IMPORTANT!

Safety Instructions

All Operators Must Read These

Instructions Before Use

Always follow these safety guidelines. Failure to do so may

result in serious bodily injury or death.

General Safety WARNINGS!

When using this electric dethatcher, basic safety precautions

should always be followed to reduce the risk of fire, electric

shock and personal injury.

Before using the dethatcher, take the time to familiarize

yourself with the controls, especially how to stop the

dethatcher in an emergency. The only individuals who

should use the dethatcher are those who have a thorough

understanding of the instructions and who know how to

operate the machine. Children should never be allowed

access to the dethatcher.

Retain this manual for future reference and reread it at the start

of each dethatching session.

General Safety

1. Avoid dangerous conditions – Do not use this machine

in rainy, stormy, damp or wet locations. Do not operate the

unit in gaseous or explosive atmospheres. Motors in these

units normally spark, and the sparks may ignite fumes.

2. Keep children, bystanders and pets away – Always

keep children and spectators a safe distance away from

the dethatcher during operation and as the machine cools.

3. Dress properly – Always wear personal safety gear (i.e.

glasses, rubber gloves, protective footwear and dust

masks) and proper clothing when using the dethatcher.

Loose clothing, long hair or jewelry may get caught in the

moving parts.

4. Use the right appliance – This dethatcher is intended

for outdoor use only. Do not use the dethatcher for any

application other than that for which it is intended.

5. Do not force the dethatcher – It will perform better with

less likelihood of personal or mechanical injury if it is used

at the rate for which it is designed.

6. Do not overreach – Keep proper footing and balance at

all times.

, LLC

14-INCH 11-AMP

ELECTRIC DETHATCHER

Model AJ800E

7. Stay alert – Always be alert and watch what you are

doing. Use common sense. Do not operate the dethatcher

when you are tired or under the influence of alcohol or

drugs.

8. Disconnect the dethatcher – Disconnect the dethatcher

from the power supply when it is not in use, before

servicing it, when changing accessories and when

performing any other maintenance task.

9. Store idle dethatcher indoors – When not in use, the

dethatcher should be stored indoors in a dry, locked place

out of the reach of children.

10. Maintain the dethatcher with care – Keep cutting edges

sharp and clean for optimal and safest performance.

Inspect the dethatcher cord periodically and if damage

is found have it repaired by an authorized service facility.

Extension cords should also be inspected periodically and

immediately replaced if damaged. Keep handles dry, clean

and free from oil and grease.

11. Double insulation – This dethatcher is equipped with

double insulation. This means that all external metal parts

are insulated from the electrical supply. This is achieved

by introducing an insulation layer between electrical and

mechanical parts. The double insulation guarantees you

the greatest possible safety.

12. Replacement parts – When servicing this unit, use only

identical replacement parts. Replace or repair damaged

cords immediately.

13. Polarized plug – Polarized appliance connections reduce

the risk of electric shock. This dethatcher has a polarized

plug (one blade is wider than the other) and will require

the use of a polarized extension cord. There is only one

way the dethatcher's plug will fit into a polarized extension

cord. If the plug does not fit fully into the extension cord,

reverse the plug. If the plug still does not fit, obtain a

correct polarized extension cord. A polarized extension

cord will require the use of a polarized wall outlet. There

is only one way the plug will fit into a polarized wall

outlet. If the plug does not fit fully into the wall outlet,

reverse the plug. If the plug still does not fit, contact a

qualified electrician to install the proper wall outlet. Do not

modify the equipment plug, extension cord receptacle or

extension cord plug in any way.

SAVE THESE INSTRUCTIONS

Form No. SJ-AJ800E-880E-MR3

OPERATOR'S MANUAL

Table of Contents

Summary of Contents for Sun joe AJ800E

Page 1: Safety Instructions
14-INCH 11-AMP ELECTRIC DETHATCHER Model AJ800E Form No. SJ-AJ800E-880E-MR3 OPERATOR’S MANUAL A Division of Snow Joe , LLC ® IMPORTANT! 7. Stay alert – Always be alert and watch what you are doing. Use common sense. Do not operate the dethatcher...
Page 2: Electrical Safety
3. To reduce the risk of electric shock, this appliance has WARNING! Some dust and debris created by the a polarized plug (i.e. one blade is wider than the other). use of this tool could contain chemicals known to the State Use this appliance only with a polarized, UL-listed (CSA of California to cause cancer and birth defects or other certified in Canada) extension cord recommended for...
Page 3: C Hildren Safety
• Your power tool should be serviced only by a qualified • Exercise caution to avoid slipping or falling. repair technician at an authorized Snow Joe + Sun Joe ® ® • If the dethatcher should start to vibrate abnormally, service center.
Page 4: Safety Symbols
Safety Symbols The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all instructions on the machine before attempting to assemble and operate. Symbols Descriptions Symbols Descriptions Do not push down stairs. CPSC Danger label.
Page 5: Technical Data
Know Your Electric Lawn Dethatcher Read the owner’s manual and safety instructions carefully before operating the dethatcher. Compare the illustration below to the dethatcher in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference and reread it prior to each dethatching session.
Page 6: Carton Contents
Assembly Upper handle Carefully follow the instructions below to assemble your Height Cable relief Sun Joe electric dethatcher. ® holder adjustment NOTE: The packaging is made of recyclable materials. holes Properly dispose of these materials in accordance with regulations.
Page 7: Operation
Removing + Emptying the Collection Bag Assembling the Thatch Collection Bag 1. Lift the thatch bag cover and take out the thatch The collection bag is delivered in a folded state and must collection bag. therefore be assembled before it is mounted on the unit. 2.
Page 8: Overload Protection
WARNING! The adjustment knob is not intended for Fig. 7 height adjustment, but rather to compensate for tine wear. Selection of a readjustment position without the corresponding wear can overload the motor and damage the cylinder. Starting + Stopping Switch bar lever WARNING! Before switching on the dethatcher, make sure that it is not in contact with any foreign objects.
Page 9: Cleaning & Storage
Work that is not described in these instructions must be WARNING! Always turn off the dethatcher and carried out by an authorized Snow Joe + Sun Joe service ® ® unplug the power cord from the outlet before performing any center.
Page 10: Power Cord
3. Wearing protective gloves, grasp the right side of the cylinder shaft. Lift the cylinder out until it reaches the top When your AJ800E's raking performance diminishes, it's time half of the bearing block cover, then slide it to the right to to replace the tine cylinder to get your dethatcher back in disengage it from the motor drive (Fig.
Page 11: Troubleshooting
Unsatisfying result a) Cutting device worn a) Replace the tine cylinder (see page 10) Service + Support If your Sun Joe AJ800E electric dethatcher requires service or ® maintenance, please call 1-866-SNOWJOE (1-866-766-9563) for assistance. Model + Serial Numbers When contacting the company, reordering parts or arranging...
Page 12: Optional Accessories
Optional Accessories WARNING! ALWAYS use only authorized Snow Joe + Sun Joe replacement parts and accessories. NEVER use ® ® replacement parts or accessories that are not intended for use with this dethatcher. Contact Snow Joe + Sun Joe if you are ®...
Page 13 NOTES...
Page 14 NOTES...
Page 15 SNOW JOE + SUN JOE CUSTOMER PROMISE ® ® ABOVE ALL ELSE, Snow Joe + Sun Joe are dedicated to you, our customer. We strive to make your experience as pleasant ® ® as possible. Unfortunately, there are times when a product does not work or breaks under normal operating conditions. We think it’s important that you know what you can expect from us.
Page 16 snowjoe.com...
