SECU SAFE RHD-1613B User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
V1.0
─ IVR ─
Notice: This content is subject to be change without notice.
User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RHD-1613B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SECU SAFE RHD-1613B

  • Page 1 User Manual V1.0 ─ IVR ─ Notice: This content is subject to be change without notice. User Manual...
  • Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOIS- TURE. NOTE: This equipment has been tested and found to comply with the limits for a class digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 LIVE OPERATIONS ....................5 Chapter 2 MAIN MENU SETUP .................... 7 2-1 Auto Sequential ......................11 2-2 Backup ......................... 12 2-2.1 Selection......................12 2-2.2 Select Backup Device ..................13 2-3 Configure ........................14 2-4 Time Search ......................... 15 2-5 System Logs.........................
  • Page 4 3-6.2 USB Flash Derive Setup ................. 50 3-6.3 DVD-RW Setup ....................50 3-7 System Setup ....................... 51 3-7.1 Auto Lock ......................51 3-7.2 Auto Reboot ..................... 51 3-7.3 Date/Time Setup ....................52 3-7.3.1 Time zone ________________________________________________________ 52 3-7.3.2 Daylight Saving Time Setup ..................53 3-7.3.3 Change Date and Time _____________________________________________ 53 3-7.4 Monitor Setup ....................

  • Page 5: Chapter 1 Live Operations

    Chapter 1 LIVE OPERATIONS In the live mode, you may monitor all channels of the IVR, listen to live audio from cameras, and configure the IVR. The IVR can support 4:3 and 16:9 aspect ratios of the screen layout. There is a shortcut toolbar on the top of the screen for users to logout, to access system information, to change screen aspect ratio, to make the IVR window full-screen, and to configure network stream quality.
  • Page 6 Table 1-1 Icon description in live mode Icon Description Recording of a channel is activated. Live audio of a channel is activated. Live audio of a channel is not activated. Video signal of a channel is available. Event recording of a channel is active in this channel.

  • Page 7: Main Menu Setup

    Chapter 2 MAIN MENU SETUP To enter the main menu and set up a IVR, log-in account and user password are required. The default password of the administrator is “123456”. Please check the “Account Setup” for management of other log-in users. Table 2-1 Definition of keys of virtual keyboard Icon Description...
  • Page 8 There are icons within the configuration pane on the live mode to operate different features of the IVR. The configuration pane is always on the left or right side of the screen in the 16:9 mode and can to be evoked by right-click in the 4:3 mode. 16:9 display, the main menu is on the right side of the screen 4:3 display, right-click on the screen to evoke the main menu.
  • Page 9 Table 2- 3 Description of icons Icon Description Set the auto sequential menu Set the backup menu to backup video data from IVR HDD. Set the configuration menu to access recording settings, event settings, camera settings, account settings, network settings, storage settings, system configuration, and information Set the time search menu to choose a specific time of the recorded video to playback...
  • Page 10 Switch to 10-split display Switch to 13-split display Switch to 16-split display Switch to 20-split display Switch to 25-split display Switch to 32-split display *1.Maya V2 Series not support focus mode *2 PIP not Support RHD-813B、RHD-1613B、HHD-2013B & DVR-3213B User Manual...

  • Page 11: Auto Sequential

    2-1 Auto Sequential 16:9 Display 4:3 Display Item Description Interval The time interval between each channel display The IVR automatically switches between channels with designated in- All Channels terval. The IVR shows each channel in a single-split mode. Quad-Screen Divi- The IVR automatically switches between channels with designated in- sion terval.

  • Page 12: Backup

    2-2 Backup User can backup recorded video data of a specified time frame. The IVR can backup video data to either direct-attached storage, such as IVR or USB drive, or remote folder of a PC. 2-2.1 Selection Item Description From The start time of video data to be backed up The end time of video data to be backed up Duration...

  • Page 13: 2-2.2 Select Backup Device

    2-2.2 Select Backup Device Item Description Select target device of backup (USB/DVD-RW/remote folder) 。 Backup Device Status The status of target backup device The available space in the target backup device. (not available for Free Space remote folder backup) Start backup operation. Backup Be sure to calculate the size of backup file BEFORE operating backup.

  • Page 14: Configure

    2-3 Configure Evoke the configuration menu, recording settings, event settings, camera set- tings, account settings, network settings, storage settings, system configuration, and information. Please refer to chapter 3 for detail. User Manual...

