Page 9: About This User Guide
About This User Guide Thank you for choosing Cambium cnPilot Home & Small Business WiFi router with ATA and optional PoE support. This manual provides basic information about how to install and deploy the cnPilot Home R200x or the R201x WiFi routers with VoIP to the Internet.
Page 10: Contacting Cambium Networks
About This User Guide Declaration of Conformity Contacting Cambium Networks Support website: http://www.cambiumnetworks.com/support Main website: http://www.cambiumnetworks.com Sales enquiries: solutions@cambiumnetworks.com Support enquiries: support@cambiumnetworks.com Repair enquiries rma@cambiumnetworks.com Telephone number list: http://www.cambiumnetworks.com/contact Address: Cambium Networks Limited, Linhay Business Park, Eastern Road, Ashburton, Devon, UK,...
Page 11: Purpose
It is recommended that all personnel engaged in such activities be properly trained. Cambium disclaims all liability whatsoever, implied or express, for any risk of damage, loss or reduction in system performance arising directly or indirectly out of the failure of the customer, or anyone acting on the customer's behalf, to abide by the instructions, system parameters, or recommendations made in this document.
Page 12: Declaration Of Conformity
About This User Guide Declaration of Conformity Declaration of Conformity Part 15 FCC Rules This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:  This device may not cause harmful interference, and ...
Page 13: Warnings, Cautions, And Notes
Warnings, cautions, and notes Warnings, cautions, and notes The following describes how warnings and cautions are used in this document and in all documents of the Cambium Networks document set. Warnings Warnings precede instructions that contain potentially hazardous situations. Warnings are used to alert the reader to possible hazards that could cause loss of life or physical injury.
Page 14: Chapter 1: Product Description
Chapter 1: Product description This chapter covers:  cnPilot Home R200x/R201x  cnPilot Home R200x LED Indicators and Interfaces  cnPilot Home R201x LED Indicators and Interfaces  Hardware Installation and Setup via cnMaestro  Accessing and Configuring cnPilot Devices via the local GUI (without cnMaestro) ...
Page 15: Cnpilot Home R200X/R201X
2X2 2.4GHz 802.11 b/g/n (300 Mbps) Wi-Fi 2X2 5GHz 802.11ac (867 Mbps) 1X USB 2.0 1X USB 2.0 VoIP 2xFXS in RJ11 2xFXS in RJ11 Cambium PoE (Power over Ethernet) Out Power Adapter 12V/2A 12V/3A 12V/2A 12V/3A 12V/3A cnMaestro Managed A maximum of four devices may be connected to each FXS port.
Page 16: Cnpilot Home R200X Led Indicators And Interfaces
Chapter 1: Product description cnPilot Home R200x LED Indicators and Interfaces cnPilot Home R200x LED Indicators and Interfaces Table 2 cnPilot Home R200x LED Indicators Front Panel Status Explanation Blinking (Green) Not registered Phone1/2 On (Green) Registered On (Green) Port is connected at 100 Mbps The port is disconnected 1/2/3/4 Blinking (Green)
Page 17: Table 3 Cnpilot Home R200X Interfaces
Chapter 1: Product description cnPilot Home R200x LED Indicators and Interfaces Table 3 cnPilot Home R200x Interfaces Rear Panel Interface Description POWER Connector for a power adapter Phone1/2 ATA Analog phone connector USB interface Connector for accessing the Internet LAN (1/2/3/4) Connectors for local networked devices Page...
Page 18: Cnpilot Home R201X Led Indicators And Interfaces
Chapter 1: Product description cnPilot Home R201x LED Indicators and Interfaces cnPilot Home R201x LED Indicators and Interfaces Table 4 cnPilot Home R201x LED Indicators Status Explanation On (Green) Connected Disconnected On (Green) Wireless access point is ready 2.4G/5G Blinking (Green) The port is passing data On (Green) The port is connected at 100 Mbps...
Page 19: Hardware Installation And Setup Via Cnmaestro
Chapter 1: Product description Hardware Installation and Setup via cnMaestro Hardware Installation and Setup via cnMaestro Before configuring your router, please see the procedure below for instructions on connecting the cnPilot Home device in your network. Procedure 1 Configuring the Router 1.
