Summary of Contents for CookTek ISW061
- Page 1 INSTALLATION ● OPERATION OWNER’S MANUAL Induction Soup Well Models ISW061, ISW062 CookTek Induction Systems, LLC Phone: 1-800-908-8726 +1 214-379-6000 Fax: +1 214-379-6073 www.cooktek.com customerservice@turbochef.com CT-104456 Manual ISW06x 14161_A USINTL...
-
Page 2: Electrical Installation Requirements
PREPARING YOUR COOKTEK INDUCTION SOUP WELL UNIT FOR USE Before operating your induction soup well, do the following: • Remove all packing material and save for subsequent shipment or in case of concealed shipping damage. • Keep unit away from other heat sources and allow at least 2” (51 mm) between all sides of the housing and any surface or obstacle, and 6” (152 mm) between the bottom of the housing and any surface or obstacle. If either the air intake or exhaust outlet is blocked, the internal temperature will rise, causing an error code to occur. -
Page 3: General Information
Control Panel Heating At Temp POWER LOCK The soup well is designed to be used with an 11qt (10.4 L) bain marie soup tureen. The unit should not be operated without using the water bath. An adapter ring can be purchased separately to allow the unit to work with a 7 qt (6.6 L)soup tureen. APPROVED FOR COMMERCIAL USE CookTek’s soup well is in conformance with ANSI/UL 197 and CSA 22.2 No. 109 standards and bears the commercially rated approvals. CookTek’s soup well is in conformance with European Economic Area standards and bears the CE marking signifying European Conformity. -
Page 4: General Operation
7qt (6.6 L) soup tureen, an adapter ring is needed to ensure proper heating and prevent damage to the appliance. Adapter rings must be purchased as an accessory through CookTek. • Fill the water pan with the appropriate amount of water. - Page 5 SMARTEMP OPERATION • Place an induction compatible pan in the unit. • The letter “F” or “C” will flash in the display window and the Heating Heating LED will turn on. • When the pan has reached the selected temperature, the “F” or “C” will stop flashing and remain solid. The Heating LED At Temp will turn off and the At Temp LED will turn on. • The set temperature can be adjusted at any time while the pan is on the unit by pressing the Up and Down Arrows. • When a pan is removed from the unit, the Heating and At Temp LEDs will turn off and the “F” or “C” will turn on solid in the display. The unit is not heating or holding the set temperature when both LEDs are off. • When finished using the unit, press the Power button to turn the unit off. The Power LED will turn off. Remove then pan from the unit. The unit will remember the last temperature setting the next time it is powered on. CHANGING THE TEMPERATURE SCALE (F/C) • Starting with the unit off, hold down the Up Arrow while pressing the Power button.
-
Page 6: Timer Operation
TIMER OPERATION • To enable/disable the timer feature, see “Setting the Timer” below. • If the timer is enabled, the timer will start counting when a pan is Heating placed on the unit and the Heating or At Temp LED will turn on. • The timer will count continuously up (in minutes) until it is reset by At Temp removing the pan. • The timer is reset when the pan is removed from the unit and the Heating Heating or At Temp LED turns off. The next time a pan is placed on the unit the timer will start again from the beginning. At Temp • To view the elapsed time from when the pan was placed on the unit, press the Lock button once. This will display the time (in minutes) from... - Page 7 • Never heat empty cookware or operate the unit without the water bath. Doing so may damage the unit or cookware and overheat the unit. When overheating occurs, an error code will flash on the display and the unit will shut itself off automatically. When the temperature returns to normal, the unit can be used again. • The cookware in the appliance will heat continuously as long as the power is ON. The cookware will be hot and caution should be exercised when working on or near the appliance. • This product may only be serviced by an authorized service agent or by CookTek personnel. DO NOT attempt to open the unit or perform service of any kind. For service information, contact CookTek at +1 (214) 379-6000. • DO NOT use the soup well for anything other than its intended use as described in this manual. This unit is designed to rethermalize and hold soup and is not intended for laboratory or industrial use. • DO NOT use any appliance that has a damaged cord or plug, or one that has malfunctioned or been damaged. Consult the warranty at www.cooktek.com/ warranty-service and follow instructions for service. • The soup well is designed to work with standard 11 qt (10.4 L) and 7 qt (6.6 L) tureen inserts. An adapter ring (sold separately) is required to accommodate 7 qt (6.6 L) tureens. • DO NOT use any accessories or attachments that are not recommended by the manufacturer. Use of unapproved accessories may cause injuries and void the warranty. • The CookTek soup well comes with a stand-alone (not built-in) control box for unit operation. Use ONLY the control box that comes with the unit to avoid any possible operation hazards. • DO NOT let the power cord touch hot surfaces or hang over the edge of the counter.