  • Page 15: Time Search

    2-4 Time Search Time search can search for the specific time of recorded data to playback. Note that dates with recording data are marked with a blue box. System will start playing video of specified time slot. Calendar will be shown by using mouse to click on “year”...
  • Page 16 16:9 Display Playback configuration 4:3 Display User Manual...
  • Page 17 Table 2-4 Available keys on the remote control functions in the PLAYBACK mode Button Description ENTER/ MODE Switch to full screen or multi split display. MENU / Turn on/off PAUSE. PLAY Playback at normal speed. / SLOW Playback at slower speed. The speed will be slowed to 1/2, 1/4, 1/8 playback speed, by each pressing of the button till the slowest speed.
  • Page 18 If you want to monitor single channel, please double-click the preferred channel. 16:9 Display 4:3 Display P.S Can drag a small window User Manual...

  • Page 19: System Logs

    2-5 System Logs The IVR logs events automatically. The event list shows the logged events, event type, event detail, event filter (criteria), and page number of the event list. If the event video is logged, there is a gray video symbol "►" on the left of the event.

  • Page 20: 2-5.1 Search Criteria

    2-5.1 Search Criteria The number of event is up to thousands, therefore, to set "search criteria" to facilitate rapid classification of events. If the checkbox of start time and end time is checked, the event list will only display the events within the specific time slot. If the user unchecks some events and press the "OK ", the lists will only shows checked events.

  • Page 21: Ptz Operation

    2-6 PTZ Operation Set up the camera PTZ settings in advance (refer to 3-3.1). Enter the PTZ con- figuration page, PTZ control panel displays the camera PTZ setting. There is a red cross on the center of the screen. Move the mouse to the Red Cross and hold down the left mouse button to the preferred location of the screen.
  • Page 22 4:3 Mode PTZ configuration Table 2-6 Function description Item Description ZOOM. Press + / - or move the slider to adjust the zoom level. FOCUS. Press + / - or move the slider adjust the PTZ focus IRIS. Press + / - or move the slider to adjust the PTZ iris Press left and right arrow keys to move the camera to the preset locations, and then press to set current camera...

  • Page 23: Zoom

    2-7 Zoom In the digital zoom mode, users may use the mouse to move the red rectangle of the zoom area. 16:9 display zoom 4:3 display zoom P.S Can drag a small window Item Description Zoom-in the area specified by the red rectangle. Zoom-out the area specified by the red rectangle.

  • Page 24: Shortcut Toolbar

    2-8 Shortcut toolbar Real-time monitoring mode, move your mouse over the window function column appears above its fast operation ICON Description User login / logout: Auto lock is used. System Information: The host model, version, IP location, MAC values and hard disk information.
  • Page 25 2-8.1 network image quality Option Description Low quality static mode: insufficient bandwidth used for one second about Low Quality Single Image running 1 ~ 2FPS. Low quality Low quality Dynamic mode: According to the IVR recording settings. High-definition single image under static mode: insufficient bandwidth to High-quality use for one second about running 1 ~ 2FPS.
  • Page 26 2-8.3 Popup Setup Item Description Prompt window displays the channel status。 Event Display time, HDD status, channel information, channel border. 2-8.4 Relay Setup Option Description Relay Relay 1 ~ 4 J Series x1, N Series x2, B Series x4. Functional open, close, automatically User Manual...

  • Page 27: Chapter 3 Configuration Menu

    Chapter 3 CONFIGURATION MENU PS. The initialization of new-installed HDD is required before recording, please refer to “UTILITY SETUP” for detail. 3-1 Record Setup Item Description Record Mode Continuous Record/ Schedule Record/ Stop Record User Manual...

  • Page 28: 3-1.1 Continuous Record

    3-1.1 Continuous Record Item Description Record Enable / Disable recording for this channel Audio Enable / Disable recording audio User Manual...

  • Page 29: 3-1.2 Schedule Recording

    3-1.2 Schedule Recording Schedule recording can configure recording time by days of a week and hour. With the A, B, C, D four settings, users can set different recording scheme ac- cording to different configuration needs. In the day and time grid map, select the schedule time zone, and then press A, B, C, D one of the buttons to specify the video settings.

  • Page 30: 3-1.2.2 Holiday Configuration

    3-1.2.2 Holiday Configuration The number of holiday is up to 50. When the time comes to the specified holi- days, the IVR will start recording according to holiday configuration. Since holidays are different by different country and region, users can setup holidays according to user needs.

