READ YOUR OPERATOR'S MANUAL COMPLETELY AND CAREFULLY BEFORE
ATTEMPTING TO SET UP OR OPERATE YOUR NEW
EQUIPMENT SHOULD READ AND UNDERSTAND ALL SAFETY RULES PRINTED ON THE MACHINE
AND IN THIS OPERATOR'S MANUAL BEFORE USE.
NOTICE: On the nameplate of your machine you will find the serial number and MFG date code of your unit.
Please record these numbers on this manual cover for future service reference.
MFG. DATE ________ PURCHASE DATE: _________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-444-6742, 8:00 a.m.-6:00 p.m., EST, Monday-Thursday,
8:00 a.m.-5:00 p.m., EST, Friday.
CAUTION - FOR YOUR SAFETY
18 V FAST CHARGE
TM
CORDLESS SWEEPER
GARDEN
TOOL. ALL OPERATORS OF THIS
ITEM # 8462
MODEL # 24013
PRINTED IN CHINA
Advertisement
Table of Contents
Related Manuals for Task Force 24013
Summary of Contents for Task Force 24013
- Page 1 ITEM # 8462 18 V FAST CHARGE CORDLESS SWEEPER MODEL # 24013 CAUTION - FOR YOUR SAFETY READ YOUR OPERATOR’S MANUAL COMPLETELY AND CAREFULLY BEFORE ATTEMPTING TO SET UP OR OPERATE YOUR NEW GARDEN TOOL. ALL OPERATORS OF THIS EQUIPMENT SHOULD READ AND UNDERSTAND ALL SAFETY RULES PRINTED ON THE MACHINE AND IN THIS OPERATOR’S MANUAL BEFORE USE.
-
Page 2: Table Of Contents
LIMITED TWO-YEAR WARRANTY …………………………………………………………………….…………..…………………14 PARTS LIST ……………………………………………………………………………………………….…………..…………………15 PRODUCT SPECIFICATIONS 18V SWEEPER Item Number ........................8462 Model Number........................24013 Type........................... Cordless, battery-operated Motor..........................18V Two speed..........................9500 RPM (Low) 13,000 RPM (High) Air volume...........................60 ft3/min (60 pi3/min) (Low) 85 ft3/min (85 pi3/min) (High) Air speed..........................80 MPH (125km/h) (Low) -
Page 3: Safety Information
SAFETY INFORMATION Please read and understand the entire manual before attempting to assemble, operate or install the product. These safety instructions are not meant to cover every possible condition that could occur. If you have any questions regarding the product please call customer service at 1-800-444-6742, 8:00 a.m.- 6:00 p.m., EST, Monday-Tursday, 8:00 a.m.-5:00 p.m., EST, Friday. -
Page 4: Electrical Safety
SAFETY INFORMATION General Safety Rules for All Battery-operated Tools WARNING READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. Work Area • Keep your work area clean and well-lit. •... - Page 5 SAFETY INFORMATION SPECIFIC SAFETY RULES For all garden tools • Avoid dangerous environments. Don’t use tool in damp or wet locations. Don’t use in rain. • Keep bystanders and children away while operating. • Dress properly. Do not wear loose clothing or jewelry.They can be caught in moving parts. Use of rubber gloves and substantial footwear is recommended when working outdoors.
- Page 6 SAFETY INFORMATION WARNING If the battery fluid gets in your eyes, flush immediately with clean water for at least 15 minutes. Get immediate medical attention. Do not charge the battery pack in rain or in wet conditions. Do not immerse the tool, battery pack, or charger in water or other liquid. •...
- Page 7 SAFETY INFORMATION Grounding (Fig. B) In the event of a malfunction or breakdown, grounding provides the path of least resistance for electric current, and reduces the risk of electric shock. This battery charger is double insulated and has a 2-prong polarized plug (one blade is wider than the other). This plug will fit into a polarized outlet only one way.
-
Page 8: Package Contents
PACKAGE CONTENTS By purchasing a battery-powered tool you have helped reduce the pollution level of our environment. Please check the contents of the carton with Fig. A. Examine all the parts before using the cordless sweeper and battery charger. If any parts aremissing or damaged, return the toolto the store with proof of purchase for a replacement. WARNING To reduce the risk of fire, electric shock, and personal injury: •... -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS Battery Pack (Fig.E) IMPORTANT! The battery pack is not charged when it is purchased. Before using the sweeper for the first time, place the battery pack in the battery charger and charge for 24 hours. Make sure to read all safety precautions, and follow the instructions in the Battery Charger section. -
Page 10: Operating Instructions
OPERATION INSTRUCTIONS Two Speed Switch (Fig. G) The sweeper has a two speed switch. To operate the sweeper: 1. Grab the handle (1) and pull the switch to the desired speed indicated on the power switch as High and Low (2). 2. -
Page 11: The Battery Charger
THE BATTERY CHARGER Charging Procedure (Fig. I) Charge the batteries before using for the first time.With regular use the battery pack will need one hour orless to charge. Occasionally, and after prolonged storagetime, charge the batteries again. Nickel-cadmium batteriescan develop a memory for usage and storage times. -
Page 12: Maintenance
MAINTENANCE WARNING To avoid personal injury and risk of fire and electric shock, always remove the battery pack before adjusting, inspecting, or cleaning. Cleaning Remove the battery pack. 1. Brush or sweep dust and debris out of the air vents using compressed air or a vacuum. Keep them free of obstructions, sawdust and wood chips. -
Page 13: Environmentally Safe Battery Disposal
ENVIRONMENTALLY SAFE BATTERY DISPOSAL The following toxic and corrosive materialsare in thebatteries used in this sweeper battery pack: Cadmium, a toxic material. WARNING All toxic materials must be disposed of in a specified manner to prevent contamination of the environment. Before disposing of damaged or worn out nickel-cadmium battery packs, contact your local waste disposal agency, or the local Environmental ProtectionAgency for information and specific instructions.Take the batteries to a local recycling and/or disposalcenter, certified for cadmium disposal. -
Page 14: Limited Two-Year Warranty
LIMITED TWO-YEAR WARRANTY The manufacturer warranties to the original purchaser that each new product and service part is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective product or part as follows from the original date of purchase. -
Page 15: Parts List
PARTS LIST Item Item 3410173 3410273 3620173 3410373 3410946 3410473 3630173 3410673 3110273 3110373 3610173 3220313 3330173 3290173 3220505 Printed in China...
