Summary of Contents for Melive T86+
- Page 1 User Manual Model : T86+ WiFi Action Camera Made by: Melive Technology Co., Ltd Version: Melive-V1.0 Melive Technology Co., Ltd - 1 -...
-
Page 2: Product Diagram
A WiFi Activation (Down select) F POWER(and menu) B LED power indicator G USB interface C LCD screen H Micro SD card port D SHOOT (menu select) I Mini HDMI interface E Microphone J Removable Li-Battery Melive Technology Co., Ltd - 2 -... -
Page 3: Remote Diagram
Please ensure the camera is switched on before using the remote. A LED Indicators B Shoot Photo C Record Video D Power Off E Micro USB Charge port on the back of remote Melive Technology Co., Ltd - 3 -... - Page 4 Turn the camera on- press and hold the POWER button for several seconds. When the camera is on, the Melive logo will appear on the screen and the three red LED lights will glow red. The camera is now in video mode.
- Page 5 Red LED light Red LED light Red LED light Melive Technology Co., Ltd - 5 -...
-
Page 6: Video Mode
Picture mode is active, it will display the Image capture settings. By default, video mode is the active mode when you turn the device on. Melive Technology Co., Ltd - 6 -... -
Page 7: Video Settings
This allows user to set record duration OFF-In this mode, camera will generate new file on every 25 mins 1 Min-In this mode, camera will generate new file on every 1 mins Melive Technology Co., Ltd - 7 -... - Page 8 SELECT OFF for video only. Date Stamp Off: to turn off displaying date stamp on captures Date: to display date on captures Date & Time: to display date& time on captures Melive Technology Co., Ltd - 8 -...
-
Page 9: General Settings
This will determine if the LCD will turn off after 1 min, 3 min or 5 min. Press any key to turn the screen on. Select OFF to keep the screen always ON. Auto Power Off To set Auto Power off function Melive Technology Co., Ltd - 9 -... -
Page 10: Light Frequency
24hr clock. Language To select the device language Light Frequency Selecting the correct light frequency will avoid the possibility for strobing General Setting Screen (Page 2) Screen rotation To rotate the screen Melive Technology Co., Ltd - 10 -... -
Page 11: Wifi Password
Note: Use the WiFi button to navigate, use SHOOT button to confirm. The name is entered in “ WiFi _CAM_000” format, you can only change the last three numbers which are displayed with cycle numbers. Melive Technology Co., Ltd - 11 -... -
Page 12: Picture Mode
Turn the camera on Press and hold the SHOOT button for 3secs You will see P( )on top left corner of the screen Press SHOOT button to take snapshots Melive Technology Co., Ltd - 12 -... -
Page 13: Picture Settings
Resolution To select the image resolution Quality To set the image quality Metering Metering mode refers to the way in which a camera determines the exposure. Melive Technology Co., Ltd - 13 -... - Page 14 This allows user to set the timer for auto image capture Date Stamp Off: to turn off displaying date stamp on captures Date: to display date on captures Date & Time: to display date& time on captures Melive Technology Co., Ltd - 14 -...
-
Page 15: Charging The Battery
Insert the Micro SD* It is recommended to use Class 6 (or higher) Micro SD card to shoot smooth video files. Lower class cards may cause the video to be blurry or jerky Melive Technology Co., Ltd - 15 -... -
Page 16: Video Recording
To take snapshot, you will need to switch the camera from video mode to image capture mode. To enter this mode: Turn the camera on Press and hold the SHOOT button for 3secs You will see on top left corner of the screen Melive Technology Co., Ltd - 16 -... -
Page 17: Playback Mode
To exit Playback mode press and hold the SHOOT button to return to the normal recording mode. Connecting to TV You can display the camera LCD screen on a TV screen. Note: You will need a Mini HDMI to HDMI cable. Melive Technology Co., Ltd - 17 -... - Page 18 3. Go to the WiFi settings on your Phone, you will see WiFi _CAM_000 in the list of available Wireless networks. Note: You can change the WiFi name in the menu setting. 4. Connect your Phone to the “iSmart DV” via WiFi . Melive Technology Co., Ltd - 18 -...
- Page 19 “iSmart DV” App on your smart phone or tablet. App Interface Diagram Settings Video Resolution Battery Icon Playback Mode Switch Photo/Mode Record Note: To watch the recorded videos on your phone, you need to download them first. Melive Technology Co., Ltd - 19 -...
-
Page 20: Saving And Viewing Options
The T86+ is designed to be used in the waterproof case (B). Before inserting the T86+ in the case, select video or picture mode. Notes: Ensure the case is dry and clean. Melive Technology Co., Ltd - 20 -... -
Page 21: Specifications
Automatic ISO 100-200 Microphone Built-in Display 2” TFT LCD Video: MOV H.264 Format Still photo: JPEG Power supply 3.7V/1000mAh removable Li-Battery Battery life Video: about 1.5 hours without WiFi Dimensions 54x37x51mm Casing 49.5x76x84mm Melive Technology Co., Ltd - 21 -... -
Page 22: System Requirements
2011/65/EC RoHs Directive 2004/108/EC Low Voltage Directive 1999/5/EG R&TTE Directive 2006/95/EEC LVD Directive 2009/125/EG EuP Directive The EC Declaration of Conformity can be requested from the address 2002/96/EG WEEE Directive specified on the Warranty card. Melive Technology Co., Ltd - 22 -... -
Page 23: What's In The Box
A T86+ Camera G 3M adhesive B Waterproof case H Lock Bolt C Portable camera frame Knuckle D Quick release mount J USB cable E Curved mount K Wrist Remote controller F Flat mount Melive Technology Co., Ltd - 23 -... -
Page 24: Safety Precautions
Do not attempt to open the case of the camera or modify it in any way. If the camera has been opened, the warranty will be void. Maintenance and repairs can only be performed by Melive. Keep the camera away from water and other liquids (unless used in the waterproof case).