Page 20: Accessing And Configuring Cnpilot Devices Via Cnmaestro
Cambium’s next generation network management system is the recommended method for managing Cambium’s cnPilot access points. As Cambium develops new features, you may find the latest information on operating these features at the Cambium Community Forum. Register at Cambium’s support forum (http://community.cambiumnetworks.com/) for instructions, discussions, and helpful tips on managing cnPilot access points.
Page 21: Accessing And Configuring Cnpilot Devices Via The Local Gui (Without Cnmaestro)
Chapter 1: Product description Accessing and Configuring cnPilot Devices via the local GUI (without cnMaestro) Accessing and Configuring cnPilot Devices via the local GUI (without cnMaestro) Before configuring your router, please see the procedure below for instructions on connecting the cnPilot Home device in your network.
Page 22 Chapter 1: Product description Accessing and Configuring cnPilot Devices via the local GUI (without cnMaestro) Warning Changes or modifications not expressly approved by the party responsible for compliance can void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 23: Voice Prompt
Chapter 1: Product description Voice Prompt Voice Prompt cnPilot Home devices may be configured by navigating the unit’s voice menu. By using your phone and dialing a sequence of commands, the device may be configured for operation. Each device configuration section may be accessed by entering a certain operation code, as shown below.
Page 24 Chapter 1: Product description Voice Prompt 1. Pick up phone and press “****” to start IVR 2. Choose “3”, and cnPilot Home R200x /R201x reports current WAN port subnet mask 3. Input a new WAN port subnet mask and press # key: WAN Port Use “*”...
Page 25 Chapter 1: Product description Voice Prompt 1. Pick up phone and press “****” to start IVR 2. Choose “7”, and cnPilot Home R200x/R201x reports “Reboot” 3. Prompt "Please enter password", the method of inputting password is same Reboot as operation 1. 4.
Page 26 Chapter 1: Product description Voice Prompt Note 1. While using Voice menu, press * (star) to return to main menu. 2. If any changes made in the IP assignment mode, the router must be rebooted in order for the settings to take effect. 3.
Page 27: Chapter 2: Configuring Basic Settings
Chapter 2: Configuring Basic Settings This chapter covers:  Two-Level Management  Web Management Interface  Configuring  Making a Call Page...
Page 28: Two-Level Management
Chapter 2: Configuring Basic Settings Two-Level Management Two-Level Management This section explains how to setup a password for an administrator or user and how to adjust basic and advanced settings. cnPilot Home R200x/R201x supports two-level management: administrator and user. For administrator mode operation, please type “admin/admin”...
Page 29: Figure 2 Login Prompt - Wan Port
Chapter 2: Configuring Basic Settings Two-Level Management The web management interface automatically logs out the user after 5 minutes of inactivity. Logging in from the WAN port Ensure your PC is connected to the router’s WAN port correctly. Obtain the IP addresses of WAN port using Voice prompt or by logging into the device web management interface via a LAN port and navigating to Network >...
Page 30: Web Management Interface Details
Chapter 2: Configuring Basic Settings Web Management Interface Details Web Management Interface Details Table 7 Web management interface Field Name Description Click an option in Top Navigation bar (area marked as “1”). Multiple Top Navigation bar options in the Sub-navigation bar are displayed Click the Sub-navigation bar to choose a configuration page (area marked Sub-navigation bar as “2”)
Page 31: Setting The Time Zone
Chapter 2: Configuring Basic Settings Web Management Interface Details Setting the Time Zone Table 8 Setting time zone Field Name Description Enable NTP (Network Time Protocol) to automatically retrieve time NTP Enable and date settings for the device When NTP Enable is set to “Disable”, manually configure the time Current Time and date via the Current Time parameter Press...
Page 32: Configuring An Internet Connection
Chapter 2: Configuring Basic Settings Web Management Interface Details Configuring an Internet Connection From the Network > WAN page, WAN connections may be inserted or deleted. For more information on Internet Connection setting, see Table 9 below. Table 9 Configuring an internet connection Field Name Description Connect Name...