-
Page 8: Warranty Statement
WARRANTY STATEMENT Please visit www.cooktek.com/warranty-service for CookTek Warranty information. CARE AND CLEANING Your CookTek Induction soup well is easy to keep clean. Be sure to follow these easy instructions: • Turn the unit OFF and remove the plug from any power outlets prior to cleaning. • When the unit cools, wipe off with a damp cloth. • To clean the surface, use a mild detergent or glass cleaning cream. • Never immerse the soup well in water or put it in the dishwasher. To clean the control panels: • Control panels should only be cleaned with a damp cloth. • Exposure to water spray may cause control panel failures. • Control panels should only be mounted vertically never horizontally. • Control panels are NOT water tight. Manual ISW06x 14161_A USINTL... -
Page 9: Troubleshooting
• Possible power brown • Assure proper voltage/power levels. suddenly stops out. • Make sure the dry well is not heating. • Circuit shared with sharing a circuit with electrical another electrical devices other than CookTek soup device. well units. • Safety shut-off • The safety shut-off will engage if an engaged. empty pan is left on the soup well surface while the unit is working at full power. Make sure that the dry well surface is clear. Wait 15-20... -
Page 10: Error Codes
ERROR CODES In the event of a possible malfunction, your CookTek soup well will display an error code on the alphanumeric display. Units will beep a specific number of times, indicated by the error and flash the lights on the control box. Please consult the following table when encountering an error code. To reset error conditions, remove the pan from the unit and press the Power button, or unplug the unit. Error Error Cause Displayed Message Troubleshooting Broken temperature E-01 Service required. sensor. Broken temperature E-02 Remove any pans from sensor. Pan temperature the dry well surface and is too high. -
Page 11: Clearance And Dimensions
CLEARANCE AND DIMENSIONS Clearance: Be sure to allow for a minimum clearance of 2” (51 mm) between all sides of the housing and any surface or obstacle, and 6” (152 mm) between the bottom of the housing and any surface or obstacle. The soup well requires 6-inch (3870 mm ) of free air space within 8” (203 mm) of the top of cabinet, and within 24” (610 mm) of each unit. Venting can be slots or holes as desired. If the ambient air temperature is above 110 F (43.3 C), the unit may not function properly. Dimensions (All Models): Dimensions Inches øA 11.25 2.25 1.91... - Page 12 Raadpleeg een erkende elektricien als u vragen heeft over deze aardingsinstructies. Voordat u begint: Controleer eerst of dit snoer stevig aan uw CookTek-apparaat is bevestigd VOORDAT u de stekker van het toestel in het stopcontact steekt en u probeert het te gebruiken. • Raak de keramische plaat (of de bovenkant van de kooktop) nooit onmiddellijk na gebruik aan. De hitte van de pan wordt op de keramische plaat overgebrachtzodat...
- Page 13 • Ne pas toucher la plaque de céramique (ou la partie supérieure de l’appareil Cooktop) immédiatement après utilisation. La chaleur de la casserole se transmet à la plaque de céramique, aussi celle-ci est chaude au toucher. • L’entretien de cet appareil ne peut être effectué que par un réparateur agréé ou • par un membre du personnel de CookTek. Ne jamais essayer d’ouvrir l’appareil ni de le réparer. Pour des informations concernant l’entretien, contacter CookTek au +1 214-379-6000. • Cet appareil doit être raccordé à la terre. Le brancher exclusivement à une prise de courant correctement raccordée à la terre. Avant utilisation, lire les instructions de raccordement à la terre, ainsi que les exigences en matière d’installation électrique...
- Page 14 WARNHINWEIS: Ein nicht fachgemäß geerdeter Stecker kann zu einem Stromschlag führen. Falls Sie noch Fragen zu diesen Anweisungen in Zusammenhang mit Schutzkontakt und Erdung haben, wenden Sie sich bitte an einen Elektrofachmann. Bevor Sie beginnen: Dieses Netzkabel muss fest mit dem CookTek verbunden sein, BEVOR Sie das Gerät an die Steckdose anschließen und es in Betrieb nehmen. • Berühren Sie die Keramikplatte (oder Oberfläche des Cooktop) nicht unmittelbar nach Gebrauch. Die Hitze der Pfanne überträgt sich auf die Keramikplatte, die dann ebenfalls heiß wird.
