Summary of Contents for Nilox DAS-1410
-
Page 2: Table Of Contents
WARNING ...................................... 4 Quick Start Guide ..................................7 Product Overview ..................................7 System Requirements ................................7 Package Contents ..................................7 Factory Default Settings ................................7 Cabling ....................................... 8 Browser Configuration ................................8 PPPoE/PPPoA .................................... 9 DEVICE INFO ....................................10 Summary ....................................10 Wan ...................................... - Page 3 Parental Control(URL Filter) ............................41 Quality of Service ................................... 42 Routing ......................................44 DNS(DNS Server) ................................. 46 DNS(Dynamic DNS) ................................46 DSL ........................................ 47 UpnP ......................................47 DNS Proxy ....................................48 Print Server ....................................48 Packet Acceleration ................................48 Storage Service ..................................48 Interface Grouping ................................
- Page 4 APPENDIX A: Connect to a network using Windows client ................77 Windows 8 ....................................77 Windows 7 ....................................77 Windows VISTA ..................................77 Windows XP ..................................... 77 APPENDIX B: IP Address in DHCP Client Mode ...................... 78 Windows 7/8 ..................................... 78 Windows Vista ..................................
-
Page 5: Warning
Corp. Pentium is trademark of Intel. All copyright ® reserved. The Nilox logo is a registered trademark. All other names mentioned may be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for technical errors and/or omissions. Safety Precautions... -
Page 6: Environmental Information
(WEEE). For further and more detailed information, we invite you to visit our website at www.nilox.com WARRANTY INFORMATIONS One year, if it is invoiced to an industry or to a professional worker (subjected to VAT number). - Page 7 WEEE BIN Logo ( ),in some devices, isn’t fully compliant with minimum dimensions requirement to European Directive due to limited sticker area. Nilox suggests to visit the web site www.nilox.com in order to retrieve update manual, tech details and driver.
-
Page 8: Quick Start Guide
UICK TART UIDE Thank you for purchasing Nilox Wireless N ADSL2+ Router that provides the easiest way to wireless networking. This document describes how to install your Nilox Router. Please keep this User Guide for future reference. RODUCT VERVIEW ADSL2+ Built-In modem for high-speed Internet Access (up to 24Mbps) ... -
Page 9: Cabling
192.168.1.1, and click Go to get the login page. The default username is admin, password is nilox and click “OK” to continue. With the following steps you can make Wireless Router ADSL2+ operate in short time using PCs in DHCP mode. Refer to the manual in the Installation CD if... -
Page 10: Pppoe/Pppoa
In order to verify the WAN Status, please click Device Info->WAN. Pay attention to the WAN-ADSL connection. If you have any doubt turn to qualified personnel or contact Nilox technical assistance. Nilox will not be considered responsible in case of wrong or bad configuration. -
Page 11: Device Info
DEVICE INFO This chapter describes how to use Web-based management of the DSL router, which allows you to configure and control all DSL router features and system parameters in an user-friendly GUI. Choose Device Info, and the submenus of Device Info are shown as below: UMMARY Choose Device Info >... -
Page 12: Wan
This page displays the device information such as the board ID, software version, and the information of your WAN connection such as the upstream rate and the LAN address. Choose Device Info > WAN and the following page appears. This page displays the information of the WAN interface, such as the connection status, and the IP address. TATISTICS Choose Device Info >... - Page 13 Choose Device Info > STATISTICS > xTM and the following page appears. In this page, you can view the statistical information about the received and transmitted data packets at the xTM interfaces. Click the Reset button to restore the values to zero and recount them.
- Page 14 Choose Device Info > STATISTICS > xDSL and the following page appears. In this page, you can view the statistical information about the received and transmitted data packets of the xDSL interfaces. Click xDSL BER Test to test the xDSL Bit Error Rate. Click Reset Statistics to restore the values to zero and recount them.
-
Page 15: Route
NOTE!: Click xDSL BER Test to perform a bit error rate (BER) test on the DSL line. The Tested Time (sec) can be 1, 5, 10, 20, 60, 120, 180, 240, 300, or 360. Select a time in the drop-down list and click Start. If the BER reaches e-5, you cannot access Internet. -
Page 16: Dhcp
Choose Device Info > DHCP and the following page appears. In this page, you can view the host name, the IP address assigned by the DHCP server, the MAC address corresponding to the IP address, and the DHCP lease time. -
Page 17: Quick Setup
QUICK SETUP Check previous chapter. ADVANCED SETUP Choose Advanced Setup and the submenus of Advanced Setup are shown as below:... -
Page 18: Layer2 Interface
NTERFACE Choose Advanced Setup > Layer2 Interface > ATM Interface . In this page, you can add or remove to configure DSL ATM Interfaces. Click Add to add ATM Interface and the following page appears. In this page, you can enter this PVC (VPI and VCI) value, and select DSL link type (EoA is for PPPoE, IPoE, and Bridge.), encapsulation mode, service category. - Page 19 Click Apply/Save to save the configuration, and return the following page: If you want to remove this Interface, please select the Remove check box and click Remove.
