HELIX VX-399 Installation, Operation & Maintanance Manual

HELIX VX-399 Installation, Operation & Maintanance Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model
VX - 399
GAS BOILER
INSTALLATION, OPERATION &
MAINTENANCE MANUAL
Manufactured by:
ECR International, Inc.
2201 Dwyer Avenue, Utica NY 13501
web site: www.ecrinternational.com
P/N 240010940 Rev. C [09/07/2016]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX-399 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HELIX VX-399

Summary of Contents for HELIX VX-399

  • Page 1 Model VX - 399 GAS BOILER INSTALLATION, OPERATION & MAINTENANCE MANUAL Manufactured by: ECR International, Inc. 2201 Dwyer Avenue, Utica NY 13501 web site: www.ecrinternational.com P/N 240010940 Rev. C [09/07/2016]...

  • Page 2: Safety Relief Valve ¾" 2

    VERIFY CONTENTS RECEIVED Description Illustration Item Fully Assembled Boiler *Safety Relief Valve ¾" Elbow ¾" 90° ¾" Close Nipple **Temperature Pressure Gauge 2" Shank Nipple 1¼" Close (1) Bushing ¾" x ¼" Bushing 1¼" x ¾" (2) 11" x 17" Page for critical installation issues. Critical Installation Instruction Document Package Includes essential documents.

  • Page 3: Overall Dimensions

    OVERALL DIMENSIONS FRONT LEFT SIDE RIGHTSIDE OF BOILER OF BOILER OF BOILER BACK OF BOILER Table 1 : Model 399 - Physical Data Location Inches Width 27 ⅛ Height - Unit only 1320 Depth 21 ⅛ Height unit w/ Optional Kit L-4006 66 ¼...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS 1 - Introduction ..........................5 2 - Important Safety Information ....................6 3 - Component Listing ........................7 4 - Locating Boiler ......................... 10 5 - Hydronic Piping ........................11 5.2 Special Conditions ......................... 11 5.3 Safety Relief Valve and Air Vent ....................11 5.4 Trim Piping ...........................

  • Page 5: Introduction

    1 - INTRODUCTION 1.1 Designated Use • Hot water heating boiler. • Indoor installation. • Closet or alcove installation. • Direct vent or single vent pipe boiler. • For use with natural gas or liquefied petroleum gases (LP/propane). 1.2 The unit MUST NOT: •...

  • Page 6: Important Safety Information

    2 - IMPORTANT SAFETY INFORMATION 2.1 General 2.3 Installation shall conform to requirements of authority having jurisdiction or in absence of such Boiler installation shall be completed by qualified agency. requirements: See glossary for additional information. • United States WARNING •...

  • Page 7: Component Listing

    3 - COMPONENT LISTING FIGURE 3-1 Boiler Components (Viewed from Left side of Boiler) NOTE: See Section 5-3 Supply Water To Heating System For Safety Relief Limit Control (Optional) Valve Piping Safety Relief Valve Instructions Controls Tree Combustion Air Inlet Temperature Pressure Gauge Vent Connector Return Water From...
  • Page 8 3 - COMPONENT LISTING 3.1 Component Listing - Refer to diagrams on following pages. Temperature Pressure Gauge (Field Installed) Combustion Air Inlet (4") See section 6. User Interface - Displays information regarding Vent Connector (4") See section 6. boiler condition. Allows adjustment of boiler operating parameters.
  • Page 9 3 - COMPONENT LISTING FIGURE 3-3 Boiler Components 399 MBH (View from Front of Boiler) As seen on front cover Supply Water To Heating System Combustion Air Inlet Limit Control Combustion Air Controls Tree (Optional) Test Port Vent Connector Safety Relief Valve (Rear) Flue Gas Test Port Temperature Pressure...

  • Page 10: Locating Boiler

    4 - LOCATING BOILER 4.1 Boiler Location Considerations FIGURE 4-1 Clearance to Combustible Materials • Ambient room temperature always above 32°F (0°C) to prevent freezing of liquid condensate. • Approved for installation in closets and on combustible floors. Do not install boiler on carpeting. •...

