UG171: ZigBee
Design (RD-0051-0201) Kit User's Guide
Silicon Labs' compact and cost-effective smart outlet reference design is based on Zig-
Bee HA (Home Automation) 1.2 standard and can be used in conjunction with a ZigBee
HA 1.2 home automation system. This reference design kit features Silicon Labs'
EFR32MG1P232F256GM48 ZigBee Pro Wireless Microcontroller (MCU), the Si7021
temperature and relative humidity sensor, and the Si1141 ambient light sensor. This
document contains instructions and guidelines for the following: a quick-start demon-
stration and next steps, system overview and operations, hardware and firmware con-
siderations, and engineering and manufacturing testing.
This guide applies to EmberZNet PRO 5.8 and later.
silabs.com | Smart. Connected. Energy-friendly.
®
Smart Outlet Reference
KEY POINTS
• Quick start demonstration
• Recommended next steps
• Kit overview
• Device operation
• HA 1.2 and FCC certifiable
• Hardware and Firmware Considerations
• Ecosystem considerations
• Engineering and Manufacturing Testing
Rev. 0.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZigBee and is the answer not in the manual?

Questions and answers

Summary of Contents for Silicon Laboratories ZigBee

  • Page 1 Design (RD-0051-0201) Kit User's Guide Silicon Labs' compact and cost-effective smart outlet reference design is based on Zig- Bee HA (Home Automation) 1.2 standard and can be used in conjunction with a ZigBee KEY POINTS HA 1.2 home automation system. This reference design kit features Silicon Labs’...
  • Page 2 Si1141 ambient light sensor. The outlet also features voltage, current, and power measurement capability, as well as current and ther- mal overload shutdown features. The reference design can be directly integrated into a connected ZigBee home automation applica- tion, as shown in Figure 1.2 ZigBee Home Automation with Smart Outlets on page...

  • Page 3: Quick Start Demonstration

    3. Connect the ZigBee Smart Outlet to the ZigBee network. a. Follow the directions provided with the ZigBee gateway to enable the smart outlet reference design to join its ZigBee network. b. Depress and hold external front button for more than three seconds, then release to begin the network join procedure.

  • Page 4: Recommended Next Steps

    A video showing the recommended next steps is available at http://www.silabs.com/zigbeesmartoutlet. 3.1 Evaluate the Smart Outlet The ZigBee smart outlet reference design can support most smart power outlet application requirements. Typical areas of evaluation include: 1. ZigBee network behavior, such as network join and leave.
  • Page 5 Table 4.1. Part Numbers and Description Part Number PCB Marking Description RD-0051-0201 ZigBee Smart Outlet Reference Design Kit with North America plug using EFR32MG1P232F256GM48, Si7021, Si1141 and PCB Antenna. RD-0051-0101 IST-A0081 rev 2.0 ZigBee Smart Outlet Reference Design Evaluation Board with North America (Power Board) plug using EFR32MG1P232F256GM48, Si7021, Si1141 and PCB Antenna.
  • Page 6 Smart Outlet Reference Design (RD-0051-0201) Kit User's Guide Overview 4.3 ZigBee Smart Outlet Reference Design This reference design contains many features for the evaluation of a smart outlet, including: Table 4.2. ZigBee Smart Outlet Reference Design Features Reference Design Features Benefit 15 A power relay Allows for power control of most household electronic products.
  • Page 7 The reference design firmware application contains the following features: • Pre-compiled and source application firmware. • Over-the-Air (OTA) upgradable. • ZigBee HA 1.2 pre-certifiable clusters: Basic, Identify, On/Off, Metering, Temperature Measurement, Electrical Measurement, Diag- nostics, and OTA Cluster. • Application firmware (source code) available in the EmberZNet ™...

