- Page 1 OUTDOOR HOUSING Hi-Speed Dome Camera Outdoor Housing Instruction Manual...
-
Page 2: Table Of Contents
CONTENTS Warning & Caution General Features Names of Each Part A. Basic Parts B. Accessories Installation A. Wall Mount Bracket B. Pipe Mount Bracket C. Gooseneck Mount Bracket D. Corner Mount Adaptor E. Pole Mount Adaptor Fan / Heater Specification Rev 1.2... -
Page 3: Warning & Caution
Warning & Caution If you fail to read this information and handle the product incorrectly, death or General Features serious injury may occur. The unit should be installed by trained IP 66 Outdoor Housing acquires weatherproof capacity Input power: With Camera - 24V AC IP66. -
Page 4: Name Of Each Part
Name of each Part A. Basic Parts FIG.1 1. Wall Mount Bracket 2. Sun-visor 3. Housing 4. Bubble 5. Ceiling Mount Bracket for indoor camera 6. Fan 7. Heater 8. Circuit Board 9. Pipe Mount Bracket Rev 1.2... -
Page 5: Accessories
Name of each Part B. Additional Accesorries TB-105 – Pipe mount bracket TB-106 – Goose neck mount bracket TB-107 – Corner mount adaptor TB-109 – Pole mount adaptor Rev 1.2... -
Page 6: Installation
Installation A. Wall Mount Bracket FIG.2 <the cable into the ceiling> <the cable out of the ceiling> A-1. To install Wall Mount Bracket Select a ceiling board strong enough to hold 4 times the total weight of the camera (weight combined camera : approx.5kg) FIG.3 FIG.4 A-2. -
Page 7: Pipe Mount Bracket
Installation B. Pipe Mount Bracket THREAD SEAL TAPE SILICON SEALANT FIG.5 <the cable into ceiling> <the cable out of ceiling> B-1. Wind the Seal Tape around the tap of pipe and screw down the Housing. B-2. Put Silicon Sealant into the connection part. FIG.6 <the cable into the ceiling>... -
Page 8: Gooseneck Mount Bracket
Installation C. Gooseneck Mount Bracket THREAD SEAL TAPE SILICON SEALANT FIG.7 C-1. Wind the Seal Tape around the tap of pipe and screw down the Housing. C-2. Put Silicon Sealant into the connection part. FIG.8 <the cable into the ceiling> <the cable out of the ceiling>... -
Page 9: Corner Mount Adaptor
Installation D. Corner Mount Adaptor D-1. Install a corner mount adaptor on the corner of wall. D-2. Install fixable brackets (wall, gooseneck) with a corner mount adaptor E. Pole Mount Adaptor E-1. Install a pole mount adaptor on the pole. Rev 1.2... -
Page 10: Fan / Heater
Fan / Heater E-2. Install fixable brackets (wall, gooseneck) with a pole mount adaptor HEATER AC24V 1A FIG 11 Joint with adaptor or FIG.7 Dome camera power Rev 1.2... -
Page 11: Specification
Specification MODEL Outdoor Housing Temperature for Heater working On: below 10 , Off: over 15 Temperature for Fan working On: over 45 , Off: below 35 -40 ℃ ~ +60 Temperature Range of Use Humidity Range of Use Below 90% Waterproof Capacity IP 66 Construction... - Page 12 Rev 1.2...