  • Page 11: Hydronic Piping

    5 - HYDRONIC PIPING 5.1 General WARNING • Install piping in accordance with authority having • Poison hazard. Ethylene glycol is toxic. Do not jurisdiction. use ethylene glycol. NOTICE • Never use automotive or standard glycol Use two (2) wrenches when tightening boiler's antifreeze, even ethylene glycol made for fitting and pipes.

  • Page 12: Trim Piping

    5 - HYDRONIC PIPING • Use pipe suitable for temperatures of 375°F (191°C) WARNING or greater. Burn and scald hazard. Safety relief valve could • Individual boiler discharge piping shall be independent discharge steam or hot water during operation. of other discharge piping. Install discharge piping per these instructions.
  • Page 13 5 - HYDRONIC PIPING Piping Legend NOTICE Illustrations are meant to show system piping concept only. Installer is responsible for all equipment and detailing required by authority having jurisdiction. NOTICE Arrange piping to prevent water dripping onto boiler. See Table 3 for primary general pump sizing. Primary circuit pipe components must also be included to size pump.
  • Page 14 5 - HYDRONIC PIPING FIGURE 5-5 Single Boiler Primary/Secondary Two-Pipe Zoned System With Zone Valves Pump General CH/System Boiler Pump Pump on Return Side Limit length to 5' (1.6m) 12"(305mm) Maximum separation FIGURE 5-6 Single Boiler Primary/Secondary Two-Pipe Zoned System With Zone Pumps Pump General Boiler Pump...
  • Page 15 5 - HYDRONIC PIPING FIGURE 5-7A Single Boiler Using Primary/Secondary Pumping CH/System Pump General Boiler Pump on Return Side Limit length to 5' (1.6m) 12"(305mm) Maximum separation FIGURE 5-7B Single Boiler Using Primary/Secondary Pumping With DHW Tank Heating Load Heating Load Primary Loop Equivalent Length Calculation &...
  • Page 16 5 - HYDRONIC PIPING FIGURE 5-8A Multiple Boiler Primary/Secondary Two Pipe Zoned System With Zone Valves - (See Multiple Boiler Guide) Pump CH/System Pump System Temperature Size common piping Sensor per maximum heat capacity of entire system General Boiler Pumps on Return Side Limit length...
  • Page 17 5 - HYDRONIC PIPING FIGURE 5-8B Multiple Boilers Using Primary/Secondary Pumping Heating Load Heating Load Heating Load System Pump Size common piping System per maximum heat capacity of entire Temperature system Sensor General Boiler Pumps on Return Side Up to 16 Limit length to 5' (1.6m) boilers...
  • Page 18 5 - HYDRONIC PIPING 5-8C Multiple Boilers Using Primary/Secondary Pumping with DHW Tank Heating Load Heating Load Heating Load CH/System System Pump Temperature Sensor Size Common Piping Per Maximum Heat Capacity Of Entire System General Boiler Pumps on Return Side Limit length to 5' (1.6m) 12"(305mm)

  • Page 19: Combustion Air And Vent Piping

    6 - COMBUSTION AIR AND VENT PIPING 6.1 General • Any improper operation of common venting system should be corrected so installation conforms with National This boiler requires a dedicated direct vent system. Fuel Code, ANSI Z223.1/NFPA 54 and/or Natural Gas Install combustion air and vent piping in accordance and Propane Installation Code, CAN/CSA B149.1.

