Summary of Contents for LH Argo LH 1200
- Page 1 OPERATORS MANUAL & FITTING INSTRUCTIONS FOR THE LH 1200 SPRAYER MONITOR LH No. 020-122-UK Version 2.00 LH Technologies Denmark ApS Mølhavevej 2 9440 Aabybro Denmark Tel. +45 9696 2500 Fax. +45 9696 2501 Internet: http://www.lh-agro.com/...
- Page 2 LH 1200 O & PERATORS FITTING MANUAL LH A...
-
Page 3: Table Of Contents
Contents INTRODUCTION .........................4 OVERVIEW .........................5 GENERAL USE ........................6 FERTILISER DISTRIBUTOR ..................6 SEED DRILL ......................7 OPERATING THE LH 1200 ....................8 PRIMARY FUNCTIONS ....................8 WORK TIME ......................8 FORWARD SPEED ....................8 AREA COUNTERS ....................9 APPLICATION RATE FOR SPRAY CHEMICALS ..........10 SPRAY CHEMICAL CONSUMPTION..............10 SECONDARY FUNCTIONS, FERTILISER DISTRIBUTOR ........11... -
Page 4: Introduction
PERATORS ITTING MANUAL INTRODUCTION Congratulations with your new LH 1200 sprayer monitor. During development of this monitor we have made a point of producing a durable product that is primarily developed to monitor chemical application. The monitor however, includes a number of other functions, which enable it to be used in connection with almost any other implement. -
Page 5: Overview
LH 1200 O & F PERATORS ITTING MANUAL VERVIEW OVERVIEW Pos. Description Pos. Description Time functions Flow figure calibration Forward speed Flow figure encodement Area (trip) Working width encodement Application rate Wheel circumference encodement Area (total) Reset key Amount used (total) -
Page 6: General Use
& F ENEREL USE PERATORS ITTING MANUAL GENERAL USE The LH 1200 is especially designed for use on a crop sprayer. The following primary functions can be selected directly from the keypad: Work time Forward speed Area counters (trip- and total) -
Page 7: Seed Drill
When Forward speed is selected and the area override sensor is activated an “r” is displayed on the left-hand side of the display. The LH 1200 is equipped with a system test program, which enables the user to test all connected sensors. For more information, see the ”SYSTEM TEST”... -
Page 8: Operating The Lh 1200
LH 1200 LH 1200 O & F PERATING THE PERATORS ITTING MANUAL OPERATING THE LH 1200 PRIMARY FUNCTIONS WORK TIME Function Work time in hours and minutes: Pressing this key displays the effective work time (max. 99 hours 59 minutes) The time counter is started and stopped by pressing the key. -
Page 9: Area Counters
LH 1200 O & F LH 1200 PERATORS ITTING MANUAL PERATING THE AREA COUNTERS The area counters start and stop automatically when the implement is in work/not in work (implement sensor), and continue to count regardless of what other function in the “primary functions“ has been selected. -
Page 10: Application Rate For Spray Chemicals
LH 1200 LH 1200 O & F PERATING THE PERATORS ITTING MANUAL APPLICATION RATE FOR SPRAY CHEMICALS Function Application rate: Pressing this key displays the present application rate in litres per ha. The calculated application rate is based on the flow through the flow meter and area metering. -
Page 11: Secondary Functions, Fertiliser Distributor
PRIMARY FUNCTIONS section of this manual. RPM FOR DISC SPREADERS Encoding a flow figure of 9999 alters the program in the LH 1200 allowing it to display RPM. RPM is displayed by pressing the L/Ha. key. ENCODE: Press the shown keys in this order. -
Page 12: Secondary Functions, Seed Drill
The functions require the same sensors and the same keys are used. SOW AXLE RPM Encoding a flow figure of 9999 alters the program in the LH 1200 allowing it to display RPM. RPM is displayed by pressing the L/Ha. key. ENCODE: Press the shown keys in this order. -
Page 13: Secondary Functions; Slurry Spreader
LH 1200 O & F LH 1200 PERATORS ITTING MANUAL PERATING THE SECONDARY FUNCTIONS; SLURRY SPREADER APPLICATION RATE MONITORING Flow metering is possible on slurry spreaders either by using a flow meter (electromagnetic) or by a RPM sensor fitted to a positive displacement pump (exact volume per revolution). -