-
Page 20: Wan Service
WAN S ERVICE Choose Advanced Setup > WAN Service, and the following page appears. In this page, you are allowed to add, remove, or edit a WAN service. WAN S (PPP ERVICE This section describes the steps for adding the PPPoE WAN service. ... - Page 21 Step 2 In this page, you can select a ATM Interface for the WAN service. After selecting the ATM interface, click Next to display the following page. Step 3 In this page, select the WAN service type to be PPP over Ethernet (PPPoE). Click Next to display the following page.
- Page 22 Step4 In this page, you can modify the PPP username, PPP password, PPPoE service name and authentication method. PPP Username: The correct user name provided by your ISP. PPP Password: The correct password provided by your ISP. ...
- Page 23 Step5 After setting the parameters, click Next to display the following page. Step6 In this page, select a preferred WAN interface as the system default gateway and then click Next to display the following page. Step7 In this page, you can obtain the DNS server addresses from the selected WAN interface. Click Next, and the following page appears.
-
Page 24: Wan Service(Pppoa)
WAN S (PPP ERVICE This section describes the steps for adding the PPPoA WAN service. Step0 Choose Advanced Setup > Layer2 Interface > ATM Interface . In this page, you can add or remove to configure DSL ATM Interfaces. Click Add to add ATM Interface and the following page appears. DSL Link Type: PPPoA and select the encapsulation mode to be VC/MUX (according to the uplink equipment). - Page 25 Step4 In this page, you can modify the PPP username, PPP password, PPPoA service name and authentication method. PPP Username: The correct user name provided by your ISP. PPP Password: The correct password provided by your ISP. ...
- Page 26 Step5 After setting the parameters, click Next to display the following page. Step6 In this page, select a preferred WAN interface as system default gateway and then click Next to display the following page. Step7 In this page, you can obtain the DNS server addresses from the selected WAN interface. Click Next, and the following page appears.
-
Page 27: Wan Service(Ipoa)
WAN S ERVICE This section describes the steps for adding the IPoA WAN service. Step0 Choose Advanced Setup > Layer2 Interface > ATM Interface . In this page, you can add or remove to configure DSL ATM Interfaces. Click Add to add ATM Interface and the following page appears. DSL Link Type: IPoA and select the encapsulation mode to be LLC/SNAP-Routing (according to the uplink equipment). - Page 28 Step4 In this page, enter the WAN IP address, the WAN subnet mask, and primary DNS server provided by your ISP and then click Next to display the following page. Step5 After setting the parameters, click Next to display the following page. In this page, Network Address Translation (NAT) allows you to share one Wide Area Network (WAN) IP address for multiple computers on your Local Area Network (LAN).
- Page 29 Step8 In this page, it displays the information about the IPoA settings. Click Apply/Save to save and apply the settings.
-
Page 30: Wan Service
3G WAN S ERVICE Choose Advanced Setup > 3G WAN Service , and the following page appears. This page is used to configure 3G connection. If you want to access Internet through 3G connection, a 3G network card is required. Connect the 3G network card to the USB interface of the Router. ... - Page 31 APN: APN (Access Point Name) is used to identify the service type. Enter the APN provided by your 3G ISP. Dial Number: Enter the dial number provided by your 3G ISP. Idle time (in sec.): If no traffic for the preset time, the 3G will disconnect automatically. ...
-
Page 32: Lan
Choose Advanced Setup > LAN, and the following page appears. In this page, you can configure an IP address for the DSL router, enable IGMP snooping, enable or disable the DHCP server, edit the DHCP option, configure the DHCP advanced setup and set the binding between a MAC address and an IP address. ... - Page 33 Configuring the DHCP Static IP Lease List: The lease list of static IP address can reserve the static IP addresses for the hosts with the specific MAC addresses. When a host whose MAC address is in the lease list of static IP address requests the DHCP server for an IP address, the DHCP server assigns the reserved IP address to the host.