Page 33 Chapter 2: Configuring Basic Settings Web Management Interface Details VLAN ID Note Multiple WAN connections may be created with the same VLAN ID DNS Mode Select DNS mode, options are Auto and Manual: 1. When DNS mode is Auto, the device under LAN port will automatically obtains the preferred DNS and alternate DNS.
Page 34: Setting Up Wireless Connections
Chapter 2: Configuring Basic Settings Web Management Interface Details Setting up Wireless Connections To set up the wireless connection, please perform the following steps. Enable Wireless and Setting SSID Open Wireless > Basic webpage as shown below: Table 10 Wireless > Basic web page (user view) Field Name Description Select “Radio Off”...
Page 35 Chapter 2: Configuring Basic Settings Web Management Interface Details Enabled: Devices connected to the router are isolated from one another on virtual networks AP Isolation Disabled: Devices connected to the router are visible on the network to each other Enabled: Devices connected to the router via one of the Multiple SSIDs are isolated from one another on virtual networks MBSSID AP Isolation Disabled: Devices connected to the router via one of the Multiple SSIDs...
Page 36: Table 11 Wireless Security Web Page
Chapter 2: Configuring Basic Settings Web Management Interface Details Encryption Open Wireless/Wireless Security webpage to configure custom security parameters. Table 11 Wireless Security web page Field Name Description Choose the SSID from the drop-drown list for which security will be SSID Choice configured Select an appropriate encryption mode to improve the security and...
Page 37: Configuring Session Initiation Protocol (Sip)
Chapter 2: Configuring Basic Settings Web Management Interface Details Configuring Session Initiation Protocol (SIP) SIP Accounts cnPilot Home devices have 2 FXS ports to make SIP (Session Initiation Protocol) calls. Before registering, the device user should have a SIP account configured by the system administrator or provider.
Page 38: Table 13 Registration Status
Chapter 2: Configuring Basic Settings Web Management Interface Details Viewing the Registration Status Table 13 Registration status Procedure To view the SIP account status of device, open the Status webpage and view the value of registration status. Page 2-12...
Page 39: Making A Call
Chapter 2: Configuring Basic Settings Web Management Interface Details Making a Call Calling phone or extension numbers To make a phone or extension number call:  Both ATA and the other VoIP device (i.e., another ATA or other SIP products) must have public IP addresses, or ...
Page 40 Chapter 2: Configuring Basic Settings Web Management Interface Details Party A dials “*77” to hold the party B, when hear the dial tone, A dials C’s number, then party A and party C are in conversation. Party A dials “*78” to transfer to C, then B and C now in conversation. If the transfer is not completed successfully, then A and B are in conversation again.
Page 41: Chapter 3: System Planning
Chapter 3: System planning This chapter guides users to execute advanced (full) configuration through admin mode operation. This chapter covers:  Login  Status  Network and Security  Wireless   FXS1  FXS2  Security  Application  Administration ...
Page 42: Login
Chapter 3: System planning Login Login Table 14 Login details Procedure 1. Connect the LAN port of the router to your PC vi an Ethernet cable 2. Open a web browser on your PC and type http://192.168.11.1. 3. Enter Username admin and Password admin. 4.
Page 43: Status
Chapter 3: System planning Status Status Table 15 Status Page Page...
Page 44 Chapter 3: System planning Status Page...
Page 45 Chapter 3: System planning Status Description This webpage shows the status information about the Product, Network, and System including Product Information, SIP Account Status, FXS Port Status, Network Status. and Wireless Info. Page...
Page 46: Network And Security
Chapter 3: System planning Network and Security Network and Security You can configure the WAN port, LAN port, DDNS, Multi WAN, DMZ, MAC Clone, Port Forward and other parameters in this section of the web management interface. This page allows you to set WAN configuration with different modes. Use the Connection Type drop down list to choose one WAN mode and then the corresponding page will be displayed.
Page 47: Table 17 Dhcp
Chapter 3: System planning Network and Security DHCP The Router has a built-in DHCP server that assigns private IP address to each local client. The DHCP feature allows to the cnPilot Home to obtain an IP address automatically from a DHCP server.