  • Page 31: Event Setup

    3-2 Event Setup 3-2.1 Video Loss 3-2.1.1 Configuration Item Description Enable Enable / Disable video loss detection function 3-2.1.2 Event Handling Item Description Write to event log when the video loss event happens. Select channel for event recording when event occurs. The video setup corresponds to the "Configuration →...

  • Page 32: 3-2.1.3 Receiver Setup

    3-2.1.3 Receiver Setup Item Description Specify whether the IVR sends e-mail notice to specified users Enable when an event occurs. Admin / Users Specify the receiver of e-mail notices 3-2.2 Motion Detection 3-2.2.1 Configuration Item Description Enable Enable / Disable the motion detection function of this channel The sensitivity value is from 0 to 100.

  • Page 33: 3-2.2.1.1 Motion Area Setup

    3-2.2.1.1 Motion Area Setup 3-2.2.2 Event Handling Please refer to 3-2.1.2 Event Handling 3-2.2.3 Receiver Setup Please refer to 3-2.1.3 Receiver Setup 3-2.3 Sensor ※ Each sensor name can be modified and remotely can enter various languages 3-2.3.1 Configuration Item Description Enable Enable/Disable sensor...

  • Page 34: 3-2.4 System

    3-2.4 System When the system event occurs, give a notice or warning according to the set- tings of relay, buzzer, and receiver. If the buzzer box is checked, the buzzer continually beeps for only errors related to the video (such as hard drives can’t write or not install the hard drive).

  • Page 35: Camera Setup

    3-3 Camera Setup Item Description Enable/Disable Cannel and IP-CAM I/O mapping Hardware Link Connection Enable/Disable IP-CAM Set camera channel name Name When disable hardware link can select IP-CAM Camera Set Display IP-CAM protocol Protocol: Display IP and Port status IP/PORT: Display device unique identification number Set IP-CAM user name User Name...
  • Page 36 Advance Setup Setup IP-CAM Stream 1(main stream), Stream 2(sub stream) resolution and quality User Manual...

  • Page 37: 3-3.1 Search Ip-Cam

    3-3.1 Search IP-CAM Item Description Select ICATCH / ONVIF protocol Protocol Refresh IP-CAM status Add IP-CAM Remove IP-CAM Modify IP-CAM setting Edit User Manual...

  • Page 38: Account Setup

    3-4 Account Setup You can set the user password and permissions of 10 user accounts (1 admin + 10 users). These different accounts gives users different permissions of IVR features. 3-4.1 Administrator The default admin account and password is “admin” and “123456” Item Description Check to activate the user’s account.

  • Page 39: 3-4.2 Other Users

    3-4.2 Other Users Item Description Check to activate the user’s account. Enable Expire Set the expiration date of the user account Name Set up username Set up the password. The password can be mixed of letters and Password numbers and is case-sensitive. e-Mail Set up user email User Manual...

  • Page 40: 3-4.2.1 Permission

    3-4.2.1 Permission The Account Setup is set to provide individual user role-based permissions, including access to Setup menu, Network operation, PTZ function, Playback, Utility, Backup, Password expiration date and Mask on specific channels while playing back. Item Description Console Playback Allow the permissions to playback channel in local side Remote Live &...

  • Page 41: Network Setup

    3-5 Network Setup Item Description DHCP The IVR retrieves from a DHCP server automatically. Static IP Set up a Static IP address of the IVR. PPPoE Set up the username and password for PPPoE connection. 3G Setup Set up the login configuration of 3G connection HTTP Setup Set up the HTTP configuration for remote access.

  • Page 42: 3-5.1 Networking Setup (Wan)

    3-5.1 Networking Setup (WAN) There are three ways to connect to the network. 3-5.1.1 DHCP Setup When DHCP is selected, IP address will be assigned by DHCP server automatically. Notice: The IP address shown in this page is not the IP address obtained from the DHCP server. The IP obtained from the DHCP server is shown in the System Information Page.

  • Page 43: 3-5.1.3 Pppoe Setup

    Item Description Enable Enable / Disable Static IP function。 Enter the static IP address provided by ISP Subnet Mask Enter IP address of Subnet Mask provided by ISP Gateway Enter IP address of the Gateway provided by ISP Enter the DNS address provided by ISP. (Note: The correct DNS address must be entered for DDNS function).

  • Page 44: 3-5.1.4 3G Setup

    3-5.1.4 3G Setup Using the USB 3G dongle to access the network PS: only specific chip of 3G dongle is supported and the 3G dial-up features may not be com- patible to some ISPs. Item Description Enable Enable / Disable 3G function. Dial Number Dial-up Number, offer by the ISP Enter SIM card password...

