- Page 1 Radio Key 600e ® STAND ALONE PROXIMITY ACCESS CONTROL SYSTEM with PATENTED* DYNASCAN TECHNOLOGY ® Operating & Installation Guide Rev. G P/N 3321490 www.SecuraKeyStore.com (800) 878-7829 sales@securakeystore.com *Patent # 6317027...
- Page 2 COPYRIGHT © 2008 SOUNDCRAFT, INC.
-
Page 3: Table Of Contents
Radio Key 600e ® Operating & Installation Guide Table of Contents Introduction ....................1 RK-PD1 Program Deck & RK-HHP Hand-Held Programmer....3 Programming Radio Key 600e .............. 4 ® Programming Hints .................. 8 Basic Operation ..................8 System Configuration ................9 Wiring ..................... - Page 4 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 5: Introduction
RK-PS, a 12VDC plug-in power supply is optional. It is designed to power the RK600e only, and requires 120 VAC input. RK600-BB Back Box / Spacer is optional. It extends the RK600e out from the mounting surface and pro- vides additional room for wiring. Secura Key 1... -
Page 6: Figure 1, Rk600E Components
Radio Key 600e Operating & Installation ® RK600e Unit Programming Deck Mounting Plate RK600-BB Back Box/ Spacer (optional) Figure 1 - RK600e Components Secura Key 2... -
Page 7: Rk-Pd1 Program Deck & Rk-Hhp Hand-Held Programmer
RK-PD1 consists of the 16 following cards: ENTER “0” ZERO “1” “2” “3” THREE “4” FOUR “5” FIVE “6” “7” SEVEN “8” EIGHT “9” NINE “ ” THRU “+” VALID “–” VOID SET TIMER Hand-Held Programmer MODE (RK-HHP) Secura Key 3... -
Page 8: Programming Radio Key ® 600E
Program Mode. The unit will “time out” and return to Active (Normal) Mode in 15 seconds if no Program card is presented. 1 + 2 + 3 + 4 + 5 (Password) (ENTER) Secura Key 4... - Page 9 ID number printed on the Transponder. Then present the ENTER card. (ADD) (ENTER) (ID Number 995) (User Number 12) Record the User Number and Transponder ID Number in the User Log Form. Secura Key 5...
- Page 10 VOID card to the unit. Then present the ENTER Card to the unit. Hold the Transponder near the RK600e Unit. A green light and beep means that the Transponder was deleted. (Hold Key Tag near Unit) (VOID) (ENTER) Secura Key 6...
- Page 11 To Exit Programming Mode Immediately: Present the MODE Card to the unit. Then present the “1” card to the unit. Present the ENTER card. This returns the unit to normal mode immediately, bypassing the 15 second timeout. (MODE) (ENTER) Secura Key 7...
-
Page 12: Programming Hints
If the Transponder ID Number is stored in memory, the latch relay is activated, unlocking the controlled door or gate and shunting any external alarms. A green light and a beep indicates that access is granted. Secura Key 8... -
Page 13: System Configuration
Install the optional Spacer between the mounting adapter and Auxiliary Reader to reduce the effect on reading distance caused by the metal mounting adapter. Alternatively, the RK600e can be used alone, post mounted with weather gaskets. Secura Key 9... -
Page 14: Wiring
Referring to Table 2, Connector P1 Color Coding and Figure 2, Wiring Diagram, make all appropriate connections from Connector P1 to the power supply, locking device or gate controller, external alarm circuit and Request-to-Exit (REX) input. Use solder and tape or gel-filled crimp-on connectors. Secura Key 10... -
Page 15: Figure 2, Mov Wiring Diagram
(GND) on P1 at the RK600e. Route the auxiliary reader cable at least two feet away from sources of EMI (electro-magnetic interference), such as radio transmitters, elevators, large electric motors or fluorescent light ballasts. Secura Key 11... -
Page 16: Power
AC power in the same cable with DC power to the reader. RK600e also has protection against accidental polarity reversal or use of low voltage AC. WARNING RK600e will not operate on AC Voltage or with DC polarity reversed. Secura Key 12... -
Page 17: Figure 3, Wiring Diagram
USE UNSHIELDED CABLE FOR PINS IF COMMON POWER SUPPLY IS USED FOR BOTH THE RK AND ELECTRONIC DOOR LOCK BE SURE TO INSTALL THE MOV WHICH IS PROVIDED WITH THE ACCESS CONTROL UNIT Figure 3 - Wiring Diagram Secura Key 13... -
Page 18: Table 2, Connector P1 Color Coding
Table 3 - Connector P2 Color Coding Wire Application Wire Color Description Antenna Coil 1 White Coil 2 Blue LED, Red Orange LED Control Green Led, Green Beeper Yellow Beeper Control Bare Wire Connect to J1, Pin 2 Shield/ Drain Wire Secura Key 14... -
Page 19: Installation
If using the optional spacer, install the thick gasket between the spacer and the mounting surface, install the mounting plate and spacer using the two 6-32 x 1-1/2” screws supplied with the spacer, then place the thin gasket around the mounting plate (Figure 6). Secura Key 15... -
Page 20: Figure 4, Basic Installation
4. Apply power. The LED will flash once and the beeper will sound. Refer to beginning of this manual for programming and operating instructions. Mounting Plate Electrical Box RK600 or Auxiliary Wall Surface Reader Housing Figure 4 - Basic Installation Secura Key 16... -
Page 21: Figure 5, Wall Mounting On Metal Surface With Optional Spacer
Figure 5 - Wall Mounting on Metal Surface with Optional Spacer Spacer Alignment Optional Thick Optional Thin Pins Mounting Gasket Mounting Gasket Optional Post or Flange Mount Adapter Mounting Optional RK600 or Auxiliary Plate Spacer Reader Housing Figure 6 - Post/Flange Mounting Secura Key 17... -
Page 22: Troubleshooting
® encoded and do not use facility codes, you can buy them off-the-shelf from any Secura Key dealer. If you do not know who your dealer is, call Secura Key and we will recommend one near you. WARRANTY (U.S. and Canadian) “Secura Key products are warranted against defects in materials and workmanship for LIFE. -
Page 23: Specifications
Back Box / Spacer - Beige, Lexan ® RK-GM Glass Mount Adaptor This product complies with UL 294 Standards, CE (European Standards) and with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. Secura Key 19... -
Page 24: Fcc Certification
Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of the manufacturer could void the user’s authority to operate this equipment. Secura Key 20...