Page 48: Table 18 Pppoe
Chapter 3: System planning Network and Security PPPoE PPPoE stands for Point-to-Point Protocol over Ethernet. It relies on two widely accepted standards: PPP and Ethernet. It connects users through an Ethernet to the Internet with a common broadband medium, such as a single DSL line, wireless device or cable modem. All the users over the Ethernet can share a common connection.
Page 49 Chapter 3: System planning Network and Security Confirm Password Enter your PPPoE password again Service Name Enter a service name for PPPoE authentication. If it is left emply, the service name is auto detected. Operation Mode Select the mode of operation, options are Keep Alive, On Demand and Manual: ...
Page 50: Table 19 Bridge Mode
Chapter 3: System planning Network and Security Bridge Mode Bridge Mode under Multi WAN is different with traditional bridge setting. Bridge mode employs no IP addressing and the device operates as a bridge between the WAN port and the LAN port. Route Connection has to be built to give IP address to local service on device.
Page 51 Chapter 3: System planning Network and Security DHCP packet from the WAN interface to the LAN interface. Local DHCP service will not allocate IP to clients of LAN port. Local Service Gateway will not forward DHCP packets between LAN and WAN, it also blocks DHCP packets from the WAN port.
Page 52: Table 20 Connect Name
Chapter 3: System planning Network and Security Connect Name and Service Table 20 Connect name Content Define Comment 1～99 WAN Connection identifier Service TR069 The connection supports management applications i.e. R069, WEB, SNMP and Provision INTERNET The connection solely supports internet service TR069_INTERNET The connection supports management and internet applications...
Page 53: Multi Wan Setting
Chapter 3: System planning Network and Security Multi WAN Setting Overview Multi WAN is used to implement the distribution of different kinds of services, and device’s Multi WAN supports the distribution of data services, voice services and management services. By setting different VLANs, different kinds of data is distributed to the corresponding networks.
Page 54: Figure 4 Multi Wan Network
Chapter 3: System planning Network and Security Figure 4 Multi WAN network Setting up the Internet Connection From the WAN page, a multi WAN connection can be created or deleted. See below for more information on configuring these settings. Connect Name and Service Table 21 Internet Page 3-14...
Page 55 Chapter 3: System planning Network and Security Content Define Comment 1 to 99 WAN Connection identifier Service TR069 The connection supports management applications including TR069, WEB, SNMP and Provision INTERNET The connection supports Internet service TR069_INTERNET The connection supports management and internet applications VOICE The connection support voice applications like...
Page 56: Table 22 Bridge Mode
Chapter 3: System planning Network and Security Table 22 Bridge Mode Field Name Description Bridge Type IP Bridge Allows all Ethernet packets to pass. A PC can connect to upper network directly. PPPoE Bridge Only Allows PPPoE packets pass. The PC needs PPPoE dial-up software. Hardware IP Bridge Packets pass through hardware switch at wired speed.
Page 57 Chapter 3: System planning Network and Security port. Clients of the LAN port can retrieve IP addressing from the DHCP server in the device. VLAN Mode Disable The WAN interface is untagged. LAN is untagged. Enable The WAN interface is tagged. LAN is untagged. Trunk Only valid in bridge mode.
Page 58 Chapter 3: System planning Network and Security Fast Bridge Setting Step 1 Login to the web management interface of the cnPilot Device. Navigate to Page Administration->Operating Mode. Set Operating mode to Basic Mode. Click Save. Step 2 Open Network->WAN, Change NAT Enable to Disable. Click Save then Reboot. The device is now operating in Bridge mode.
Page 59 Chapter 3: System planning Network and Security Step 3 Log into the device via the WAN port. Below is example of Page Status->Basic displaying device configuration. Page 3-19...
Page 60: Lan
Chapter 3: System planning Network and Security LAN Port NAT translates the packets from public IP address to local IP address to forward packets to the proper destination. Table 23 LAN port Field Name Description IP Address Enter the IP address of the router on the local area network. All the IP addresses of the computers which are in the router’s LAN must be in the same network segment with this address, and the default gateway of the computers must be this IP address.