-
Page 34: Lan (Ipv6 Auto-Configuration)
LAN (IP CONFIGURATION Click Advanced Setup > LAN >IPv6 Autoconfig, and the following page appears. In this page, you can set an IP address for the DSL IPv6 router, enable the DHCPv6 server, enable RADVD and enable the MLD snooping function. ... -
Page 35: Nat(Virtual Servers)
NAT(V IRTUAL ERVERS Firewall can prevent unexpected traffic on the Internet from your host on the LAN. The virtual server can create a channel that can pass through the firewall. In that case, the host on the Internet can communicate with a host on your LAN within certain port range. -
Page 36: Nat(Port Triggering)
NAT(P RIGGERING Some applications need some ports to be opened in the firewall for the remote access. When an application initializes a TCP/UDP to connect to a remote user, port triggering dynamically opens the open ports of the firewall. Choose Advanced Setup > NAT > Port triggering, and the following page appears. In this page, you are allowed to add or remove any entry of port triggering. -
Page 37: Nat(Dmz Host)
NAT(DMZ H DMZ Host DMZ allows all the ports of a PC on your LAN to be exposed to the Internet. Set the IP address of the PC to be DMZ host, so that the DMZ host will not be blocked by firewall. Choose Advanced Setup >... -
Page 38: Security(Firewall)
ECURITY IREWALL Choose Security > Firewall and the following page appears. Click Modify Firewall or Remove Firewall to modify or remove the firewall. And click Modify Rule or Remove Rule to modify or remove the rule. Click Add Firewall, and the following page appears. ... - Page 39 In this page, you can add or remove the MAC filtering rule. You may change the MAC filtering policy from FORWARDED to BLOCKED by clicking the Change Policy button. Click the Add button to display the following page.
- Page 40 Protocol Type: Select the proper protocol type. Destination MAC Address: Enter the destination MAC address. Source MAC Address: Enter the source MAC address. Frame Direction: The direction of transmission frame. WAN Interface (Configured in bridge mode only): Select the proper WAN interface in the drop-down list. After finishing setting, click Apply/Save to save and apply the filtering rule.
-
Page 41: Parental Control(Time Restriction)
ARENTAL ONTROL IME RESTRICTION Choose Advanced Setup > Parental Control > Time Restriction, and the following page appears. Click the Add button to display the following page. This page is used to control the time restriction to a special LAN device that connects to the DSL router. In this page, save the user name and configure the time settings. -
Page 42: Parental Control(Url Filter)
(URL F ARENTAL ONTROL ILTER Choose Advanced Setup > Parental Control > URL Filter, and the following page appears. This page is used to prevent the LAN users from accessing some Websites in the WAN. In this page, you may select the Exclude URL list type or the Include URL list type. If you select the Exclude URL list type, it means that the URLs in the list are not accessible. -
Page 43: Quality Of Service
UALITY OF ERVICE Choose Advance Setup > Quality of Service and the following page appears. Select Enable QoS to enable QoS and configure the default DSCP mark. In this page, enable the QoS function and select the default DSCP mark. After finishing setting, click Apply/Save to save and apply the settings. - Page 44 Name: Enter the name of QoS queue. Enable: Enable or disable the QoS queue. Interface: Select the proper interface for the QoS queue. After finishing setting, click Apply/Save to save and apply the settings. Choose Advanced Setup > Quality of Service > QoS Classification, and the following page appears. In this page, you can enable, add or remove a QoS classification rule.
-
Page 45: Routing
OUTING Choose Advanced Setup > Routing > Default Gateway and the following page appears. In this page, you can modify the default gateway settings. Select a proper WAN interface in the drop-down list of Selected WAN Interface as the system default gateway. After finishing setting, click Apply/Save to save and apply the settings. - Page 46 Choose Advanced Setup > Routing > Policy Routing and the following page appears. In this page, you can add or remove a static policy rule. Click the Add button to display the following page. In this page, enter the policy name, source IP and default gateway, and select the physical LAN port and interface. After finishing setting, click Apply/Save to save and apply the settings.
-
Page 47: Dns(Dns Server)
DNS(DNS S ERVER Choose Advanced Setup > DNS > DNS Server and the following page appears. In this page, you can select a DNS server interface from the available interfaces, manually enter the DNS server addresses, or obtain the DNS address from a WAN interface. After finishing setting, click Apply/Save to save and apply the settings. -
Page 48: Dsl
Password: Enter the password for accessing the DDNS management interface. After finishing setting, click Apply/Save to save and apply the settings. Choose Advanced Setup > DSL and the following page appears. In this page, you can view the DSL settings. Usually, you can keep this factory default setting. -
Page 49: Dns Proxy
DNS P ROXY Choose Advanced Setup > DNS Proxy and the following page appears. In this page, you can enable or disable the DNS proxy function. After enabling the DNS proxy function, enter the host name of the broadband router and the domain name of the LAN network, and then click Apply/Save to save and apply the settings. -
Page 50: Interface Grouping
NTERFACE ROUPING Choose Advanced Setup > Interface Grouping and the following page appears. Interface grouping supports multiple ports to PVC and bridging groups. Each group will perform as an independent network. To support this feature, you must create mapping groups with the appropriate LAN and WAN interfaces using the Add button. - Page 51 In this page, please follow the on-screen configuration steps to configure the parameters of the interface grouping. After finishing setting, click Apply/Save to save and apply the settings.
