  • Page 1 PROFESSIONAL MOVING HEAD USER MANUAL WALLY LPAR21 KEEP THIS MANUAL FOR FUTURE NEEDS...
  • Page 2 Thank you for your patronage. We are confident that our excellent products and service can satisfy you. For your own safety, please read this user manual carefully before installing the device. Every person involved with the installation, operation and maintenance of this device has to - be qualified - follow the instructions of this manual...

  • Page 3: Description Of The Device

    Belows are the optional accessories, please purchase from your local dealer if needed 1.Barn-door 2.Frost filter Please check carefully that there is no damage caused by transportation. Should there be any, consult your dealer and don’t install this device. DESCRIPTION OF THE DEVICE Features •...
  • Page 4 Overview (1) Housing (2) LEDS (3) Floor-stand (4) Menu-button (5) Up-button (6) Down-button (7) Enter-button (8) Power input (9) DMX output (10) DMX-input XM340-V1.2 - A...

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS This device has left the factory in perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.

  • Page 6: General Guidelines

    before cleaning it. Only handle the power cord by the plug. Never pull out the plug by tugging the power cord. During initial start-up some smoke or smell may arise. This is a normal process and does not necessarily mean that the device is defective, it should decrease gradually.
  • Page 7 This fixture is only allowed to be operated with the max alternating current which stated in the technical specifications in the last page of this manual, the device was designed for indoor use only. Lighting effects are not designed for permanent operation. Consistent operation breaks may ensure that the device will serve you for a long time without defects.

  • Page 8: Installation Instructions

    INSTALLATION INSTRUCTIONS Mounting the device The applicable temperature for the lignting is between -25°C to 45°C. Do not use the lighting under or above the temperature. The installation of the effect has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation.
  • Page 9 Cautions: The effect should be installed outside areas where persons may reach it, walk by or be seated. Overhead mounting requires extensive experience, including amongst others calculating working load limits, installation material being used, and periodic safety inspection of all installation material and the device. If you lack these qualifications, do not attempt the installation yourself.

  • Page 10: Overhead Rigging

    Overhead rigging Screw the bolt of the clamp into the hold of the bracket, and tighten the screw underneath. Pull the safety-rope through the holes on the bracket of the base and over the trussing system or a safe fixation spot. Insert the end in the carabine and tighten the safety screw.

