Libtor Technology T270-A1 User Manual

T270 series
Hide thumbs

Advertisement

Quick Links

Download this manual
T260Sseries Router
user manual
T270 series router user
The manual is suitable for the following model :
Model
T270-A1
T270-B1
T270-DE1
T270-DE2
Shenzhen Libtor Technology Co.,Ltd
Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street
Office, Longgang District, Shenzhen City, Guangdong Province.
Web:http:www.libtor.com Tel: 86-755-28345166-807 Fax:86-755-28345166-804
Mail:lemon@szlbt.net
Product Version
V1.5
Product name: T270
manual
Product type
WCDMA/HSDPA/HSUPA/HSPA+/GSM/
GPRS/EDGE router
CDMA/EVDO router
TD-LTE/FDD-LTE/WCDMA
/TD-SCDMA/GSM/GPRS/EDGE router
TD-LTE/FDD-LTE/WCDMA
/TD-
SCDMA/WVD0/CDMA20001X/GSM
router
T260 Series Router User Manual
Page
Total:41
Page 1 of 41

Advertisement

loading
Need help?

Need help?

Do you have a question about the T270-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Libtor Technology T270-A1

  • Page 1 CDMA/EVDO router TD-LTE/FDD-LTE/WCDMA T270-DE1 /TD-SCDMA/GSM/GPRS/EDGE router TD-LTE/FDD-LTE/WCDMA /TD- T270-DE2 SCDMA/WVD0/CDMA20001X/GSM router Shenzhen Libtor Technology Co.,Ltd Page 1 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province. Web:http:www.libtor.com Tel: 86-755-28345166-807 Fax:86-755-28345166-804 Mail:lemon@szlbt.net...
  • Page 2 T260 Series Router User Manual Copyright owned and kept by Shenzhen Libtor Technology Co,Ltd (2008-2014). Any Company and Individual mustn’t use and copy the part and complete content and broadcast in any form without permission from company. Trade mark declaration Libtor and Other Libtor trademarks are owned and controlled by Shenzhen LIBTOR Technology Co.ltd...

  • Page 3: Chapter 1: Product Specification

    . Supporting Web configuration, easy management and remote message control . 1.1 Product description Shenzhen Libtor Technology Co.,Ltd Page 3 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 4 T260 Series Router User Manual 1.2 Connector description Shenzhen Libtor Technology Co.,Ltd Page 4 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province. Web:http:www.libtor.com Tel: 86-755-28345166-807 Fax:86-755-28345166-804 Mail:lemon@szlbt.net...
  • Page 5 Connection successful Connection light Internet light Flash (LINK) Normal connection slowly Shenzhen Libtor Technology Co.,Ltd Page 5 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province. Web:http:www.libtor.com Tel: 86-755-28345166-807 Fax:86-755-28345166-804 Mail:lemon@szlbt.net...
  • Page 6 .Power supply voltage ranged from 5to 35 voltage .We suggest using 12 voltage to supply power. The power suppy should be equal or larger than 10 W. Antenna connector Shenzhen Libtor Technology Co.,Ltd Page 6 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.

  • Page 7: Chapter 2 Setting Preparation

    Pls use Ping order to confirm if the computer connect with router or not when your computer monitor successfully connected with IP. For example :Proceed Ping order under Windows XP environment :Ping192.168.10.1 Shenzhen Libtor Technology Co.,Ltd Page 7 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 8 2.2.2enter Web setting Enter web setting when you successfully login , Then you can set and management router . Shenzhen Libtor Technology Co.,Ltd Page 8 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 9 2: Enter Web stteing -Status- Shared file , then it can check current storage information . Shenzhen Libtor Technology Co.,Ltd Page 9 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 10 4.Access to T270 storage medium by mobile phone, you can use the function of ES files browser and other tools, setting methods as below: (1) Open ES file browser Shenzhen Libtor Technology Co.,Ltd Page 10 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 11 T260 Series Router User Manual (2) Click the menu on the top-left, Choose FTP Shenzhen Libtor Technology Co.,Ltd Page 11 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province. Web:http:www.libtor.com Tel: 86-755-28345166-807 Fax:86-755-28345166-804...
  • Page 12 T260 Series Router User Manual (3)Click 192.168.10.1 in the server under pop-up web setting ,the user name and password are admin,Click “confirm” Shenzhen Libtor Technology Co.,Ltd Page 12 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 13 T260 Series Router User Manual (4)It can access to T270 storage medium,here, We can add, delete,modify the content of storage card . Shenzhen Libtor Technology Co.,Ltd Page 13 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 14 T260 Series Router User Manual Shenzhen Libtor Technology Co.,Ltd Page 14 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province. Web:http:www.libtor.com Tel: 86-755-28345166-807 Fax:86-755-28345166-804 Mail:lemon@szlbt.net...