-
Page 52: Ip Tunnel
IP T UNNEL Choose Advanced Setup > IP Tunnel > IPv6inIPv4 and the following page appears. The default value is IPv6 in IPv4 information. Click Add and the following page appears. In this page, you can add a new tunnel. -
Page 53: Certificate
ERTIFICATE Choose Advanced Setup > Power Management and the following page appears. In this page, you can acquire the local certificate by creating a certificate request or importing a certificate. You may also create or remove a certificate. Creating a New Certificate Request Click the Create Certificate Request button to display the following page. - Page 54 The certificate request needs to be submitted to a certificate authority, which will sign the request. Then the signed certificate needs to be loaded to the DSL router. Click Load Signed Certificate in this page, and the following page appears. In this page, paste the signed certificate, and then click the Apply button.
- Page 55 Importing an Existing Local Certificate To import an existing certificate, click the Import Certificate button to display the following page. In this page, paste the certificate and the private key. Finally, click the Apply button to import the certificate.
- Page 56 Trusted CA Choose Advanced Setup > Certificate > Trusted CA and the following page appears. In this page, you may import or remove a CA certificate. Click the Import Certificate button to display the following page. In this page, enter the certificate name and paste the certificate content. Finally, click the Apply button to import the certificate.
-
Page 57: Power Management
OWER ANAGEMENT Choose Advanced Setup > Power Management and the following page appears. This page allows control of Hardware modules to evaluate power consumption. Use the control buttons to select the desired option. After proper configurations, click Apply to take the configurations effect. ULTICAST Choose Advanced Setup >... -
Page 58: Wireless
WIRELESS Choose Wireless and the submenus of Wireless are shown as below:... -
Page 59: Basic
ASIC Choose Wireless > Basic to display the following page. In this page, the figure in the right area is 2-dimensional code. It includes the wireless SSID and password. You can obtain the wireless SSID and password through scanning this figure. This page allows you to configure the basic features of the wireless LAN interface. - Page 60 Max Clients: Specify the maximum wireless client stations to be enabled to link with AP. Once the clients exceed the max value, all other clients are refused. The value of maximum clients is 16. Wireless - Guest/Virtual Access Points: If you want to make Guest/Virtual network function be available, you have to check those boxes in the table below.
-
Page 61: Security
ECURITY Choose Wireless > Security to display the following page. This page allows you to configure the security features of the wireless LAN interface. In this page, you can configure the network security settings by the Wi-Fi Protected Setup (WPS) method or setting the network authentication mode. WPS Setup There are 2 primary methods used in the Wi-Fi Protected Setup: ... - Page 62 – Enter STA PIN: If you select it, you need to enter the station PIN from client. – Use AP PIN: The PIN is generated by AP. Push button configuration (PBC), an actual push button on the hardware or through a simulated push button in the software.
- Page 63 802.11x Select SSID: Select a SSID for configuring the security settings. Network Authentication: Select the 802.1X in the drop-down list. RADIUS Server IP Address: Enter the IP address of the RADIUS server. RADIUS server is used to authenticate the hosts on the wireless network.
- Page 64 WPA Select SSID: Select a SSID for configuring the security settings. Network Authentication: Select the WPA-PSK mode. WPA Group Rekey Interval: Setting the interval for renewing key. RADIUS Server IP Address: Enter the IP address of the RADIUS server. RADIUS server is used to authenticate the hosts on the wireless network.
- Page 65 WPA2 Select SSID: Select a SSID for configuring the security settings. Network Authentication: Select the WPA2 mode. WPA2 Preauthentication: Enable or disable pre-authentication. Network Re-auth Interval: Set the network re-auth interval. WPA Group Rekey Interval: Setting the interval for renewing key. ...
- Page 66 NOTE!: The parameters’ description of Mixed WPA2/WPA mode, please refer to the WPA2 mode. NOTE!: The parameters’ description of Mixed WPA2/WPA-PSK mode, please refer to the WPA-PSK mode.