Page 61 Chapter 3: System planning Network and Security DHCP Start Enter a valid IP address as a starting IP address of the DHCP server, and if the router’s LAN IP address is 192.168.11.1, starting IP address Address can be 192.168.11.2 or greater, but should be less than the ending IP address.
Page 62: Table 24 Dhcp Server Settings
Chapter 3: System planning Network and Security DHCP Server The router has a built-in DHCP server that assigns private IP address to each local client. DHCP stands for Dynamic Host Configuration Protocol. The router, by factory default acts a DHCP server for your network so it automatically dispatches related IP settings to any local user configured as a DHCP client.
Page 63: Table 25 Dhcp Server, Dns And Client Lease Time
Chapter 3: System planning Network and Security Table 25 DHCP server, DNS and Client Lease Time Field Name Description Specify the Primary DNS address provided by your ISP. If your ISP Primary DNS does not provide it, the router will automatically apply default DNS Server IP address: 202.96.134.33 to this field.
Page 64: Table 26 Mac Clone
Chapter 3: System planning Network and Security MAC Clone Some ISPs will require you to register your MAC address. If you do not wish to re-register your MAC address, you can have the router clone the MAC address that is registered with your ISP. To use the Clone Address button, the computer accessing the web management interface will have the MAC address automatically entered in the Clone WAN MAC field.
Page 65: Table 27 Vpn
Chapter 3: System planning Network and Security Table 27 VPN Field Name Description VPN Enable Enable/Disable VPN. If the VPN is enabled, user can select PPTP and L2TP mode VPN. Initial Service IP Enter VPN server IP address. User Name Enter authentication username.
Page 66: Table 29 Ddns Setting
Chapter 3: System planning Network and Security DDNS Setting Table 29 DDNS setting Field Name Description Dynamic DNS Provider DDNS is enabled and select a DDNS service provider. Account Enter the DDNS service account. Password Enter the DDNS service account password. DDNS Enter the DDNS domain name or IP address.
Page 67: Table 30 Port Forward
Chapter 3: System planning Network and Security Port Forward Table 30 Port Forward Field Name Description Comment Sets the name of a port mapping rule or comment IP Address The IP address of devices under the LAN port. Port Range Set the port range for the devices under the LAN port.
Page 68: Table 31 Advance
Chapter 3: System planning Network and Security Advance Table 31 Advance Field Name Description Most Nat connections The largest value which the cnPilot Home R200x can provide Mss Mode Choose Mss Mode from Manual and Auto Mss Value Set the value of TCP AntiDos-p You can choose to enable or prohibit IP conflict detection...
Page 69: Table 32 Port Setting
Chapter 3: System planning Network and Security Port Setting Table 32 Port setting Field Name Description WAN Port speed Nego Auto-negotiation, options are Auto, 100M full, 100M half-duplex, 10M half and full. LAN1~LAN4 Port Speed Auto-negotiation, options are Auto, 100M full, 100M half, 10M half Nego and 10M full.
Page 70: Table 33 Qos
Chapter 3: System planning Network and Security Table 33 QoS Field Name Description QoS Enable Enable/Disable QoS function Upstream Set the upstream bandwidth Downstream Set the downstream bandwidth Delete Selected In NO., Check the items you want to delete, click the Delete option Click Add to add a new parameter Note From system release 4.2 or later, the QoS bandwidth can be configured for...
Page 71: Table 34 Routing
Chapter 3: System planning Network and Security Routing Table 34 Routing Field Name Description Destination Destination address Host/Net Both Host and Net selection Gateway Gateway IP address Interface LAN/WAN/Custom three options, and add the corresponding address Comment Comment Page 3-31...
Page 72: Wireless
Chapter 3: System planning Wireless Wireless Basic Table 35 Basic Field Name Description Radio on/off Select “Radio off” to disable wireless. Select “Radio on” to enable wireless. Wireless connection According to the wireless client type, select one of these modes. mode Default is AP Network Mode...