Page 14: Secondary Functions, Distance Measuring
LH 1200 LH 1200 O & F PERATING THE PERATORS ITTING MANUAL SECONDARY FUNCTIONS, DISTANCE MEASURING This function can only be used alone. When this function is activated, all other functions are unusable. ENCODE: Press the shown keys in this order. -
Page 15: Encoding The Lh 1200
LH 1200 O & F LH 1200 PERATORS ITTING MANUAL NCODING THE ENCODING THE LH 1200 WORKING WIDTH Function Working width: The working width of the implement being used is encoded here. Step Procedure Press the working width key. Encode the working width in centimetres using the numerical keys. -
Page 16: Wheel Circumference With Magnets Fitted To The Wheel
LH 1200 LH 1200 O & F NCODING THE PERATORS ITTING MANUAL WHEEL CIRCUMFERENCE WITH MAGNETS FITTED TO THE WHEEL Step Procedure Make a mark on the field and on the tire on the wheel with magnets fitted. Drive slowly forward until the wheel has turned 10 times. -
Page 17: Wheel Circumference With A Magnet Fitted To Cardan Shaft
LH 1200 O & F LH 1200 PERATORS ITTING MANUAL NCODING THE WHEEL CIRCUMFERENCE WITH A MAGNET FITTED TO CARDAN SHAFT A magnet can be fitted to the cardinal shaft if, for some reason, it is not possible to fit any magnets onto a wheel. To determine the value to be entered as the "wheel circumference"... -
Page 18: Flowmeter Calibration (Flow Figure)
LH 1200 LH 1200 O & F NCODING THE PERATORS ITTING MANUAL FLOWMETER CALIBRATION (FLOW FIGURE) Function Flow figure: 1. If this is the first time that the monitor is being used with a sprayer, encode a "start" flow figure of 2000. -
Page 19: Volume Monitoring Calibration For Seed And Fertiliser
The calibration value is the volume per pulse from the sensor. Thus if you let the LH 1200 count the number of pulses during the normal drill/distributor calibration and thereafter divide the amount released (during calibration) by the number of pulses, a new calibration figure for the implement can be found. - Page 20 LH 1200 LH 1200 O & F NCODING THE PERATORS ITTING MANUAL Procedure 1. Prepare the implement for calibration. Do not turn the metering shaft after the monitor has been prepared for calibration. 2. Encode a flow figure of 9999: Press the keys in this order and the monitor is ready for counting pulses.
-
Page 21: Fitting The Lh 1200
The form supplied with the LH 1200 can be stuck in the cabin so that the noted values can easily be found and re-entered if necessary. -
Page 22: Fitting The Speed Sensor
LH 1200 LH 1200 O & F ITTING PERATORS ITTING MANUAL FITTING THE SPEED SENSOR We recommend fitting the wheel sensor to the tractors right back wheel. See the following diagram. The distance between the magnets and the wheel sensor must not be greater than 5 mm. - Page 23 LH 1200 O & F LH 1200 PERATORS ITTING MANUAL ITTING The wheel sensor can be fitted to the cardinal shaft on 4-wheel drive machines. A ”bipolar” sensor must be used when fitting to the cardinal shaft. This sensor must be ordered separately as it is different than the supplied sensor (see the...
-
Page 24: Fitting The Area On/Off (Implement) Sensor
+12 V MAIN SWITCH SWITCH LIFT UP SPRAYER ON/OFF SIGNAL SIGNAL SIGNAL ELECTRIC ELECTRIC LIFT VALVE COMP. SPRAYER FITTING IMPORTANT! Never connect power (+12V) to the brown output on the LH 1200, as this will damage the LH 1200. LH A... -
Page 25: Fitting The Flowmeter
LH 1200 O & F LH 1200 PERATORS ITTING MANUAL ITTING FITTING THE FLOWMETER Due to the large numbers of different field sprayers on the market it is impossible to make a universal flow meter fitting kit to suit all. However, the following... -
Page 26: System Test
ERROR WARNING To ensure that data will not be lost, the LH 1200 has a built in error indication: If your LH 1200 displays this error warning, the supply voltage to the monitor is too low. Check therefore the power supply to the monitor (both + and -). - Page 27 LH 1200 O & F PERATORS ITTING MANUAL OTES NOTES LH A...
- Page 28 LH 1200 O & F OTES PERATORS ITTING MANUAL LH A...
