Please completely read and understand the entire manual before using, assembling and/or
disassembling your remote controlled car.
1/24TH SCALE 4WD/4WS ELECTRIC POWERED ROCK CRAWLER
Technical Data:
SCALE
LENGTH
1/24TH
190mm
SCALE
Note: This date is subject to change without the prior notice.
Main Features:
Indoors or out, this 1/24th scale rock crawler is a fun in the palm of your hand.
4-Wheel drive and 4-Wheel steering makes this 1/24th scale rock crawler agile and enjoyable.
Complete ready to run, just add three AA batteries to the radio controller, this 1/24th scale rock crawler includes
a 2.4GHz remote control and is fully assembled.
Four Wheel Drive
Four Wheel Steering
Anodized Aluminum TVP Chassis
4-link Suspension
This product is not a toy. It is not intended for persons under 14 years of age, unless closely
supervised by an adult.
This manual is subject to change without prior notice.
WIDTH
HEIGHT
125mm
105mm
Ready To Run
Integrated receiver/ESC
2.4GHz radio system
High-precision steering servos
INSTRUCTION MANUAL
1/24TH SCALE ROCK CRAWLER
WHEELBASE
WHEEL DIA.
135mm
55mm
ITEM NO.: 2098B
WHEEL WIDTH
BATTERY
27mm
6.4V,500mAH
Rechargeable battery pack
Animated off road body
V-tread off road tires
