- Page 1 INDUSTRIAL RANDOM ORBITAL SANDER INDUSTRIAL RANDOM ORBITAL SANDER 6” (150MM) SWIRL SELF BALANCED FREE YEAR GENERATING SANDING VACUUM FINISHES WARRANTY K13250 ED1 December 15...
- Page 2 5. Hook & Loop Pad 6. Sander Body 7. Trigger 8. Vacuum Port/Exhaust 9. Nitto Style Fitting Model No: ........................K13250 Description: ......................Industrial Random Orbital Sander Air Inlet: ........................1/4” Orbit: ........................... 5mm Average Air Consumption: ..................45.3 lpm (1.6cfm) Free Speed: .......................
- Page 3 Check for misalignment or binding of moving parts, breakage of parts, and any other condition that affects the tool’s operation. If damaged, have the tool serviced before using, at an authoriesd Kincrome repair agent.Many accidents are caused by poorly maintained tools.
- Page 4 INDUSTRIAL RANDOM ORBITAL SANDER 4) Service a. Tool service must be performed only by qualified repair personnel. b. When servicing the Random Orbital Sander, use only identical replacement parts. Use only authorized parts. c. Use only the lubricants specified by the manufacturer. 5) Additional Safety Warnings a.
- Page 5 Note: If an automatic oiler system is not used, add a 4 to 5 drops of Kincrome Air Tool Oil to the air inlet (7) before operation. Add 1-2 more drops every hour of continual use. Figure A Attach an air hose to the compressor’s air outlet.
- Page 6 INDUSTRIAL RANDOM ORBITAL SANDER 9) Assembly Assembling the Dust Bag directly to the sander. Disconnect the air hose from the air inlet (3) and feed the air hose through the loop on the dust bag (1). Note: This will keep the dust bag (1) away from the sander while in operation. Get the dust bag (1) and feed the open end over the vacuum port (8).
- Page 7 Disconnect the tool from the air supply holding it so the air inlet (3) faces up. Hold the trigger (7) down and put 4 to 5 drops of Kincrome Air Tool Oil in the air inlet. Holding the trigger (7) down helps circulate oil in the motor.
- Page 8 CYLINDER K13250-44 PIN (3*14L) K13250-23 O-RING Kincrome reserve the right to change spare parts at any time without notice WE RESERVE THE RIGHT FOR ANY DESIGNING CHANGES TO THE PARTS AND WITHOUT ANY NOTICEMENT Indicates stocked spare parts IN ADVANCE.
- Page 9 INDUSTRIAL RANDOM ORBITAL SANDER Notes:...
- Page 10 www.kincrome.com.au...