  • Page 11: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise.
  • Page 12 VALU A001~AXXX (AXXX) DMX address setting SLAV ON/OFF (SLAV) Slave setting ADDR Change DMX address EBOC ON/OFF via external controller ALON (AU-A) Automatic Run in Stand Alone AUTO MAST (AU-M) Automatic Run as Master MODE Sound-controlled Run ALON (SO-A) in Stand Alone SOUN MAST (SO-M) Sound-controlled Run as Master...
  • Page 13 Main functions: - Main menu 0 1. Press [MENU] to enter the main menu "MODE" (display flashing) 2. Press [ENTER] and select "ADDR", “RUN” or "DISP" by pressing [UP] or [DOWN] button. 3. Press [ENTER] for selecting the desired sub menu. - DMX address setting, Slave setting - DMX address setting With this function, you can adjust the desired DMX-address via the Control Board.
  • Page 14 3. Press [ENTER] to confirm or pressing [MENU] to return to main menu. - Slave setting With this function, you can define the device as slave. 1. Select “SLAV” by pressing [UP] or [DOWN] button. 2. Press [ENTER], the display shows “ON” or “OFF”. 3.
  • Page 15 Step-Time or sound-controlled (SOUN). The selection "ALON" means Stand Alone-mode and "MAST" that the device is defined as master. 1. Select "AUTO" or "SOUN" by pressing [UP] or [DOWN] button. Press [ENTER] for selecting the desired extension menu. Select "ALON" or "MAST" by pressing [UP] or [DOWN] button. Press [ENTER] to confirm or Press [MENU] to return to the main menu.
  • Page 16 will be displayed. Press [UP] or [DOWN] button in order to select the desired channel. If you select “D-12” the display will only show the DMX-value of the 12 channel. 4. Press [ENTER] to confirm or Press [MENU] to return to the main menu. 5.
  • Page 17 - Main menu 1 1. Press [MENU] to enter the main menu (display flashing). 2. Press [UP] or [DOWN] button. to select “SET”. - Mic sensitivity With this function you can adjust the sensitivity of the microphone. 1. Select “MIC” by pressing [UP] or [DOWN] button. Press [ENTER], the display shows “M-XX”, “XX”...
  • Page 18 1. Select “AUTO” by pressing [UP] or [DOWN] button. 2. Press [ENTER], the display shows “CLOS”, “HOLD”, “AUTO” or “AUDI”. 3. Press [UP] or [DOWN] button to select “CLOS”, “HOLD”, “AUTO” or “AUDI”, the default is “HOLD”. 4. Press [ENTER] to confirm or Press [MENU] to return to the main menu. - Fan’s mode select With this function you can select the Fan’s mode.
  • Page 19 number, such as the display may also show,"V-1.0","V-9.9"etc. 3. Press [ENTER] to confirm or Press [MENU] to return to the main menu. - Main menu 2 1. Press [MENU] to enter the main menu (display flashing). 2. Press [UP] or [DOWN] button to select “ADJU”. - Test function of each channel With this function you can test each channel on its (correct) function.
  • Page 20 1. Press [MENU] to enter the main menu (display flashing). 2. Press [UP] or [DOWN] button to select “TIME”. - Fixture running time With this function you can display the running time of the device. 1. Select “MATI” by pressing [UP] or [DOWN] button. 2.
  • Page 21 - Main menu 4 1. Press [MENU] to enter the main menu (display flashing). 2. Press [UP] or [DOWN] button to select “EDIT”. - Define the number of steps in Run With this function you can define the number of steps in the Program Run.
  • Page 22 Press [ENTER], the display shows “RE.XX”, “XX” stands for the number from 1 to 400. Press [ENTER] to confirm or Press [MENU] to return to the main menu. - Editing the channels of the individual scenes With this function you can edit the program to be called up in Run. Notation: In the scene "SC01-SC48", the before 16 scenes are defaulted to the presupposed scenes, the specific colors as follows: Order...
  • Page 23 a) Editing via the Control Board 1. Select “SC01” by pressing [UP] or [DOWN] button. 2. Press [ENTER], the display shows “SCXX”, “X” stands for the scene no. to be edited. 3. Change the scene no. by pressing [UP] or [DOWN] button. 4.
  • Page 24 b) Editing via the external controller Call up the first scene in your controller now. 1. Select “SC01” by pressing [UP] or [DOWN] button. 2. Press [ENTER], the display shows “SC01”. 3. Press [ENTER], the display shows “C-01”. 4. Select "CNIN" by pressing [UP] or [DOWN] button. 5.
  • Page 25 2: INSTRUCTIONS ON USE: DMX channel´s functions and their values (7 DMX channels): Mode/Channel Value Function 4CH 7CH Rainbow: 0-10 No function 11-220 Rainbow colours 221-255 Crossfading colours from slow to fast Red : 0-255 Red ( 0-Black , 255-100% Red ) Green: 0-255 Green ( 0-Black , 255-100% Green )
  • Page 26 100-119 Internal program 1 120-139 Internal program 2 140-159 Internal program 3 160-179 Internal program 4 180-199 Internal program 5 200-219 Internal program 6 220-239 Internal program 7 240-255 Internal program 8 Instructions for installing the barn-door and frost filter: For this device, the barn door and the frost filter can be installed separately or together.

  • Page 27: Cleaning And Maintenance

    CLEANING AND MAINTENANCE We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use alcohol or solvents! There are no servicable parts inside the device. Maintenance and service operations are only to be carried out by authorized dealers. Should you need any spare parts, please use genuine parts.
