- Page 1 Te c h n i c a l d o cu m e n t a t i o n I n s t a l l a t i o n i n s t r u c t i o n s AQ A 3 0 0 / AQ A 50 0 Aus g ab e 22/10/15 Hot water tank for drink water preparation...
-
Page 2: Contents
Contents H E P O W E R F A M I L Y (C) IDM ENERGIESYSTEME GMBH Installation Instruction Hygienik... -
Page 3: Table Of Contents
2.2. Scope of delivery 2.3. Design information 3. T ECHNICAL PECIFICATIONS 3.1. Technical data AQA 300, AQA 500 3.2. Dimensional drawings AQA 300, AQA 500 4. I NSTALLATION 4.1. Setup conditions AQA 300/AQA 500 4.2. Setup location AQA 300/AQA 500 4.3. -
Page 4: General Information
1. General Information 1. General Information D I E E N E R G I E F A M I L I E 1.1 . G ener al infor m ation 1.4 . S e r vic ing a n d ma in te n a n ce Please read this documentation carefully. -
Page 5: Protection Of The Environment
General Information D I E E N E R G I E F A M I L I E 1.8 . P rote cti on of t he envir onm ent The hot water tank is made from high valuable materials, which are not allowed to be disposed like normal household garbage, but have to be disposed professional and proper... -
Page 6: Description 6
2.1 . De scr ipt ion 2.2 . S co p e o f d e liv e r y The hot water tank AQA 300 and AQA 500 consists AQA 300, AQA 500: of high quality steel with a special enameling of the - Boiler chassis with internal baretube, enameled inner surface. -
Page 7: Design Information
D I E E N E R G I E F A M I L I E 2.3 . D e si g n in fo r ma tio n The hot water tank is available in two different sizes. „Boiler capacity AQA 300, AQA 500“ Capacity Intended purpose... -
Page 8: Technical Specifications
EC-Declaration of Conformity EC-Declaration of Conformity IDM-Energiesysteme herewith declares, that the hot water storage tanks, described overleaf, fulfi ll the provisions of the following relevant Community harmonization legislation: - Directive 2009/125/EC of the European Parliament and of the Council of October 21st, 2009 on the establishment of a framework for the setting of eco-design requirements for energy-related products. -
Page 9: Dimensional Drawings Aqa 300, Aqa 500
Technical Specifications D I E E N E R G I E F A M I L I E 3.2 . Di m ensi on a l dr aw ings AQA 300, AQA 500 AQA 500 Plastic cover AQA 300... -
Page 10: Installation
When storing, transporting and assembling the components, it must be ensured that no mechanical effects such as deformations, scratches and tensions occur. 4.2 . Se tup loca t ion AQA 300/AQA 500 1...Pressure reducer (only at more than 6 bar) 2...Emtying valve 3...Backfl ow preventer The boilers must be set up in a frost-free room by an 4...Pressure gauge connecting piece 1/2“... -
Page 11: Filling, Emtying
Installation D I E E N E R G I E F A M I L I E 4.6 . Fi lli ng, Em t y ing Corresponding fi lling- and emptying valves should be provide for easy fi lling and emptying. For frost-proof emptying the hot water tank must be emptied at the points provided for this. -
Page 12: Applications Overview
5. Applications Overview 5. Applications Overview D I E E N E R G I E F A M I L I E 5.1 . Dr awing ex p la nat io n and n ot es o n the Symbol Bedeutung ove r vi ew of t h e applicat io ns... -
Page 13: Overview Of Applications
This schemes are only a tentative suggestion for installing an IDM heat pump in the heating system. This suggestion replaces no professional planning of an executing company! On part of IDM-Energiesysteme can no warrenty be taken concerning the function of the whole system! Install a 18l expansion vessel in the buffer when a TERRA IL Complete or TERRA ML 8-18 with direct heating circuit is used in combination with the AQA 300/AQA 500. -
Page 14: Terra Ml 8-18 + Aqa + Direct Heating Circuit N_2.17-7-10-0-1-2
5. Applications Overview Applications Overview D I E E N E R G I E F A M I L I E 5.2 .1. TERRA IL Complete + AQA + direct h eating ci rcuit N _2 . 10- 7- 1 0- 0- 1 - 0 RE (A) When using direct heating cirles and zone valves, at... -
Page 15: Terra Sw Complete Hgl + Aqa + Termo + 1 Hc N_1.3-0-10-11-1-0
Applications Overview D I E E N E R G I E F A M I L I E 5.2 .3. TERRA SW Com plet e H GL + AQA + T ER MO + 1 HC N _1. 3- 0- 10- 11 - 1- 0 HC-module internal availabel as accessory RE (A) - Page 16 Always there for you. I DM HEADQUARTERS IN EASTERN TYROL , AUSTRIA I DM HEADQUARTERS IN EASTERN TYROL , AUSTRIA IDM ENERGIESYSTEME GMBH IDM ENERGIESYSTEME GMBH Se b l a s 16 – 18 Se b l a s 16 – 18 A-9971 M a trei in O s t tiro l, Aus t ria A-9971 M a trei in O s t tiro l, Aus t ria Te l e p h on e +43(0) 4875.6172 - 0...
