SpaNet TK06B User Manual

Gps gsm gprs gps tracking system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1
GPS GSM GPRS GPS Tracking System

User Manual

Model: TK06B
Thank you for purchasing the tracker. This manual shows how to operate the device smoothly
and correctly. Make sure to read this manual carefully before using this product. Please note
that specification and information are subject to changes without prior notice in this manual.
Any change will be integrated in the latest release.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TK06B and is the answer not in the manual?

Questions and answers

Summary of Contents for SpaNet TK06B

  • Page 1: User Manual

    GPS GSM GPRS GPS Tracking System User Manual Model: TK06B Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual.

  • Page 2: Table Of Contents

    Contents ◆Quick using ....................... 3 ◆Installation attentions ..................3 1. Summary ......................4 2. Main functions ....................4 3.Specs........................4 4. Installation instructions ..................5 5. Wires connection .................... 6 6. Function setting ....................6 6.1 Initialization ....................6 6.2 Change Password ....................

  • Page 3: Quick Using

    ◆Quick using 1）Proper insert GSM SIM card, connect to power supply 12V/24V, Must turn on small switch inside SIM card hole. 2） Put device outside, around 45-90s three lights will keep lighting on stands for device can work normally. 3）Dialing device number, it will hang up and reply tracking message with valid Long and lat to show location.

  • Page 4: Summary

    1. Summary Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or GPRS. NOTE: Please turn on small switch inside SIM card hole after install SIM card 2. Main functions ·...

  • Page 5: Installation Instructions

    4. Installation instructions 4.1 Preparation: Choose SIM card, need insert a GSM SIM card into device. Please insert SIM card before turning the device power switch to on; The SIM card need open the GPRS function; Please make sure SIM card with full balance.

  • Page 6: Wires Connection

    make a call to device number. 5. Wires connection 1) Red wire connects to vehicle power anode 2) Black wire connects to vehicle power cathode 3) Yellow wire connects to oil or circuit control wires 4) Green wire connects to ACC ignition wire 6.

  • Page 7: Change Password

    and initialize all the settings to default factory settings.（default password: 123456） For example: send SMS “begin123456”, it will reply “BEGIN,CONFIG OK ”. The “+” in the command, please don’t type “+”, space means press the space keyboard on your cell phone. 6.2 Change Password 6.2.1 Send SMS “password+old password+space+new...

  • Page 8: Single Tracking

    All alarms will be received by central number. 6.4.1 Setup: send command “centernum+password+space+number” to tracker, it will reply “centernum ok”. After setup monitor center number, the messages of auto track by SMS will be set to this center number, if all alarms need to be sent to this number too, then this center number must be setup as authorized number.

  • Page 9: Data Logging (Optional)

    tracker first before using this function, if there is user name and password for GPRS login, Please refer to following to configure the APN, user name and password for GPRS login. 6.6.2 After configure the APN, send SMS “cell+password” to device, it will reply cell ID info.

  • Page 10: Overspeed Alarm

    district. The unit will send SMS to the central number when it detects alarm. Remark: 0 represents close alarm; 1 represents out fence alarm; 2 represents enter fence alarm. 6.8.2.1 Set Up: Send SMS“stockade+password+space+semi-diameter+space+alarm type” to unit to set the restricted district. In case of breach, it will send SMS “stockade!+geo-info”...

  • Page 11: Vibration Alarm

    reply "ACC,CONFIG OK". And tracker will send "ACC on+latitude & longitude" to central number when detect ignition action, that means the vehicle has been started. 2) Send "ACC+password+Space+0" to disabled this function, tracker will reply "ACC,CONFIG OK". 6.8.5 Vibration alarm 1) Send SMS “vibrate+password+space+0”...

  • Page 12: Imei Checking

    will reply following SMS: imei: unique IMEI number for register in tracking platform. apn: APN info. Of SIM card. IP: server IP and Port number. Cnum: central number for receive alarms. GPS: 1 means GPS working, 0 means searching signal, -1 means GPS sleep for lower power consumption purpose.

  • Page 13: Gprs Setting

    For example: Send SMS “timezone123456 330”, +5.5 is India time zone, so it is 5.5*60=330; If your country time zone is minus -6, send SMS “time zone123456 -360”. 6.15 GPRS Setting User must send SMS via cell phone to set up APN, IP and port before starting tracking by GPRS on tracking system.

  • Page 14: Faults & The Solutions

    7 . Faults & the Solutions Faults Solution Its failed to read SIM card, need re-install SIM card; after inserting yellow light flashing SIM card, then turn on power GPS not located, check if working outside not in room; install blue light flashing place has no metal cover Lights will enter sleep after stable lighting on 5 minutes and not...
