Summary of Contents for MIG MIG-630CS2
- Page 1 Full HD Digital & Analog Signal Mixed Video Switcher User Manual V1.1 △ Before using this Mixed Video Switcher, please read this manual carefully and preserve for future reference. MAGNIMAGE MIG-630C series...
- Page 2 Statements Without the written permission, any unit or individual could not copy, reproduction or translate the book or part of it. Also could not transmit it in any form or any way（electronic, mechanical, photocopying, record or other way) for any business and profitable purpose.
-
Page 3: Table Of Contents
Contents BRIEFS · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1 ·... - Page 4 WARRANTY EXPLANATION · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 33 ·...
-
Page 5: Briefs
Briefs Thanks for your purchasing our full HD Digital & Analog mixed signal video switcher. Do hope you can enjoy the experience of the product performance. The design of the LED video processor conforms to international and industry standards. But if with improper operation, there will be a personal injury and property damage. - Page 6 available for overlying, cutout synthesis function, and can easily achieve caption overlying and image synthesis effects internal multi image layer handling， and available for 3 image output at a time at most available for storage and invoking of multi-templates ...
-
Page 7: Using Directions
Using directions Included Accessories Using manual Power line CVBS cable DVI signal cable 5BNC-VGA USB Cable switching line Compact Disk Certificate of Quality... -
Page 8: Port Expansion
Port Expansion Name Corresponding Explanation product model MIG-630CS1 External one channel SDI input One external expandable SDI input MIG-630CS2 External two channel SDI input Two external expandable SDI inputs MIG-630CD External one channel DVI input One external expandable DVI input... -
Page 9: Safety Tips
Safety Tips This product power supply input voltage range is from 110~240VAC, 50/60Hz, please use the correct power. Please make sure that all power cables are unplugged when connecting or disconnecting any signal lines or control lines. Make sure that all signal and power cables are unplugged when adding ... -
Page 10: Features
Features Overview MIG-630C series is the video switcher developed especially for display systems. It adopts industry-leading image processing chip with 12 internal digital processing, making images clearer and colors richer. Its advanced interlace moving image adaptive processing technology ... - Page 11 Multi-layer processing technology is set in the product which can open three screens at the same time, and support 1 channel Logo input and black input. The product supports graphics overlay and matting function, facilitating the achievement of a subtitle overlay and image synthesis. The product’s man-machine interface is friendly which is easy and fast ...
-
Page 14: Technical Specifications
Technical Specifications Input Index Resolution Specifications Port Channel(s) PAL/NTSC VESA Standard VESA Standard （Support 1080i Input） Extendable Port 480i，576i，720p，1080i/p(3G SDI) Extendable Port SDI or DP Port Extendable Output Index Resolution Specifications Port Channel(s) 1024×768/60Hz 1280×1024/60Hz 1440×900/60Hz 1600×1200/60Hz 1920×1080/60Hz/50Hz 1920×1200/60Hz Machine Specification Input Power 110～240VAC，50/60Hz Machine Power... -
Page 15: Usage Menu
Usage Menu MIG-630C series uses a highlight high contrast LCD to display the user menu. Under the conditions of user not having the operation or the operation timed out, the LCD screen will display the non-menu state. If you use the buttons on the front panel to set the machine, LCD screen will display the appropriate menu according to user’s operation, prompting users to operate better,... -
Page 16: Non-Menu State Introduction
Non-Menu State introduction After opening the power of the MIG – 630C series, and during the system’s startup, the boot interface will be displayed on the left of the front panel LCD screen. After the start up, the screen will show the current state of the... -
Page 17: Main Menu Introduction
Main menu introduction Use "OK" button in the main menu to return and the knob button to select and adjust various projects. The operation has a fixed mode, please see the table below: Main Menu In the non-menu state, press "knob" and the menu system will enter the main menu and what displayed on the LCD screen will be shown as below: Image Settings Input Configuration... -
Page 18: Image Set Submenu
Image Set Submenu Image Mode Standard Brightness Contrast Color Acuteness VGA Enrichment DVI Enrichment Color Temperature Image Parameter Reset color temperature Standard Image parameter reset Press the OK button to continue Green Press return to cancel Blue... -
Page 19: Import Configuration
Import Configuration Button 1 Port #1 Type VGA Button 2 Port #2 Type VGA Button 3 Port #3 Type VGA Button 4 Port #4 Type VGA Button 5 Port #5 Type VGA Button 6 Port #6 Type VGA Button 7 Port #7 Type DVI Button 8... -
Page 20: Output Configuration
Press OK to confirm Pre-monitoring 2 Press the back key to return Horizontal width： 1024 Vertical height： 768 Horizontal position：0 Vertical position：0 Press OK to confirm Output MIG-630C series supports 7-channel resolution output as Resolution follows: 1024x768/60Hz, 1280x1024/60Hz, 1440x900/60Hz, 1600x1200/60Hz， 1920x1080/50Hz, 1920x1080/60Hz, 1920x1200/60Hz,... - Page 21 The selection of the resolution is to set the output resolution to the three channel output port (the resolution of three channel output port is the same). Then to individually adjust the screen size and position of the three channel output signal by adjusting the output window (screen size, position can only be adjusted within the set resolution range).