  • Page 20: Vent Pipe Installation

    6 - COMBUSTION AIR AND VENT PIPING 6.4 Vent Pipe Installation plastic vent pipe from vent connector must be readily accessible for visual inspection. • Minimum and maximum combustion air and vent pipe lengths listed in Table 5. Pipe length counted from combustion air connector to termination.
  • Page 21 6 - COMBUSTION AIR AND VENT PIPING 6.6 Venting Configurations NOTICE Various venting configurations can be applied to this boiler. Use of vent covers may cause freezing. If using For guidance see Venting Configuration Table 7A and vent covers overall vent length must be considered. corresponding Figure.
  • Page 22 6 - COMBUSTION AIR AND VENT PIPING FIGURE 6-1 Two Pipe Roof Vent 12" (205mm) Min. horizontal  12" (205mm) Min. separation between combustion air intake and vent of same appliance. 12" (305mm) Min. 15" 12" (205mm) Min. or greater separation (381mm) ...
  • Page 23 6 - COMBUSTION AIR AND VENT PIPING FIGURE 6-4 Side Wall Concentric Terminal FIGURE 6-5 Side Wall Concentric Terminal Multiple Appliances Roof 1"(2.54cm) 1" (25mm) Overhang Maximum 1" (25.4mm) Max. Max. 12" (305mm) Min. * See Note 36" (457mm) Min. Below Vent Maintain 12"...
  • Page 24 6 - COMBUSTION AIR AND VENT PIPING FIGURE 6-7 Concentric Roof Terminal Vent  Glue inner vent pipe to prevent Maintain 12"(305mm) US recirculation. (18"(457mm) Canada) clearance above highest  Maintain 12" (305mm) US anticipated snow level 24" (18"(457mm) Canada) minimum Combustion Air (610mm) above roof clearance above highest...
  • Page 25 6 - COMBUSTION AIR AND VENT PIPING FIGURE 6-10 Flue on Sidewall, Combustion Air on Roof FIGURE 6-12 Two Pipe Side Wall with 45° Vent Maintain 12"(305mm) US (18"(457mm) Canada) clearance above highest Combustion anticipated snow level 24" Vent (610mm) above roof 45°...

  • Page 26: Venting Configurations

    6 - COMBUSTION AIR AND VENT PIPING 6.7 Side Venting Terminal Requirements of • USA - National Fuel Gas Code, ANSI 223.1/NFPA 54. • Canada - Natural Gas and Propane Installation Code, CAN/CSA B149.1 Venting terminal from doors and windows See figure 6-12 Venting terminal from forced air inlet of other appliances See figure 6-13...
  • Page 27 6 - COMBUSTION AIR AND VENT PIPING FIGURE 6-15 Keep vent termination 3’ minimum Vegetation, (0.9m) away from vegetation. Position Plants & termination where vent vapors will not Shrubs damage plants/shrubs or air conditioning equipment. Termination Vent termination US only - 4’ (1.2m), Meters, Canada - 6' (1.8m) horizontally from, Regulators,...

  • Page 28: Multiple Boiler Venting Installation

    6 - COMBUSTION AIR AND VENT PIPING 6.8 Multiple Boiler Venting Installation FIGURE 6-17 Condensate Piping • Multiple boiler application boiler shall be vented individually. • Follow guidelines as described in Figure 6-1 through 6-7. • Plastic vent pipe from vent connector must be readily accessible for visual inspection.

  • Page 29: Gas Supply Piping

    7 - GAS SUPPLY PIPING FIGURE 7-1 Gas Connection (at top of Boiler) CAUTION WHAT TO DO IF YOU SMELL GAS Gas Connection Top of Boiler • Do not try to light any appliance. 1"NPT • Do not touch any electrical switch; do not use any phone in your building.
  • Page 30 7 - GAS SUPPLY PIPING FIGURE 7-2 Manual Gas Shutoff Valve - Inside Boiler DANGER Jacket Fire Hazard. Do not use matches, candles, open flames, or other methods providing ignition source. Gas Valve Failure to comply will result in death or serious injury.

  • Page 31: Electrical Connections

    8 - ELECTRICAL CONNECTIONS 8.1 General WARNING Electrically bond boiler to ground in accordance with Electrical shock hazard. Turn OFF electrical power requirements of authority having jurisdiction. Refer to: supply at service panel before making electrical • USA- National Electrical Code, ANSI/NFPA 70. connections.
  • Page 32 8 - ELECTRICAL CONNECTIONS NOTICE NOTICE IMPORTANT: Do not apply power to DHW T-T Use dry contact for wires to CH T-T terminal and terminals. Dry contact only, use of isolation relay DHW T-T terminal. E33 error code is displayed if may be necessary.