-
Page 67: Mac Filter
ILTER Choose Wireless > MAC Filter to display the following page. This page is used to allow or reject the wireless clients to access the wireless network of the wireless router. In this page, you can add or remove the MAC filters. The MAC restrict modes include Disabled, Allow, and Deny. -
Page 68: Wireless Bridge
IRELESS RIDGE Choose Wireless > Wireless Bridge to display the following page. This page allows you to configure the wireless bridge features of the wireless LAN interface. AP mode: you may select Access Point or Wireless Bridge. Bridge Restrict: Enable or disable the bridge restrict function. ... -
Page 69: Advanced Settings
DVANCED ETTINGS Choose Wireless > Advanced to display the following page. This page allows you to configure the advanced features of the wireless LAN interface. Usually, you do not need to change the settings in this page. Band: You can select 2.4GHz only. ... - Page 70 802.11n Rate: Select the transmission rate for the network. The rate of data transmission should be set depending on the speed of your wireless network. You can select from a range of transmission speeds, or you can select Auto to have the Router automatically use the fastest possible data rate and enable the Auto-Fallback feature.
-
Page 71: Station Info
Note: T HE ADVANCED WIRELESS SETTING IS ONLY FOR THE ADVANCED USER OR THE COMMON USER DO NOT CHANGE ANY SETTINGS IN THIS PAGE TATION Choose Wireless > Station Info to display the following page. This page shows the authenticated wireless stations and their status. -
Page 72: Diagnostics
DIAGNOSTICS Click Diagnostics > Diagnostics, and the following page appears. This page is used to test the connection to your local network, the connection to your DSL service provider, and the connection to your Internet service provider. You may diagnose the connection by clicking the Test button or the Test With OAM F4 button. If the test continues to fail, click Help and follow the troubleshooting procedures. -
Page 73: Management
MANAGEMENT Choose Management and the submenus of Management are shown as below: ETTINGS ACKUP Choose Management > Settings > Backup to display the following page. In this page, click the Backup Settings button to save your router’s settings to your local PC. ETTINGS PDATE Choose Management >... -
Page 74: System Log
YSTEM Choose Management > System Log to display the following page. In this page, you are allowed to configure the system log and view the security log. Click the View System Log button to display the following page. In this page, you can view the system log. Click the Refresh button to refresh the system log. -
Page 75: Snmp Agent
SNMP A GENT Choose Management > SNMP Agent, and the following page appears. Simple Network Management Protocol (SNMP) allows a management application to retrieve statistics and status from the SNMP agent in this device. In this page, you may enable or disable the SNMP agent and set the parameters such as the read community, system name and trap manager IP. -
Page 76: Access Control (Services)
In the page, you can modify the username and password of different users. After finishing setting, click the Apply/Save button to save and apply the settings. CCESS ONTROL ERVICES Choose Management > Access Control > Services Control and the following page appears. In this page, you can enable or disable the different types of services. -
Page 77: Reboot
If you want to upload the software, click the Sfoglia… button to choose the new software, and then click the Update Software button. Note: When software update is in progress, do not shut down the router. After software update completes, the router automatically reboots. -
Page 78: Windows 8
From Manage wireless connections dialog box From Connect/Disconnect context menu option of a wireless network adapter in the Network Connections folder Select Wireless (on the combo box) in the field Show, select the wireless network SSID (DAS-1410 or DAS-2420) and click Connect ... - Page 79 APPENDIX B: IP A DHCP C DDRESS IN LIENT INDOWS Go to Start / Control Panel (select Large/Small Icon). In the Control Panel, double-click on Network and Sharing Center icon Click Change Adapter Settings then double-click Local Area Connection/Wireless and click Properties ...
-
Page 80: Appendix C: Technical Specifications
APPENDIX C: TECHNICAL SPECIFICATIONS Code 16NXRW1430001 16NXRW14CQ001 Standards IEEE 802.11b/g/n WAN Interface (ADSL2+): RJ11 LAN Interface 4 x RJ45 10/100 Base-T Ethernet ports (auto MDI/MDI-X) Antenna 2*2 dBi internal striped antennas 1*2 dBi internal striped antenna 10 Diagnostic LED BUTTON Reset, WPS, WLAN (On/OFF) and Power Switch USB Interface USB 2.0... - Page 81 DNS, DNS relay and IGMP proxy DHCP server , DHCP client, SNTP Certifications CE (Europe) Dimensions(mm)/ Weight 145 x 115 x 32/ 220g Temperature Range Operation: 0°C ~ 32°C Storage: -10°C ~ 60°C Humidity 10% ~ 75% (non Condensing) Power Consumption: 12 DC@0.8A (Max 5.1W) System Requirements...
