Lynxx 63284 Owner's Manual

Lynxx 63284 Owner's Manual

40v lithium cordless blower

Advertisement

Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2016 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
REV 16g

Advertisement

loading
Need help?

Need help?

Do you have a question about the 63284 and is the answer not in the manual?

Questions and answers

Dilip m patel
February 12, 2025

Where buy 40v 2.5ah battery n.j Parsippany 07054

Summary of Contents for Lynxx 63284

  • Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
  • Page 2: Table Of Contents

    Follow instructions for lubricating and changing accessories. Keep handles dry, clean, and free from oil and grease. Page 2 For technical questions, please call 1-888-866-5797. Item 63284...
  • Page 3 Keep a but must be supplied by the operator. fire extinguisher and a smoke detector in the area. Frequently monitor the Charger and Battery Pack while charging. Item 63284 For technical questions, please call 1-888-866-5797. Page 3...
  • Page 4: Save These Instructions

    6. Remove or disconnect battery after use, contains important safety and operating before servicing, cleaning or removing instruction for battery charger Model 63284. material from the gardening appliance. 2. Before using battery charger, read all instructions 7. Do not dispose of battery in a fire. The and cautionary markings on battery charger, cell may explode.
  • Page 5 0 xxxx/min. damaged battery packs. No Load Revolutions per Minute (RPM) WARNING marking concerning Risk of Eye Injury. Wear ANSI-approved safety goggles with side shields. Item 63284 For technical questions, please call 1-888-866-5797. Page 5...
  • Page 6: Safety

    Functions Battery pack Release Buttons Battery pack Trigger Safety Turbo Speed Lock Button Trigger Variable Speed Dial Handle Blower Tube Page 6 For technical questions, please call 1-888-866-5797. Item 63284...
  • Page 7 • Three Solid Green Lights - 75% charge. • Two Solid Green Lights - 50% charge. • One Solid Green Light - 25% charge • One Blinking Green Light - Charge Battery. Item 63284 For technical questions, please call 1-888-866-5797. Page 7...
  • Page 8 Attaching Blower Tube 1. Slide Blower Tube over Blower Outlet, lining 2. Rotate Blower Tube clockwise to lock in place. upBlower Tube′s Slot over Blower Outlet′s Tab. Blower Blower Tube Outlet Slot Page 8 For technical questions, please call 1-888-866-5797. Item 63284...
  • Page 9 1. To install: Slide Battery Pack into slot on Release back of Blower until it clicks into place. Buttons 2. To remove: Press both Battery Pack Release Buttons and pull Battery Pack out of slot. Battery pack Item 63284 For technical questions, please call 1-888-866-5797. Page 9...
  • Page 10: Operation

    4. Press Turbo Speed button to increase air speed. Release button when done. Turbo Speed Trigger Button Safety Lock Trigger Variable Speed Dial Page 10 For technical questions, please call 1-888-866-5797. Item 63284...
  • Page 11: Maintenance

    3. All parts are permanently lubricated. Do not use additional lubrication. • cracked or broken parts, • damaged electrical wiring, and • any other condition that may affect its safe operation. Item 63284 For technical questions, please call 1-888-866-5797. Page 11...
  • Page 12 LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 12 For technical questions, please call 1-888-866-5797. Item 63284...
  • Page 13 Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Item 63284 For technical questions, please call 1-888-866-5797. Page 13...
  • Page 14: Parts List And Diagram

    Battery Contact Screw Battery Contact Plate Screw Switch Brushless Motor Micro Switch Upper Blower Tube Trigger Wind Cover Variable Speed Dial Blower Tube Screw Battery Pack Rear Cover Charger Controller Page 14 For technical questions, please call 1-888-866-5797. Item 63284...
  • Page 15 Assembly Diagram Item 63284 For technical questions, please call 1-888-866-5797. Page 15...
  • Page 16: Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