  • Page 15: Chapter 3 Working Mode

    Wireless AP+wireless customer end bridge mode ,wireless AP+Wireless customer end mode 3.1, 3Gwireless router mode Shenzhen Libtor Technology Co.,Ltd Page 15 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 16 Null In this mode, 2 RJ45 router connectors are LAN port 3.2 Wire connection standard router mode Shenzhen Libtor Technology Co.,Ltd Page 16 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 17 Entering working mode to choose standard router mode, Choose the dynamic IP address under WAN setting windows. Click apply button ,then the router will obtain ISP assigned parameter automatically . Shenzhen Libtor Technology Co.,Ltd Page 17 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 18 Choose this mode ,we can use T270 as a bridge connection for AP using, it’s used as bridge connection of former grade wireless router . Shenzhen Libtor Technology Co.,Ltd Page 18 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 19 LAN2 connector, enter Web ,Choose wireless AP+ Customber end bridge mode . 2.Click LAN setting button, Search for Wireless network, Shenzhen Libtor Technology Co.,Ltd Page 19 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 20 AP accordingly 4. Fill wireless AP password chose, then you can bridge connection former Wireless AP Shenzhen Libtor Technology Co.,Ltd Page 20 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 21 Then press apply button. Web –wireless setting - choose Channel accordingly in wireless channel . Shenzhen Libtor Technology Co.,Ltd Page 21 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 22 WPAPSKWPA2PSK(WPA-PSK and WPA2-PSK mixed mode ) 4.1.1 Open system There are two types of encryption :None and WEP Shenzhen Libtor Technology Co.,Ltd Page 22 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 23 128bit encryption：26 unit sexadecimal or 13 unit character type. 4.1.2 WPA This safe mode offer WPA-PSK encryption and Raduis server certification Shenzhen Libtor Technology Co.,Ltd Page 23 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 24 Key update Set key interval updating time . the unit is as per interval second. Shenzhen Libtor Technology Co.,Ltd Page 24 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 25 Set key interval updating time . the unit is as per interval second. 4.1.5 WPAPSKWPA2PSK Shenzhen Libtor Technology Co.,Ltd Page 25 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 26 T270 can be used as a Internet server, offer many service function, Only need to fill right IP address of external connector,internal connector and internal server . then it can be used as virtual service Shenzhen Libtor Technology Co.,Ltd Page 26 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 27 5.2 Serial Port One main functions of T270 is used as serial port server (customer end), Here, we can connect many serial ports. Shenzhen Libtor Technology Co.,Ltd Page 27 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 28 We can send SMS to T270 router and control the start,close and restart by setting telephone number if T260S have 3G SIM card for sending and receiving messages.The details listed below : Shenzhen Libtor Technology Co.,Ltd Page 28 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 29 Regarding to there are many contents of many Ad certification, We don’t make description in details. If you want to konw more .Pls contact related person from our company. Shenzhen Libtor Technology Co.,Ltd Page 29 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 30 (1): Store the updating files to your computer. (2): Click “scan”button to choose the software your need to upgrade. (3):Click “upgrading” button, and start to upgrade. Shenzhen Libtor Technology Co.,Ltd Page 30 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 31 (1) fill the original password in the <original password> radio box;Fill the new password in the <new password> text box, Refill the new password in the <confirm Shenzhen Libtor Technology Co.,Ltd Page 31 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 32 The assigned IP from China mobile communication and China unicom are inside network IP. External network can’t access to, So it can’t be used as server. Shenzhen Libtor Technology Co.,Ltd Page 32 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 33 2. Use another computer (Server B), Link T260S with Internet line or WIFI, Open web setting of Wirless router (192.168.10.1), Open “system service”, Choose “serial serive” to set Shenzhen Libtor Technology Co.,Ltd Page 33 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 34 WEB setting screen, modify parameter of serial service for router. Make server’s IP address accordded with ports one by one . Shenzhen Libtor Technology Co.,Ltd Page 34 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 35 4.Open super terminal by using A computer,Choose COM1 connection, Pay attention to making Baud and so on parameters same with web setting of router . Shenzhen Libtor Technology Co.,Ltd Page 35 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 36 T260 Series Router User Manual 5.Now , It can data transparent transmission bettween A and B Shenzhen Libtor Technology Co.,Ltd Page 36 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 37 2. Enter T260S user managment screen -3G/4G Setting -DDNS,fill in DDNS account information ,make sure the account could be registered successfully. 3.Enter system service -serial port service , Start T260S’s server function Shenzhen Libtor Technology Co.,Ltd Page 37 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 38 China mobile telecom provide internal IP , We can’t use DDNS 5. Find a computer whatever you want, Ping szlbt.xicp.net, obtain T260S’s IP address. We can obtain IP address (113.113.105.150). Shenzhen Libtor Technology Co.,Ltd Page 38 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 39 7. T260S use serial port to connect a computer,open super customer end, then it can obain the data from customer end . Shenzhen Libtor Technology Co.,Ltd Page 39 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 40 3.B can be used as LAN port to connect C setting ways: Enter setting screen of Router B-system service- virtual service, set parameter as below: Shenzhen Libtor Technology Co.,Ltd Page 40 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
  • Page 41 Now ,we can connect Router A by Customer end U. Fill Http://192.168.1.55:1000 in address colum and press enter button , then Scaner will enter web setting screen of router C directly . Shenzhen Libtor Technology Co.,Ltd Page 41 of 41 Add:Room 608, Building A,Hongshengyuan Industrial Zone,No.339 Bulong Road, Bantian Street Office, Longgang District, Shenzhen City, Guangdong Province.
