ASSEMBLY

1. Remove the heater and all the accessories from the carton.
2. Fasten the 4 casters onto the base supporting plates by using the nuts
provided.
3. Turn the heater upside down.
4. Attach the caster base assemblies on first and last radiating fins.
5. Hook U-bolts on caster base assemblies and then wrap it around the
center tubing.
6. Tighten the wing nuts.
7. Turn the heater back to the upright position with casters on the ground.

ELECTRICAL RATINGS

This product is rated 12.5 amps (1500W) at 120V, 60 Hz.

FEATURES

Radiating flanges
Built-in handle
Thermostat knob
Power switch knob
Power indicator
Cord housing
Caster base assemblies
Caster