  • Page 45: 3-5.2 Http Setup

    3-5.2 HTTP Setup Item Description Enable Check to enable HTTP server. Users can remotely access into the IVR over the network if the HTTP function is activated. Port Enter a valid port value from 1 up to 65535. The default value is 80. 3-5.3 DDNS Setup User Manual...

  • Page 46: 3-5.4 Ntp Setup

    Item Description Enable Enable / Disable DDNS function. Enter the registered DDNS Server: Server ez- dns.com、i-IVR.net、dyndns.org ez- dns.com、i-IVR.net Supports automatic assignment DDNS When these two DDNS service, The system will automatically bring up to C + IVR Mac Address last six yards at the beginning of a host site, Such as the Mac end of the six yards of FD5CCD, Then bring out the host site at CFD5CCD.i-IVR.net or CFD5CCD.ez-dns.com...

  • Page 47: 3-5.5 Mail Setup

    Item Description Automatically Synchro- Check to enable IVR automatic synchronization function when nize rebooting Update Interval (Hours) Setup interval for time synchronization Server Setup time server address Update Now Update the time information from the NTP server immediately. 3-5.5 Mail Setup The Mail Setup tab controls the email-sending configuration when the IVR needs to send e-mail to specified users.

  • Page 48: 3-5.6 Lan Setup

    3-5.6 LAN Setup Item Description Set the IVR IP address Subnet Mask Set the IVR IP address of Subnet Mask Gateway Enter IVR IP address of the Gateway provided by IVR WAN IP Enter the DNS address provided by ISP. (Note: The correct DNS address must be entered for DDNS function).

  • Page 49: Storage Setup

    3-6 Storage Setup 3-6.1 HDD Setup ※ Click the status bar to change the attributes of the hard disk Item Description Video Preservation Setup the video preservation period. Recorded video will be de- (Hours) leted automatically after expiry of preservation period. Model Display HDD model Status...

  • Page 50: 3-6.2 Usb Flash Derive Setup

    3-6.2 USB Flash Derive Setup Item Description Model Display USB flash drive model Free/Capacity Display USB flash drive capacity (Free/Capacity ) 3-6.3 DVD-RW Setup Item Description Model Display IVR-RW model Media Type Display disk type Free/Capacity Display IVR-RW capacity (Free/Capacity ) User Manual...

  • Page 51: System Setup

    3-7 System Setup Item Description The name of IVR to be shown while users login from remote site. IVR Name Language Specify the OSD language. Video Format Detec- Specify the format of video signal (auto-detect, NTSC, PAL). The tion configuration requires IVR reboot to take effect 3-7.1 Auto Lock Item Description...

  • Page 52: 3-7.3 Date/Time Setup

    3-7.3 Date/Time Setup Item Description Hour Format 12HOURS/ 24HOURS Date Format MM-DD-YY/DD-MM-YY/YY-MM-DD 3-7.3.1 Time zone Item Description Set up the time zone of the IVR, from GMT - 13 ～ GMT+ 13。 Time Zone Setup Daylight Saving Time Enable / Disable Daylight Saving Time User Manual...

  • Page 53: 3-7.3.2 Daylight Saving Time Setup

    3-7.3.2 Daylight Saving Time Setup Item Description Beginning Setup the beginning time of Daylight Saving Time. Ending Setup the ending time of Daylight Saving Time. 3-7.3.3 Change Date and Time Setup date and time of the IVR. User Manual...

  • Page 54: 3-7.4 Monitor Setup

    3-7.4 Monitor Setup This feature is only support "Maya v2" series models. Users have to decide which one is the main screen, which is the second screen. In the setting can be used when there are three configurations. In duplicate mode, both monitors display the same content. In the HDMI (1) VGA (2) mode, HDMI will be the screen 1, VGA will be the screen 2.
  • Page 55 Monitor setup Item Description 1、2 set the main screen (1), the second screen (2) screen display setup menu Resolution selection screen resolution Border Color Set the color of border Luminance Setting brightness, from 0 to 100. Contract Setting screen display color contrast, from 0 to 100. Saturation Setting screen display color saturation from 0 to 100.

  • Page 56: 3-7.5 Input Setup

    3-7.5 Input Setup The Input Setup allows users’ setup input device (Key Tone, Remote control, Panel, Mouse, Keyboard, Touch screen). Item Description Key Tone Enable / Disable Key Tone. 3-7.5.1 Remote Control Setup Item Description Enable Enable / Disable remote control. Default ID is 0.