  • Page 33: Start Up Procedure

    9 - START UP PROCEDURE 9.1 Fill Boiler With Water And Purge Air NOTICE NOTICE IMPORTANT: Condensate trap must be manually filled with water at initial start up. To maintain boiler efficiency and prevent boiling inside the heat exchanger, flush entire heating FIGURE 9-1 Condensate Drain Assembly - Option may system until clean.
  • Page 34 9 - START UP PROCEDURE 9.3 Program Boiler Control FIGURE 9 -2 User Interface Description - Manual Lockout Reset - Enter/Exit user menu - Go to previous screen - Select a menu item - Confirm new parameter value - Scroll up to next menu item - Increase value - Scroll down to next menu item - Decrease value...
  • Page 35 9 - START UP PROCEDURE For Propane (LP): 9.4 Boiler Start-up and Operational Test Verify air is purged from hydronic piping 9160 x cu ft Input (MBH) System test pumps - verify each pump is seconds operational using vibration, noise and amp draw. For Metric formulas- See Glossary Verify gas piping •...
  • Page 36 9 - START UP PROCEDURE FIGURE 9-3 Throttle Screw Location - 399 MBH WARNING Fire, explosion, asphyxiation and electrical shock hazard. Read this instruction and understand all requirements, including requirements of authority having jurisdiction before making adjustments. Failure to follow these instructions could result in death or serious injury.
  • Page 37 9 - START UP PROCEDURE FIGURE 9-4 Offset Screw Location - 399 MBH LOW fire combustion - 399 MBH Flame signal Design μA Target Natural 8.8% 9.2% 9.0% <100ppm >4.5 Propane 9.8% 10.5% 10.0% See Figure 9-4 for location of Offset Screw on modulating gas valve of various boiler models.

  • Page 38: Perform Csd-1 Compliance Test

    9 - START UP PROCEDURE 9.7 Perform CSD-1 Compliance Test (see WARNING paragraph 2.4 page 6) Asphyxiation hazard. Carbon monoxide is odorless, Verify operation of boiler safety control operation with tasteless, clear colorless gas, which is highly toxic. regard to no flow conditions as follows: Verify cap is firmly placed on combustion analyzer Turn off boiler using boiler service switch.

  • Page 39: Complete Start Up Procedure

    9 - START UP PROCEDURE 9.8 Complete Start Up Procedure FIGURE 9-7 Control Module J7 Connector Reset control parameters to operating settings if adjusted to allow startup and operation test. Follow instructions TO TURN OFF GAS TO APPLIANCE (page 41) if boiler is not being placed into immediate operation.

  • Page 40: Operating Instructions

    10 - OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE OPERATING CAUTION WARNING WHAT TO DO IF YOU SMELL GAS If you do not follow these instructions • Do not try to light any appliance. exactly, a fire or explosion may result •...

  • Page 41: General Maintenance And Cleaning

    11 - GENERAL MAINTENANCE AND CLEANING 11.1 Beginning of Each Heating Season DANGER • Check boiler area is free from combustible materials, Before servicing, turn off electrical power to boiler gasoline, and other flammable vapors and liquids. at service switch. Close manual gas valve to turn •...
  • Page 42 11 - GENERAL MAINTENANCE AND CLEANING 11.2 Annual Shut Down Procedure Figure 11-2 Condensate Trap (Left Side Shown) • Follow instructions “To Turn Off Gas To Appliance” unless boiler is also used to supply domestic hot water. See section 10. •...

