 (Watt Control) E. Body Types: F. There are 9 body categories divided according to the FAT% calculated. Type 1 is from 5% to 9%. Type 2 is from 10% to 14%. Type 3 is from 15% to 19%. Type 4 is from 20% to 24%.
Page 15
E. Body Fat Program: Program 8 is a special program designed to calculate users’ body fat ratio and to design a specific loading profile for users. With 9 different body types, the computer can generate 9 different profiles for each. Press “ENTER” key to select GENDER, HEIGHT, WEIGHT, and AGE.
After pressing “START/STOP” key to exercise, please also apply the heart rate detector appropriately. During the exercise, the level of loading is not adjustable. In this program, computer will adjust the level of loading according to the value of WATT setup. For example, the level of loading may increase while the speed is too slow.
Page 17
Symptom Possible Cause Solution The Adaptor is not plugged in? Check that the Adaptor is correctly connected to the Mains The LCD Screen does NOT Power Socket and is correctly connected to the Computer. Display anything The Computer is faulty? Replace the Computer by contacting your dealer.
Page 18
Open the Computer Case, The connection between the remove the Circuit Board Circuit Board and the LCD Screws, gently remove the Screen Membrane is Circuit Board, reassemble the The LCD Screen Partially Misaligned. If this is the LCD Screen and/or the problem you might be able to Membrane taking care not to see that the LCD Screen is on...
Page 19
(1)Review the Assembly Instructions and check that all the Computer Plugs and Sockets are FIRMLY and correctly connected. (2)Review the Bike’s Magnetic Resistance System to ensure that it is set correctly and they be at it can freely be adjusted. A symptom of the previous problem is the Motor will struggle to adjust the...
Page 20
(1)Review the Bike’s Magnetic Resistance System to ensure that it is set correctly and they be at it can freely be adjusted. A symptom of the previous problem is the Motor will struggle to adjust the resistance and will start making an abnormal sound.