  • Page 57: 3-7.5.2 Panel Setup

    3-7.5.2 Panel Setup Item Description Test Enable / Disable panel button test function. Press Key Display information of the pressed key. 3-7.5.3 Mouse Setup Item Description Setup the mouse cursor speed. The right side of the slider means Speed faster mouse speed. (Only valid for local configuration) User Manual...

  • Page 58: 3-7.5.5 Touch Screen Setup

    3-7.5.4 PTZ Keyboard Setup Item Description RS-485 ID RS-485 ID, valid values range from 1 to 64 RS-485 Baud rate RS-485 Baud rate from 2400, 4800, 9600, 19200 Keyboard Select PTZ Keyboard Test Enable / Disable keyboard test function Press Key Display press key information 3-7.5.5 Touch Screen Setup Detects the touch screen...

  • Page 59: 3-7.6 Utility Setup

    3-7.6 Utility Setup Item Description Export Configuration Export IVR configuration to a USB flash drive or a remote PC. Import Configuration Import configuration from a USB flash drive or a remote PC to IVR. Reset Configuration Reset system configuration. Export Logs Save IVR system log to a USB flash drive or a remote PC.

  • Page 60: 3-7.6.1 Export Configuration

    3-7.6.1 Export Configuration There are several options for target storage of IVR configuration. a. Export to a USB Flash Drive: The default filename is “IVR.cfg” b. Save *.cfg as PC User Manual...

  • Page 61: 3-7.6.2 Import Configuration

    3-7.6.2 Import Configuration Import configuration to the IVR from a USB drive or a remote computer. a. Import from USB Flash Drive: Import the configuration from a USB flash drive. b. Open *.cfg from PC User Manual...

  • Page 62: 3-7.6.3 Reset Configuration

    3-7.6.3 Reset Configuration Reset the IVR to default settings. 3-7.6.4 Export Logs a. Export to USB Flash Drive: Export logs to a USB flash drive. The default file name is “log.csv” b.Save *.csv as PC User Manual...

  • Page 63: 3-7.6.5 Clear Logs

    3-7.6.5 Clear Logs Clear the system logs. User Manual...

  • Page 64: 3-7.6.6 Upgrade Firmware

    3-7.6.6 Upgrade Firmware Notice! DO NOT TURN OFF POWER OR UNPLUG USB DEVICE DURING THE UPGRADE because that may cause incomplete firmware upgrade and damage the IVR. a. Upgrade from USB Flash Drive...: Choose the firmware from USB flash drive to upgrade b.

  • Page 65: System Information

    3-8 System Information 3-8.1 IVR Information Item Description Model IVR model name and video type Version IVR firmware version 3-8.2 Network Information Item Description IVR IP address If there is no network connection, it will show "Network is not con- nected.

  • Page 66: 3-8.4 S.m.a.r.t Information

    3-8.4 S.M.A.R.T Information User Manual...

  • Page 67: Remote Software Installation And Setup

    REMOTE SOFTWARE INSTALLATION and SETUP The IVR allows users remotely access and control the IVR from a PC by 「iWatchIVR」or IE v6.0 or above. p.s. The IVR currently supports Windows XP SP2 or above and Windows Vista, Windows 7. Application Software Connection Step 1：...
  • Page 68 Step 3 ： Click on the link ” iWatchIVR for Windows XP/Vista/7” to start downloading the AP software. Step 4： The program can be run directly, or save the program to the remote PC and execute later. If you choose to run the software, Start window will be shown up. Please enter information of login IVR: IP, Port, Username and Password.

  • Page 69: Ie Connection

    he drop-down menu can be used to record IP address. Press “Clear” to clear IP address. You’ve logged into the IVR Step 5： 3-10 IE Connection Step 1： Enter the IP address of IVR in IE browser. The address appeared in this image is only for demonstration.
  • Page 70 ” iWatchIVR for Internet Explorer 7/8/9 ”. Step 3： Click on p.s. There will be IE connection security issue when clicking this link for the first time. Please refer to index III for Remote Monitoring IE ActiveX Control Installation Instruction. Step 4：...

  • Page 71: Ap Software And Ie Connection Operation

    3-11 AP Software and IE Connection Operation Table 4-3.1 System Requirements Intel Core 2 Due above Microsoft Windows 7, Windows Vista, Windows XP SP2 above 4G above VGA Card Needed to support DirectX9.0 (Above) Note 1 Anti-virus soft- The TCP destination port 80 should be available. ware (firewall) Others DirectX 9.0 above...