  • Page 43: Ratings And Capacities

    12 - RATINGS AND CAPACITIES Table 13 - Sea Level Ratings SEA LEVEL RATINGS NATURAL AND PROPANE GASES GROSS Net AHRI Thermal Boiler Input Rate (MBH) Size OUTPUT Rating, Water Efficiency (MBH) (MBH) (1)(2) (1)(3) Maximum Minimum 96.0 1000 Btu/hr (British Thermal Units Per Hour) Gross Output and Thermal Efficiency is based on DOE (Department of Energy) test procedures.
  • Page 44 13 - TROUBLE SHOOTING If boiler does not function. Remove Jacket. Is User Interface lit? Check for 120 vac in boiler high Does display show "Standby - No voltage terminal box. Demand? Is 120 vac present? Locate fuse holder on front of Check power supply to There is no call for control and pull to check fuse.
  • Page 45 13 - TROUBLE SHOOTING Go to Page For Screen Display Explanation Troubleshooting Control has blocking error for more than 20 Go to Page 47 hours in a row. Thirty five unsuccessful ignition attempts in a Go to Page 48 Open gas valve power circuit. May involve high temperature switch, gas valve, or gas Go to Page 47 valve relay in control module.
  • Page 46 13 - TROUBLE SHOOTING Go to Page For Screen Display Explanation Troubleshooting Low water cutoff sees no water. Go to Page 53 Flue temperature sensor sees temperature Go to Page 54 B l o c k i n g E r r o r E 39 higher than 200°F.
  • Page 47 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 48 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 49 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 50 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 51 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 52 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 53 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 54 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 55 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 56 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 57 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 58 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 59 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...
  • Page 60 13 - TROUBLE SHOOTING P/N 240010943, Rev. C [09/07/2016]...

  • Page 61: Trouble Shooting (Temperature Resistance Chart)

    13 - TROUBLE SHOOTING Thermistor Resistance Chart Temperature Temperature Resistance °C °F 36100 28590 22790 18290 14770 12000 9805 8055 6653 5524 4809 3863 3253 2752 2337 1994 1707 1467 1265 1095 P/N 240010943, Rev. C [09/07/2016]...

  • Page 62: Wiring Diagram

    14 - WIRING DIAGRAM 14.3 Connection Diagram - 399 MBH P/N 240010943, Rev. C [09/07/2016]...
  • Page 63 14 - WIRING DIAGRAM 14.4 Schematic Diagram of Ladder Form - 399 MBH P/N 240010943, Rev. C [09/07/2016]...

  • Page 64: Glossary

    15 - GLOSSARY • ANSI - American National Standards Institute, Inc. • GAS PIPE SIZES - Size pipe per NFPA-54. oversees creation and maintenance of voluntary • HIGH-VOLTAGE - Circuit involving potential of not consensus standards, including ANSI Z21.13/CSA 4.9: more than 600 volts and having circuit characteristics in Gas-Fired Low Pressure Steam and Hot Water Boilers.
  • Page 65 15 - GLOSSARY • SAFETY RELIEF VALVE - Valve designed to relieve pressure in hot water supply system when pressure exceeds pressure capability of equipment. • SAFETY SHUTOFF DEVICE - Device that will shut off gas supply to controlled burner in event source of ignition fails.

  • Page 66: Appendix A - Control Module

    APPENDIX A - CONTROL MODULE 1.1 Introduction Operation with LCD character display module Boiler is equipped with programmable electronic control and user interface module. 1.2 Operation • Display: 4 x 20 character LCD screen to show boiler status. • Function Keys Description - Manual Lockout Reset - Enter/Exit user menu...

  • Page 67: Sequence Of Operation

    APPENDIX A - CONTROL MODULE 1.4 Sequence of Operation Operational State User Interface Display Explanation Boiler operates in standby mode until demand for Central Heat (CH) Heat or Domestic Hot Water (DHW) is Demand? detected. CH or DHW pump is turned on based on type of heating demand.
  • Page 68 APPENDIX A - CONTROL MODULE 1.4 Sequence of Operation Operational State User Interface Display Explanation After 2 seconds If flame detected before Gas Valve opens during ignition boiler will lockout. Lockout Flame Error A21 Detected? Please refer to troubleshooting guide. Note: Lockout A01 after allowed...

