Document Reference
Viq601a.doc
Videoswitch
Ocean House, Redfields Industrial Park
Redfields Lane, Church Crookham
Hants GU52 0RD
Video Processor
User Manual
Product ranges covered by this manual
Vi-P14
Vi-P14A
Date
26/11/2009
Telephone
Fax
Email
Web
Vi-Q4C1
Firmware
From Viq001a21
01252-851510
01252-851296
sales@videoswitch.co.uk
www.videoswitch.co.uk
Advertisement
Table of Contents
Related Manuals for Videoswitch Vi-P14
Summary of Contents for Videoswitch Vi-P14
-
Page 1: User Manual
Video Processor User Manual Product ranges covered by this manual Vi-P14 Vi-Q4C1 Vi-P14A Document Reference Date Firmware Viq601a.doc 26/11/2009 From Viq001a21 Videoswitch Telephone 01252-851510 Ocean House, Redfields Industrial Park 01252-851296 Redfields Lane, Church Crookham Email sales@videoswitch.co.uk Hants GU52 0RD www.videoswitch.co.uk... - Page 2 Viq601a.doc...
-
Page 3: Table Of Contents
Remote Keyboard (lower connector) ................12 5.1.2 Alarms (upper connector) ....................12 Specifications ........................13 5.2.1 Vi-P14 Screen Modes ......................13 5.2.2 Vi-P14A Additional Screen Modes...................13 5.2.3 Vi-Q4C1 Screen Modes ....................13 5.2.4 Video Processing ......................13... - Page 4 Video Processor 5.2.9 CE Marking ........................16 5.2.10 Ventilation ........................16 5.2.11 Safety..........................16...
-
Page 5: Start Here
Each video input can be scaled, cropped, mirrored, positioned and then combined on the analogue video output • A VGA output is provided on the Vi-P14 and Vi-P14A for driving any VGA enabled monitor or TV • Menus allow the user to configure the unit •... -
Page 6: Connecting Up
Connect the mains power using the mains cable provided Keypad The Vi-P14 and Vi-P14A have a mini-keypad with the key layout as above. All functions can be controlled by the 16 keys provided. Two additional functions are provided by holding... - Page 7 Video Processor Names of keys used Keypad legend Used for in this manual Select cameras and enter number numbers when in the menu Select next screen format, right navigate in menu Select prior screen format, left navigate in menu Select next input for spot monitor, navigate in menu Select prior input for spot down...
-
Page 8: Front Panel
Video Processor 2 Front Panel The Vi-Q4C1 has a front panel with LEDs to indicate important status information. Note that this model requires a PC or Vi-K1 Remote Keyboard to access the menus or change screen modes. Leds Video Inputs 1,2,3,4 The green video input LEDs illuminate when video is present on the corresponding camera inputs Alarm... -
Page 9: Menus
Video Processor Menus • The menu system in this Video Processor allows many aspects of it operation to be customised to suit a specific installation • Note that not all menus options described below are available on some models • The factory defaults may be restored at any time via the CONFIGURATION menu The keys listed below refer to the built-in keypad. -
Page 10: Login
Video Processor Login Some parts of the menu are password protected. Enter the password here to gain access to the menu. • Use left and right to move the cursor • Use up and down to select the digits • Use left or ESC to exit this menu item A message on the screen will indicate if you have logged in successfully. -
Page 11: Display
Video Processor Display 3.3.1 Format Prior to editing image positions of title positions, select the screen format that you wish to edit. 3.3.2 Image Positions • Use the number keys 1, 2, 3 and 4 to select the camera for which you wish to adjust the image position. -
Page 12: Selectable Formats
Video Processor • Use the number keys 9 and 0 to select the Date/Time and Unit title • Use the up, down, left and right keys to move the selected title to the desired location on the screen. • Note that the down key moves the title down by 8 steps whilst up moves it up by just 1 step. -
Page 13: Camera1 Title
Video Processor • Use DEFAULT to default or clear the title 3.3.7.2 Camera1 Title Each camera may be given a title that is displayed on the screen whenever that camera image is displayed. • Use left and right to move the cursor •... -
Page 14: Config
Video Processor CONFIG 3.5.1 Lock Keypad If you do not want the user to be able to select screen formats or cameras, set this option to YES. To change screen format you now have to enter menu, enter password and change the screen format in the Format menu. -
Page 15: Connections
Video Processor 4 Connections This shows a typical example of the video and power connections required. The spot monitor is optional. The second row of BNC connectors may be used for loop-through. -
Page 16: Technical Data
Video Processor 5 Technical Data 5.1.1 Remote Keyboard (lower connector) Physical: RJ45 PIN1 PIN8 Electrical: RS485 Pin Number Signal RS485 Input+ (A) RS485 Input- (B) RS485 Output+ (A) +9V output for Keyboard RS485 Output- (B) Not used Not used 5.1.2 Alarms (upper connector) Physical: RJ45... -
Page 17: Specifications
Video Processor Specifications 5.2.1 Vi-P14 Screen Modes The vertical and horizontal splits provide both cropped and squished options. 5.2.2 Vi-P14A Additional Screen Modes All screen modes are fully programmable and may be edited by the user via the keypad or using the Vi-SA1 Configuration Manager software. -
Page 18: Display
Video Processor Resolution 720 x 576 pixels x 16.8 million colours Hardware/Software Embedded processor, proprietary Videoswitch software Simultaneous processing Scaling, cropping, pan, Video inputs 0.5 to 1V pk-pk, 75 Ohms (switch able via menu), composite PAL (BNC), all inputs have loop-through BNCs... - Page 19 Video Processor Firmware upgrades Firmware upgrades will be made available on the Internet (free of charge)
-
Page 20: Ce Marking
Video Processor 5.2.9 CE Marking This product is CE marked. It has been fully tested and complies with 89/336/EEC Electromagnetic Compatibility and 73/23/EEC Low Voltage directives, and with EN 60950:2000 safety standards. Warning: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. - Page 21 Video Processor Serial Number of Video Processor Notes Notes Date Purchased Purchased From Fax to: 01252-851296 Or Send to: Videoswitch, Ocean House, Redfields Industrial Park, Redfields Lane Church Crookham, Fleet, Hants GU52 0RD...
