Operating Instructions This unit is for the use in Japan only. Table of contents Getting Started Checking the package contents ......116 Choosing the location for the base phone ..... 116 Transmission range of the handset ......116 Preparations .............. 117 Identifying the parts ..........
α -ALPHA5Lite application form α -ALPHA5Lite user's guide x Warranty x Sony information center address list Choosing the location for the base phone • Where you place the base phone affects the reception quality of the handset. Be sure to place the base phone: –...
Preparations Connecting the base phone Connect the base phone to the telephone outlet and to an AC outlet. Receiver click Antenna Receiver cord to an AC outlet (AC 100V) click to a telephone to DC IN 9V outlet to the telephone line jack Telephone line cord click AC power adaptor...
Page 118
Choosing the dialing mode Preparations (continued) This unit automatically selects the appropriate Setting the date and time dialing mode (tone or pulse) for your telephone line. However, if the call cannot connect , follow the steps below to select an appropriate dialing mode. Use the buttons on the base phone.
10 hours of charging, the usable life of the battery has expired and the battery pack must be replaced. Contact your local Sony dealer or service center and ask for a Sony BP-T50 rechargeable battery pack. We recommend you return the handset to the charger for charging after every use.
Identifying the parts The following illustrations are those of the black Base phone model. message in use nanotteru transfer intercom/ nanotteru/ name ask redial call priority message speed dial transfer message play/stop ringer/handset speaker volume three flash/program four five hold/erase on hook seven eight...
Page 121
1 redial button qh hold/erase button Redials the last number called. Used to hold a call and to erase recorded messages. 2 intercom/name ask button qj on hook button (green) Used to make an intercom call. Used also to have the phone answer incoming calls with a message Used to make a call without picking up the that asks the caller to give his/her name.
Identifying the parts (continued) Handset The following illustrations are those of the black model. Display window data receive redial directory in use/charge talk tone/fee morning call play/ flash intercom call priority handset hold/erase program priority Handset charger...
Page 123
1 redial data button wa Redial indication Used to recall numbers previously dialed. Displayed when a call is made. 2 receive data button ws Program indication Used to recall numbers previously received. Displayed while storing numbers. 3 talk button (blue) wd Reasons why a caller's number cannot be vol (volume) button displayed...
BBasics On the handset Making calls Pick up the handset from the charger when the phone rings. On the base phone If the charger is not on the charger, press talk Pick up the receiver and if you hear a dial When you finish talking tone, dial the number using the number Base phone:...
BTelephone Features Tips Switching phones • Returning the receiver to the base phone after step 1 does not hang up the phone. Just pick up the receiver to during a call resume the conversation. • After step 1, you can transfer a call by pressing intercom/name ask To switch from the base phone to •...
Switching phones during a call Talking between the (continued) phones (intercom) To switch from the handset to the Note base phone Conversation between handsets is not possible. 1 When using one handset: To talk from the base phone to the Press during the phone intercom...
To talk from the handset to the base Adjusting the speaker volume The volume is factory-set to medium. phone While listening to the voice or recorded messages from the speaker, 1 Handset: Pick up the handset from the press the ringer/handset speaker volume charger and press intercom The base phone starts to ring.
Making calls with speed dialing on Speed dialing (base phone) the base phone (continued) 1 Pick up the receiver and press on hook Make sure you hear a dial tone. To check the stored number and the name recorded 2 Press speed dial 1 Press with the receiver placed on the base...
Page 129
Making calls from the phone Entering a pause between numbers Press between the numbers in step 5 above. directory redial data The display will show “P”. A press on the button will create a pause of 1 Recall the phone number you wish to dial approximately 4 seconds.
BAnswering Machine Features To listen to the messages again Basic operation Press play/stop Playback starts from the first message. Before you go out Notes • If a call comes in, the playback will stop. Make sure the date and time are set correctly (see •...
Recording a greeting Changing the number of rings If you do not wish to use the prerecorded greeting, you can record your own greeting. The answering machine is factory-set so that it answers a call after about 5 rings when there is no 1 Press with the receiver message and about 2 rings when messages have been...