Page 73 Chapter 3: System planning Wireless SSID It is the basic identity of wireless LAN. SSID can be any alphanumeric or a combination of special characters. It will appear in the wireless network access list. Multiple SSID1~SSID3 CnPilot Home R200x supports 4 SSIDs. Hidden After the item is checked, the SSID is no longer displayed in the search for the Wi-Fi wireless network connection list...
Page 74 Chapter 3: System planning Wireless Enabled: Multiple copies of signals are transmitted to increase the chance of successful delivery Disabled: STBC is not employed for signal transmission Enabled: Allows the device to aggregate multiple Ethernet frames into a single 802.11n, thereby improving the ratio of frame data to Aggregation MSDU (A- frame overhead MSDU)
Page 75: Wireless Security
Chapter 3: System planning Wireless Wireless Security Table 36 Wireless security Field Name Description Choose one SSID from SSID, Multiple SSID1, Multiple SSID2 and SSID Choice Multiple SSID3. Select an appropriate encryption mode to improve the security and privacy of your wireless data packets. Security Mode Each encryption mode will bring out different web page and ask you to offer additional configuration.
Page 76: Table 37 Wifi Security Setting
Chapter 3: System planning Wireless User can configure the corresponding parameters. Here are some common encryption methods: OPENWEP：A handshake way of WEP encryption, encryption via the WEP key: Table 37 WiFI Security Setting Field Name Description Security Mode This is used to select one of the 4 WEP keys, key settings on the clients should be the same with this when connecting.
Page 77: Table 38 Wpa-Psk
Chapter 3: System planning Wireless WPA-PSK, the router will use WPA way which is based on the shared key-based mode: Table 38 WPA-PSK Field Name Description WPA Algorithms This item is used to select the encryption of wireless home gateway algorithms, options are TKIP, AES and TKIPAES.
Page 78: Table 40 Wireless Access Policy
Chapter 3: System planning Wireless WPA-PSK/WPA2-PSK WPA/WPA2 security type is actually a simplified version, which is based on the WPA shared key mode, higher security setting is also relatively simple, suitable for ordinary home users and small businesses. Wireless Access Policy: Table 40 Wireless Access Policy Field Name Description...
Page 79: Table 41 Wmm
Chapter 3: System planning Wireless Table 41 WMM Description WMM (Wi-Fi Multi-Media) is the QoS certificate of Wi-Fi Alliance (WFA). This provides you to configure the parameters of wireless multimedia; WMM allows wireless communication to define a priority according to the home gateway type. To make WMM effective, the wireless clients must also support WMM.
Page 80: Table 42 Wds
Chapter 3: System planning Wireless Table 42 WDS Description WDS stands for Wireless Distribution System, enabling WDS access points to be interconnected to expand a wireless network. WPS (Wi-Fi Protected Setup) provides easy procedure to make network connection between wireless station and wireless access point with the encryption of WPA and WPA2. It is the simplest way to build connection between wireless network clients and wireless access point.
Page 81: Table 43 Wps
Chapter 3: System planning Wireless Table 43 WPS Field Name Description WPS Setting Enable/Disable WPS function WPS Summary Display the current status of WPS, including current state, SSSID name, authentication methods, encryption type and the PIN code of this AP. Generate Generate a new PIN code ...
Page 82: Table 44 Station Info
Chapter 3: System planning Wireless  PIN：Enter the PIN code of the wireless device which accesses to this WPS Mode LAN in the following option, and press apply. Then CnPilot Home R200x begins to send signals, turn on the PIN accessing method on the clients, and then it can access the wireless AP automatically.
Page 83: Table 45 Advanced
Chapter 3: System planning Wireless Advanced Table 45 Advanced Field Name Description BG Protection Select G protection mode, options are on, off and automatic. Mode Beacon Interval The interval of sending a wireless beacon frame, within this range, it will send a beacon frame for the information of the surrounding radio network.
Page 84 Chapter 3: System planning Wireless RTS Threshold Specify the packet RTS threshold, when the packet exceeds this value, the router will send RTS to the destination site consultation TX Power Define the transmission power of the current AP, the greater it is, the stronger the signal is.
