Mobilator IBOX-1037UA User Manual

Supports intel celeron 1037u processor

Advertisement

Quick Links

User Manual
IBOX-1037UA
Supports Intel Celeron 1037u Processor
With POWER DC
1*RTL8105E LAN /3*SATA/COM1, COM4~COM6 support RS232/
COM2-COM3 support RS485/ 4G RAM/ 128G M-SATA/1*VGA
User Manual
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IBOX-1037UA and is the answer not in the manual?

Questions and answers

Summary of Contents for Mobilator IBOX-1037UA

  • Page 1 User Manual IBOX-1037UA Supports Intel Celeron 1037u Processor With POWER DC 1*RTL8105E LAN /3*SATA/COM1, COM4~COM6 support RS232/ COM2-COM3 support RS485/ 4G RAM/ 128G M-SATA/1*VGA User Manual...
  • Page 2 Trademarks IBOX-1037UA is a registered trademarks; IBM PC is a registered trademark of the International Business Machines Corporation; Pentium is a registered trademark of Intel Technologies Inc; Award is a registered trademark of Award Software International Inc; other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.
  • Page 3 IBOX-1037UA Model Processor INTEL® Celeron® 1037U(22mm, 2M Second Cache, 1.8 GHZ) Chipset INTEL® Celeron 1037U + NM70 Memory 1 * 204-pin DDR3 800/1066/1333 SDRAMcan up to 8G 2 * Mini PCI-E Slot Expansion Slot 3* Serial ATA2 Storage 1 * Mini-SATA...
  • Page 4 Check if the following items are included in the package. l * IBOX-1037UA l * Screw Package l * Software Utility CD l * 12V/5A Power Adapter COM2, COM3 support RS485...
  • Page 5 CPUFAN SYSFAN ATX_12V PS/2 JHDMI DDR3 JVGA1 PWROUT SATA1-3 LVDS JVGA2 COM7_10 GPIO TX-RXCOM Mini-PCIE COM2 MSATA AUDIO USB2/3 COM3_6 1)JBAT :CMOS Data retention/clear...
  • Page 6 2)COM Port Setting (JP13, JP14) JP13 and JP14 can be used to set the COM1~6 RS232 with function of Electricity, Default : RS232 . JP14 JP13 Jumpe Setting Function COM1 RS232 JP14 COM1 +5V COM1 +12V COM2 RS232 COM2 +5V COM2 +12V COM3 RS232 9-10...
  • Page 7 JP15 can be used to set the Transmission Mode of COM2/COM3, COM2/COM3 support RS232/RS422/RS485. You can set it according to your requirement, Default: RS232. JP15 JP15 Function Remark RS232 RS485 COM2 RS422 RS232 9-10 RS485 COM3 11-12 RS422 4) SATA Power Supply Interface (SATA1/SATA2/SATA3/PWROUT) SATA PWROUT Signal...
  • Page 8 SATA SATA_TXP SATA_TXN SATA_RXN SATA_RXP 5) AUDIO AUDIO AUDIO Signal Signal MIC-L MIC-R AUDIO-JD Line out-R Sense-FB Line out-L...
  • Page 9 6). FP1 Signal Signal HDD-LED+ PWRLED+ HDD-LED- PWRLED- 7) USB(USB2, USB3) Provide 2*9Pin USB pin header, Can Convert to 4*USB2.0 Signal Signal DATA- DATA- DATA+ DATA+...
  • Page 10 8) Definition of COM Port Notice: The RS485/422 signal of COM2/3 is extracted by TX-RXCOM pin header: Specific Definition is Following: COM2 COM3_6 COM3-6 COM7_10 COM2 Signal Signal MDCD MRXD MTXD MDTR MDSR MRTS MCTS COM3_6 Signal Signal COM3_DCD COM3_RXD COM3_TXD COM3_DTR COM3_DSR...
  • Page 11 COM6_DSR COM6_RTS COM6_CTS COM6-RI TX-RXCOM Signal Signal TXD+ TXD- RXD+ RXD- TXD+ TXD- RXD+ RXD- 9) Display Interface ( JHDMI, LVDS, ) JHDMI LVDS LVDS JVGA2 JHDMI Signal Signal TXP2 SCLDDC TXN2 SDADDC TXP1 TXN1 PLUGC TXP0 5V_HDM TXN0 TXCP TXCN...
  • Page 12 10)Programmable for Input and Output interface(GPIO) The GPIO support 4 Roads GPIO GPIO GPIO Signal Signal GPIO GP14 GP54 GP51 GP55 GP52 GP56 GP53 GP57 11) Power Suppply Interface(ATX_12V) ATX_12V ATX-12V Signal +12V +12V...
  • Page 13 12) Mini-PCIE slot (Mini-PCIE、MSATA) Provide 1*Mini-PCIE,Support WIFI/3G Model and 1 * MSATA slot,Support SSD/WIFI. MSATA Slot MINI-PCIE Slot...
  • Page 14: Bios Setting

    BIOS SETTING This chapter describes the BIOS menu displays and explains how to perform common tasks needed to get the system up and running. It also gives detailed explanation of the elements found in each of the BIOS menu displays. The following topics are covered: Main Setup Advanced Setup Chipset Setup...