- Page 15 ΠΡΟΕΙΔΟΠΟΙΗΣΗ: Ένα εσφαλμένα γειωμένο φις μπορεί να έχει ως αποτέλεσμα την ηλεκτροπληξία. Παρακαλείστε να συμβουλευτείτε αρμόδιο ηλεκτρολόγο εάν έχετε τυχόν ερωτήσεις σχετικά με αυτές τις οδηγίες γείωσης. Πριν ξεκινήσετε: Βεβαιωθείτε ότι αυτό το ηλεκτρικό καλώδιο είναι σταθερά συνδεδεμένο στη μονάδα CookTek σας ΠΡΙΝ συνδέσετε το φις της μονάδας σε ηλεκτρική πρίζα και πριν προσπαθήσετε να θέσετε τη μονάδα σε λειτουργία. • Μην αγγίξετε την κεραμική πλάκα (ή το άνω μέρος του Cooktop) αμέσως μετά τη χρήση. Η θερμότητα από την κοιλότητα θα μεταφερθεί στην κεραμική πλάκα. Ως εκ τούτου, αυτή θα είναι πολύ ζεστή για να την αγγίξετε. • Οι εργασίες επισκευής του προϊόντος αυτού πρέπει να πραγματοποιούνται μόνο από εξουσιοδοτημένο αντιπρόσωπο επισκευών ή από προσωπικό της CookTek. Μην επιχειρήσετε να ανοίξετε τη μονάδα ή να εκτελέσετε οποιαδήποτε εργασία...
- Page 16 Ta kontakt med en kvalifisert elektriker dersom du har spørsmål om disse jordingsinstruksene. Før du begynner: Kontroller at strømkabelen er satt helt inn i CookTek-enheten FØR du kopler enheten til stikkontakten og før bruk. • Den keramiske platen (eller overflaten på komfyren) må ikke berøres umiddelbart etter bruk. Varme fra kjeler vil overføres til den keramiske platen og gjøre den varm. • Dette produktet kan bare repareres av en autorisert serviceagent eller av CookTek- ansatte. Ikke prøv å åpne enheten eller utføre reparasjoner av noe slag. For serviceinformasjon, kontakt CookTek på tlf. +1 214-379-6000. • Dette produktet må jordes. Må kun koples til et korrekt jordet støpsel. Før bruk bør du lese jordingsinstruksene og kravene til elektrisk installasjon på side 2 i denne veiledningen. Ikke bruk skjøteledning. POLISH Przed rozpoczęciem używania urządzenia Cooktop, należy wykonać poniższe...
- Page 17 Przed rozpoczęciem używania: Należy sprawdzić, czy przewód zasilania jest pewnie przymocowany do modułu CookTek PRZED podłączeniem urządzenia do gniazdka zasilania i przed rozpoczęciem jego używania. • Nie dotykać płyty ceramicznej (lub wierzchniej części urządzenia Cooktop bezpośrednio po zakończeniu jego używania. Wysoka temperatura patelni może przenosić się na płytę ceramiczną, stwarzając możliwość oparzenia w przypadku jej dotknięcia. • Obsługa serwisowa tego produktu może być prowadzona jedynie przez upoważnionego pracownika serwisu lub przez personel firmy CookTek. Nie podejmować samodzielnej próby otwarcia urządzenia ani nie wykonywać żadnych napraw. Aby uzyskać informacje dotyczące obsługi serwisowej, należy skontaktować się z firmą CookTek pod numerem +1 214-379-6000. • Niniejsze urządzenie wymaga uziemienia. Podłączać jedynie do właściwie uziemionego gniazda. Przed użyciem należy przeczytać instrukcję dotyczącą uziemienia oraz część „Wymogi instalacji elektrycznej” na stronie 2 niniejszej ulotki. Nie używać przedłużacza. PORTUGUESE Antes de funcionar com o seu Cooktop, faça o seguinte: • Retire todo o material de embalagem.
- Page 18 Si tiene alguna duda relacionada con las instrucciones de conexión a tierra, póngase en contacto con un electricista cualificado. Antes de comenzar: Asegúrese de que el cable eléctrico está unido firmemente a la unidad CookTek ANTES de conectar la unidad a la electricidad y antes de intentar utilizarla. • No toque la placa cerámica (situada en la parte superior del anafe) inmediatamente después de utilizarla. El calor de la cazuela se transferirá a la placa cerámica y hará...
- Page 19 CookTek Induction Systems, LLC Phone: 1-800-908-8726 +1 214-379-6000 Fax: +1 214-379-6073 www.cooktek.com customerservice@turbochef.com...
