Congratulations on becoming the new owner of the world's
most prestigious boat. We at Sea Ray
welcome you into our worldwide and ever-expanding
family of boating enthusiasts.
The Owner's Manual Packet, to be kept on board your
Sea Ray, gives you important information on all the
features of your Sea Ray, for years of trouble-free boating
take the time to carefully review the information in your
Owner's Manual Packet and really get to know your boat.
Have everyone who will operate your boat read this
manual.
The Owner's Manual Packet contains the following:
•
Owner's Manual: The Owner's Manual gives you
important operating and safety information, as well
as reminding you about your responsibilities as a
boat owner/operator.
52 Sedan Bridge (525 Sedan Bridge)
W
ELCOME
Owner's Manual
•
®
Boats, Inc.
Because your purchase represents a substantial
investment, we know you will want to take the necessary
measures to protect its value. We have outlined a program
for proper operation, periodic maintenance and safety
inspections. We urge you to follow these recommendations.
If you have questions which are not fully covered by the
Owner's Manual Packet, please consult your authorized
dealer for assistance.
Original Equipment Manufacturer (OEM)
Information: This section of your Owner's Manual
Packet contains information from the manufacturers
of equipment installed on your boat. Examples
include the engine, engine control and steering
system. Throughout the Owner's Manual you will be
referred to information provided by manufacturers of
specific systems.
Thank You For Selecting A Sea Ray
®
!
Bon Voyage