Page 85: Table 46 Wireless Security
Chapter 3: System planning Wireless Wireless Security Table 46 Wireless security Field Name Description Choose one SSID from SSID, Multiple SSID1, Multiple SSID2 and Multiple SSID Choice SSID3. Select an appropriate encryption mode to improve the security and privacy of your wireless data packets. Security Mode Each encryption mode will bring out different web page and ask you to offer additional configuration.
Page 86: Station Info
Chapter 3: System planning Wireless WDS. See WPS. Station Info Station Info. Advanced See Advanced. Page 3-46...
Page 87: Sip
Chapter 3: System planning SIP Settings Table 47 SIP settings Field Name Description SIP T1 The minimum scale of retransmission time Max Forward SIP contains Max Forward message header fields used to limit the requests for forwards. SIP Reg User The agent name of SIP registered user Agent Name Max Auth...
Page 88: Table 48 Voip Qos
Chapter 3: System planning Mark All AVT Voice packet marking to enable this item will see the mark on the voice Packets message when the call environment changed (such as press a key during the call) RFC 2543 Call Enable the Connection Information field displays the address is 0.0.0.0 in Hold the invite message of Hold.
Page 89: Fxs1
Chapter 3: System planning FXS1 FXS1 SIP Account Basic Set the basic information provided by your VOIP Service Provider, such as Phone Number, Account, password, SIP Proxy and others. Table 49 SIP Account – Basic Field Name Description Line Enable Enable/Disable the line.
Page 90: Table 50 Audio Configuration
Chapter 3: System planning FXS1 Outbound Port Outbound Proxy’s Service port, default is 5060 Backup Outbound Backup Outbound Proxy’s Service port, default is 5060 Port Display Name The number will be displayed on LCD Phone Number Enter telephone number provided by SIP Proxy Account Enter SIP account provided by SIP Proxy Password...
Page 91: Table 51 Supplementary Service
Chapter 3: System planning FXS1 G.723 Coding Speed Choose the speed of G.723 from 5.3kbps and 6.3kbps Packet Cycle The RTP packet cycle time, default is 20ms Silence Supp Enable/Disable silence support. Echo Cancel Enable/Disable echo cancel. By default, it is enabled. Auto Gain Control Enable/Disable auto gain.
Page 92: Table 52 Advanced
Chapter 3: System planning FXS1 Voice Mailbox Fill in the voice mailbox phone number, Asterisk platform, for example, its Numbers default voice mail is *97 VMWI Serv Enable/Disable VMWI service. Enable/Disable DND (do not disturb). If enable, any phone call cannot arrive at the device; default is disable. Enter the speed dial phone numbers.
Page 93 Chapter 3: System planning FXS1 Carry Port If or not carry port information in the SIP URI. Information Signal Port The local port of SIP protocol, default is 5060. DTMF Type Choose the DTMF type from Inbound, RFC2833 and SIP INFO. RFC2833 User can use the default setting.
Page 94: Table 53 Volume Settings
Chapter 3: System planning FXS1 Dial Prefix The number will be added before your telephone number when making calls. User Type Choose the User Type from IP and Phone. Hold Method Choose the Hold Method from ReINVITE and INFO. Request-URI User Enable/Disable the user request URI check.
Page 95: Table 54 Regional
Chapter 3: System planning FXS1 Regional Table 54 Regional Field Name Description Tone Type Choose tone type form China, US, Hong Kong and so on. Dial Tone Dial Tone Busy Tone Busy Tone Off Hook Warning Off Hook warning tone Tone Ring Back Tone Ring back tone...
Page 96: Table 55 Features And Call Forward
Chapter 3: System planning FXS1 Features and Call Forward Table 55 Features and call forward Field Description Name All Forward Enable/Disable forward all calls Features Busy Forward Enable/Disable busy forward. No Answer Forward Enable/Disable no answer forward. All Forward Set the target phone number for all forward. Call The device will forward all calls to the phone number Forward...
Page 97 Chapter 3: System planning FXS1 IVR key code Signatures of the voice menu, default is ****. R key enable Enable/Disable R key way call features. R key cancel code Set the R key cancel code, option are ranged from R1 to R9, default value is R1.