  • Page 69: User Menu

    APPENDIX A - CONTROL MODULE 1.5 User Menu Explanation User Interface Display Boiler operates in standby mode until demand for Central Heat (CH) or Domestic Hot Water (DHW) is detected. User Menu (Press Menu button on user interface to access User Menu) User Menu structure includes: •...
  • Page 70 APPENDIX A - CONTROL MODULE Explanation User Interface Display Adjust CH set point to hydronic system design while in Operating in CH Mode = 0 (CH with Thermostat) or 3 (Permanent Demand). In CH Mode = 1 (CH with Thermostat and Outdoor Reset) or 2 (CH with Full Outdoor Reset).
  • Page 71 APPENDIX A - CONTROL MODULE Explanation User Interface Display Installer Menu Installer Menu structure includes: • User 'Menu' can be accessed by pressing 'Menu' key on user interface. • Installer 'Menu' can be accessed by first pressing and holding the 'Enter' key continue to hold and at the same time press and hold the 'Menu’...
  • Page 72 APPENDIX A - CONTROL MODULE Explanation User Interface Display Installer Menu Control module logs successful and failed ignition attempts. Information accessed in ‘Ignition Attempts’ Screen as shown. Ignition attempts are stored in non-volatile memory and are retained in event of power failure. Figure A-1 Typical Ignition Cycle Following control features are implemented to ensure safe and reliable operation of Combustion System:...
  • Page 73 APPENDIX A - CONTROL MODULE Explanation User Interface Display Boiler stores information regarding total CH and DHW run time in hours. Data stored in non-volatile memory and retained in event of power failure. Boiler logs last 16 blocking errors and 16 lockout errors in non-volatile memory.
  • Page 74 APPENDIX A - CONTROL MODULE Explanation User Interface Display Two pump modes are available: Pump Mode = 0 ‘CH or CH&DHW’ • In this mode either CH or DHW pump terminal is energized depending on type of demand (CH or DHW). •...
  • Page 75 APPENDIX A - CONTROL MODULE Explanation User Interface Display 4. Central Heating (CH) modes available: • CH Mode = 0 ‘CH with Thermostat’ • Boiler will attempt to satisfy CH demand while CH thermostat input is closed. • Boiler will modulate its firing rate to maintain CH set point and match system heat load.
  • Page 76 APPENDIX A - CONTROL MODULE Explanation User Interface Display If outdoor temperature is greater than Warm Weather Shutdown Temperature, demand for CH blocked and pumps stopped. Allowed Range: 35°F to 100°F (2°C to 38°C) Default Setting: 70°F (21°C) Boiler capable of operating in Outdoor Reset Mode when included Outdoor Sensor is connected and proper CH Mode selected.
  • Page 77 APPENDIX A - CONTROL MODULE Explanation User Interface Display Outdoor reset boost function increases CH set point by increment (‘Temp’) if CH demand continues beyond pre-set time limit (‘Time’). CH set point will continue to increase until set point reaches 195°F / 91°C Allowable Temperature Increment: 0..36 °F (0..20 °C) Default Temperature increment:...
  • Page 78 APPENDIX A - CONTROL MODULE Explanation User Interface Display Maximum time boiler operates in DHW mode limited by DHW Maximum Priority Time Setting. Priority timer starts when both CH and DHW demand is present. Boiler will switch from DHW back to CH operation after Maximum Priority Time has elapsed.

  • Page 79: Optional User Interface Relocation

    399 MBH - PRIMARY LOOP EQUIVALENT LENGTH CALCULATION & PUMP SELECTION For 399MBH Boiler (This boiler must be piped with a primary loop) These charts are valid for piping diagrams on pages 14 & 18 Instructions: Pipe diameter determines pump size. Smaller the diameter of pipe, larger the pump. 399 Mbh boiler can be piped in 1¼"...

  • Page 80: Primary Loop Equivalent Length Calculations & Pump Selection

    399 MBH - PRIMARY LOOP EQUIVALENT LENGTH CALCULATION & PUMP SELECTION Chart 2 Equivalent Length Enter Number of Pipe Diameter Fitting Multiply By Fittings A x B 90° Elbow 45° Elbow 1½" Tee-branch (Any pipe/fitting larger than 1½", Tee-through count as 1½") Swing check valve 12.5 Lift check valve...
  • Page 81 P/N 240010943, Rev. C [09/07/2016]...
  • Page 82 DUNKIRK BOILERS 2201 Dwyer Avenue, Utica NY 13501 web site: www.ecrinternational.com...
