CARE and MAINTENANCE

Clean the tank:

●

The stainless steel tank, rubber tubing and valves may be damaged by corro-

sive cleaning liquids. Always clean the tank with plain water after usage. Do

not allow cleaning liquids to stagnate in the rubber tubing and tank.

Replace water seal and rubber tubing:

●

The rubber tubing inside the tank should be checked for leaks or damages..

●

The water seal rubber at the drain filter and the rubber tubing inside the ma-

chine should be replaced every 3 years or when damage to the tube or seal is

suspected.

Allow system to rest:

●

Do not continually use the system at high power mode for prolonged periods.

Allow system to take 10 to 15 minutes breaks between high intensity cleaning

procedure. If system is working at high power mode for more than an hour.

Allow 15 minutes of rest for each hour.

●

The system may detect an overheat and cut off power to the ultrasonic sys-

tem. If an over heat is detected, cut off power to the system and let system

cool to room temperature before reactivating system for use.

Heating Elements:

●

Heating elements have a limited working cycle. Replacement of heating ele-

ments are needed if heating efficiency has deteriorated.

Manufacturer:

AOYUE TONGYI ELECTRONIC EQUIPMENT FACTORY

Jishui Industrial Zone, Nantou, Zhongshan City,

Guangdong Province, P.R.China

http://www.aoyue.com

AOYUE

9070

ULTRASONIC CLEANER

INSTRUCTION MANUAL

Thank you for purchasing the Aoyue 9070 Ultrasonic Cleaner.

It is important to read the manual before using the equipment.

Please keep manual in accessible place for future reference.

Table of Contents

Need help?

Do you have a question about the 9070 and is the answer not in the manual?

Questions and answers

Summary of Contents for aoyue 9070

Page 1: Care And Maintenance
Heating elements have a limited working cycle. Replacement of heating ele- ments are needed if heating efficiency has deteriorated. Thank you for purchasing the Aoyue 9070 Ultrasonic Cleaner. It is important to read the manual before using the equipment. Please keep manual in accessible place for future reference.
Page 2: Table Of Contents
OPERATING GUIDELINES This manual is designed to familiarize and instruct the op- erator with the proper usage and maintenance of the Press the switch button to program segment “C”. ● equipment. The “Care and Safety Precautions” section explains the hazards of using any type of soldering or re- We set the power level of segment “C”...
Page 3: Product Description
OPERATING GUIDELINES PRODUCT DESCRIPTION The Aoyue 9070 is an advanced high power ultrasonic cleaning Default profile of Mode 8: system which incorporates the latest technologies to allow efficient and Segment effective cleaning in the shortest amount of time. Power Level...
Page 4: Specifications
SPECIFICATION OPERATING GUIDELINES To save the programmed cleaning profile, repeatedly press the ● Power Input : available in 110V / 220V switch button until the display shows the word “SAVE”. Press the start button to save the newly programmed profile into memory. Station Dimensions: 350(w) x 265(h) x325(d) mm The display will jump to displaying segment “A”...
Page 5: Safety Precautions
OPERATING GUIDELINES SAFETY PRECAUTIONS Place items to be cleaned into the tank with the cleaning liquid. ● Improper usage can cause serious injury to personnel CAUTION: Repeatedly press the mode selection button to reach the desired and/or damage to equipment. For your own safety, please observe ●...
Page 6: Safety Precautions
OPERATING GUIDELINES SAFETY PRECAUTIONS Start the cleaning process by pressing the Start button (“8”). ● Never leave equipment running unattended. ● ● If the heating function is enabled the system would start heating Never use volatile/highly reactive solvents, including flammable ●...
Page 7: Control Panel Guide
OPERATING GUIDELINES CONTROL PANEL GUIDE E. MODE FUNCTIONS 1. Modes 1 and 2: High/Low power operating modes. Mode 1 allows temperature heat up with continuous high power cleaning. While mode Front View 2 allows temperature heat up with continuous low power cleaning. Place items to be cleaned into the tank with the cleaning liquid.
Page 8: Operating Guidelines
OPERATING GUIDELINES OPERATING GUIDELINES 5. To start the heating process simply press the Start button (button IMPORTANT REMINDERS: “8”). 1. Make sure the equipment is placed on a flat stable surface . 6. The system would start heating up and engage the ultrasonic 2.