  • Page 8: Operation

    5.1.1 Remote Control The ZigBee smart outlet reference design utilizes a 15A controllable relay to manually or remotely toggle power to a device connected to the front female outlet of the device. If it receives an “on” command from the gateway it will close the relay contact to supply power to the load.
  • Page 9 This section describes the various operational states that the smart outlet reference design is able to occupy as it joins and leaves a ZigBee network. The input mechanism for operation utilizes the external push button. The green LED and red LED operates as output signaling information as the reference design traverses or occupies a functional state.
  • Page 10 5.2.5 ON-NETWORK State The ON-NETWORK state is a condition where the smart outlet reference design is connected to a ZigBee network and is not searching for another network. This state contains multiple entry and exit paths depending on various factors.
  • Page 11 The RF board mounts on the power board via connectors. The sensor board mounts to the power board with a ribbon cable connector. 6.1.1 RF Board Highlights • ERF32MG ZigBee Pro radio with an embedded flash • Cirrus Logic CS5463 energy monitoring IC •...
  • Page 12 The demo board can be reprogrammed with an available .ota file and a device that can perform OTA upgrades such as the RD-0001 or RD-0002 ZigBee USB Gateway Kit supported by Silicon Labs. Refer to the gateway documentation for more information on how to reprogram via OTA upgrade.
  • Page 13 ® UG171: ZigBee Smart Outlet Reference Design (RD-0051-0201) Kit User's Guide Firmware 7.5 Cluster Support This section details clusters that were implemented as part of this project. Cluster Name Cluster Hex Value Basic 0x0000 Identify 0x0003 On/Of 0x0006 Over The Air Boot Loading...
  • Page 14 ® UG171: ZigBee Smart Outlet Reference Design (RD-0051-0201) Kit User's Guide Firmware 7.7 Included Plugin Options Numerous plugins are available from the EmberZNET PRO stack. Notable ones are described in this section, along with their set op- tions. Manufacturing Library CLI To assist with the manufacturing process, the occupancy sensor reference designs include the manufacturing library as well as the manufacturing library CLI commands.
  • Page 15 Theory of operation Silicon Laboratories has created a custom ZigBee cluster that provides RF commands for the purpose of putting the device receiving the commands into manufacturing test mode. Specifically, it can force the device to transmit an unmodulated tone, transmit a modula- ted tone, or receive packets for a short time to check the TX or RX path of the device in the field.
  • Page 16 ® UG171: ZigBee Smart Outlet Reference Design (RD-0051-0201) Kit User's Guide Firmware Here is an example of the commands used to command the reference design to transmit a modulated carrier at channel 15 with a pow- er of 13 dBm until the next device power cycle.

  • Page 17: Ecosystem Considerations

    8. Ecosystem Considerations In this reference design the firmware examples are ZigBee HA certifiable. As such, they should work with any of the ZigBee-certified Home Automation gateways in the market. However, each gateway may have some individual requirements beyond the ZigBee Home Automation requirements.

  • Page 18: Engineering Tests

    • Underwriter's Laboratory (UL) 9.1 ZigBee Home Automation HA v1.2 The outlet reference design went through a preliminary HA 1.2 testing to verify compliance with the ZigBee standard. 9.2 FCC Emissions Testing This design went through a preliminary FCC pre-scan testing to verify compliance with FCC Part 15 restrictions. Such testing is done to ensure customers are given a design that can pass FCC tests.

  • Page 19: Manufacturing Tests

    • Desktop PC • RF Shielded Box • Isolated AC Mains power supply • 2x WSTK with debug adapter board • Golden Node (Silicon Labs ZigBee coordinator device) • Spectrum Analyzer (Agilent E4407B) • Device Under Test (DUT) 10.3 Test System Diagram Figure 10.1.
  • Page 20 ® UG171: ZigBee Smart Outlet Reference Design (RD-0051-0201) Kit User's Guide Manufacturing Tests 10.4 Test System Connection Procedure Wire the system as indicated above. All WSTK adapters will be connected to the PC through USB. One adapter will connect to the DUT, to both reprogram and interact with the DUT, whereas the second adapter will connect to the Golden Node for testing network functionality.
  • Page 21 Trademark Information Silicon Laboratories Inc.® , Silicon Laboratories®, Silicon Labs®, SiLabs® and the Silicon Labs logo®, Bluegiga®, Bluegiga Logo®, Clockbuilder®, CMEMS®, DSPLL®, EFM®, EFM32®, EFR, Ember®, Energy Micro, Energy Micro logo and combinations thereof, "the world’s most energy friendly microcontrollers", Ember®, EZLink®, EZRadio®, EZRadioPRO®, Gecko®, ISOmodem®, Precision32®, ProSLIC®, Simplicity Studio®, SiPHY®, Telegesis, the Telegesis Logo®, USBXpress®...
