SP5 Signal Processor
Phase shift & Metal Loss Corrector
Handbook Contents:

Safety

•
•
•
•
•
•
•
•
Safety:
This symbol is used to alert the user to important
operating or maintenance instructions.
The Lightning bolt triangle is used to alert the user
to the risk of electric shock.
1. It is important to read these instructions, and to follow them.
2. Keep this instruction manual in an accessible place.
3. No user serviceable parts. Refer all servicing to qualified personnel.
4. No objects filled with liquids, such as vases, shall be placed on the
apparatus.
WARNING: Do not expose to dripping or splashing.
5. Clean only with a dry cloth.
Box Contents:
1 x SP5
1 x 15V Power cable
2 x 3-pole jack to jack cable
1 x Handbook (this document)
1 x SP5 connection drawing