-
Page 22: Image Transition
Deploy the switch effect of “effect 1” and “effect 2”. Layout MIG-630C series has 16 kinds of transition effects: flash switch, fade-in and fade-out, right slide, left slide, up slide, down slide, horizontal inward, horizontal outward, vertical inward, vertical outward, box inward, box outward, cross inward, cross outward, checkerboard and blinds. -
Page 23: Vga Adjust
VGA Adjust Correcting Main Output ……… Pre Monitoring 1 Pre Monitoring 2 Corrected ……… Main Output Correction of the VGA input signal in main output channel PIP 1 Correction of the VGA input signal in first pre-monitoring channel PIP 2 Correction of the VGA input signal in second pre-monitoring channel... -
Page 24: Pip
PIP 1 PIP 1 Horizontal Horizontal PIP 2 Width 1024 Position Vertical Vertical Height Position PIP 2 Horizonta l Horizontal Width 1024 Position 768 Vertical Vertical Height Position Picture in Picture has the function of "open" and "off", the default is off。 Horizontal Width Level of the points of output window. -
Page 25: Image Crop
Image Crop Port Main Output Image Crop Horizontal Horizontal Width 1024 Position Vertical Vertical Height Position Image Crop The image capture has the function of "open" and "off", the default is off. Horizontal Width Interception of the level of image points. Vertical Height Vertical interception of image points. -
Page 26: Chroma Key Function
Chroma Key Function Chroma function Chroma settings Layer Selection Picture （0~0） picture 2 Green （0~0） Green Color range 1 Blue （0~0） Blue Color range 2 Auxiliary Color range 2 Disable/Enable Cursor switch Chroma Chroma key has the function of "open" and "off", the default function is off. -
Page 27: Logo Setting
After finishing selecting LOGO layer (PIP 1 or PIP 2), enter color range 1, then select the color need to be wiped through the auxiliary cursor "left" or "right", “up” or “down”. Take white LOGO with black background for example. You can move the cursor to the black areas and press "OK"... - Page 28 V height To adjust the vertical height of the frame from the source channel. To adjust the horizontal setting of the frame from the position source channel. To adjust the vertical setting of the frame from the position source channel. Save To save the selected part of image from the source LOGO...
-
Page 29: Test Pattern
Note1: the switcher will shut down for a period in the process of saving logo, this process may last for 8~180 seconds. Note 2: Two key lights in the front panel may twinkle alternately in the process of saving or loading LOGO files. Note 3: It takes 170~180 seconds to save LOGO, the time takes to load is in proportion to the LOGO area. - Page 30 Customized EDID DVI port 1920 Output refresh rate 1080 apply ► reset 60Hz ► DVI port Select the signal source port which needs customized EDID. Adjust the value of horizontal resolution. Adjust the value of vertical resolution. Output refresh rate Adjust the value of refresh rate.
- Page 31 Language You can choose the type of language customer needs. "English" and "Chinese". Multi-Preview Simultaneously preview the specified or the entire channel screen. Multi-channel pre-monitoring uses the time-sharing processing technology. Therefore when opening the multi-channel preview function, please select the input channels which need to pre-monitored. Only activated channels are pre-monitored.
-
Page 32: Quick Application
QUICK APPLICATION Port Introduction MIG-630C series is supportive for 6 AV signal input, 6 VGA signal input and 4 DVI input，and 2 expanding input, including 1 SDI input and 1 DVI input. MIG-630Cseries is supportive for 3 group signal output including main output, preview 1 and preview 2. -
Page 33: Shortcut Introduction
Expanding Cross-shape Cross-shape Expanding Squeezing Checkerboard Shutter Shortcut Introduction Number Key There are three rows of number keys. The first row are signal choosing keys of the main channel, and the second row is input signal choosing key of channel DVI 1. - Page 34 PIP1 Double image shortcuts, lightly press this key, and open the debug menu of picture in picture 1 in DVI 1. Picture in Picture1 Open Horizontal Width1024 Horizontal Location 768 Vertical Height Vertical Location PIP2 Double image shortcuts, lightly press this key, and open the debug menu of picture in picture in DVI 2.
- Page 35 Prog represents the main channel. Pre1 represents preview channel 1. Pre2 represents preview channel 2. H represents horizontal width. V represents vertical height. POSITION Shortcut for adjusting image location， lightly pressing this key, and the menu to adjust the three image location will pop out. Position Prog Pre1...
- Page 36 MODE Mode shortcut button, lightly press this key and mode dialog box will pop out as below Preview 2 Number Key Loading Mode Load/Reserve EFFECT1/2 Number Key 1 to 10 can choose serial number of templates which are needed for loading or reservation. Lightly pressing key “EFFECT1”, the current menu can be switched into template loading interface.
-
Page 37: Model Introduction
Model Introduction MIG-630C X X Expand Input 1 Expand Input 2 Warranty Explanation Whole Unit Warranty Period One year (from the buying date); If the invoice is lost, the 60 days after the production date will be the ...