Page 98: Table 56 Miscellaneous
Chapter 3: System planning FXS1 Miscellaneous Table 56 Miscellaneous Field Name Description Codec Loop Set off-hook loop current, default is 26 Current Impedance Set impedance matching, default is US PBX,Korea,Taiwan(600). Maching CID service Enable/Disable displaying caller ID; If enable, caller ID is displayed when there is an incoming call or it won’t be displayed.
Page 99: Table 57 Parameters And Settings
Chapter 3: System planning FXS1 Dial Plan Parameters and Settings Table 57 Parameters and settings Field Name Description Dial Plan Enable/Disable dial plan. Line Set the line. Digit Map Enter the sequence used to match input number The syntactic, please refer to the following Dial Plan Syntactic Action Choose the dial plan mode from Deny and Dial Out.
Page 100: Table 58 Adding One Dial Plan
Chapter 3: System planning FXS1 Adding one Dial Plan Table 58 Adding one dial plan Description Step 1. Enable Dial Plan Step 2. Click Add button, and the configuration table Step 3. Fill in the value of parameters. Step 4. Press OK button to end configuration. Dial Plan Syntactic Table 59 Dial Plan String...
Page 101 Chapter 3: System planning FXS1 <dialed:substituted> Replace dialed with substituted. For example： <8:1650>123456：input is “85551212”, output is“16505551212” Make outside dial tone after dialing “x”, stop until dialing character “y” For example： “9,1xxxxxxxxxx”:the device reports dial tone after inputting “9”, stops tone until inputting “1” “9,8,010x”: make outside dial tone after inputting “9”, stop tone until inputting “0”...
Page 102: Table 60 Blacklist
Chapter 3: System planning FXS1 Blacklist In this page, user can upload or download blacklist file, and can add or delete or edit blacklist one by one. Table 60 Blacklist Description Click to select the blacklist file and click to upload it to CnPilot Home; Click to save the blacklist file to your local computer.
Page 103: Table 61 Call Log
Chapter 3: System planning FXS1 Call Log To view the call log information such as redial list (incoming call), answered call and missed call. Table 61 Call log Redial List Page 3-63...
Page 104 Chapter 3: System planning FXS1 Answered Calls Missed Calls Page 3-64...
Page 105: Fxs2
Chapter 3: System planning FXS2 FXS2 The settings of FXS2 are the same as FXS1. See FXS1 on page 3-49. Page 3-65...
Page 106: Security
Chapter 3: System planning Security Security Filtering Setting Table 62 Filtering setting Field Name Description Filtering Enable/Disable filter function Default Policy Choose to drop or accept filtered MAC addresses Mac address Add the Mac address filtering Dest IP address Destination IP address Source IP address Source IP address Protocol...
Page 107: Table 63 Content Filtering
Chapter 3: System planning Security Content Filtering Table 63 Content filtering Page 3-67...
Page 108 Chapter 3: System planning Security Field Name Description Filtering Enable/Disable content Filtering Default Policy The default policy is to accept or to prohibit filtering rules Current Webs URL List the URL filtering rules that already existed (blacklist) Filters Delete/Cancel You can choose to delete or cancel the existing filter rules Add a URL Filter Add URL filtering rules Add/Cancel...
Page 109: Application
Chapter 3: System planning Application Application UPnP UPnP (Universal Plug and Play) supports zero-configuration networking, and can automatically discover a variety of networked devices. When UPnP is enabled, the connected device is allowed to access the network, obtain an IP address, and convey performance information. If the network has a DHCP and DNS server, the connected device can automatically obtain DHCP and DNS services.
Page 110: Table 65 Igmp
Chapter 3: System planning Application Table 65 IGMP Field Name Description IGMP Proxy enable Enable/Disable IGMP function. Table 66 MLD Field Name Description MLD enable Enable/Disable MLD function (Multicast Listener Discovery) Page 3-70...
Page 111: Storage
Chapter 3: System planning Storage Storage Disk Management This page is used to manage the USB storage device. Table 67 Disk Management Field Name Description Adding files to the USB storage device Delete Remove the USB storage device file Remove Disk Transfer files within a USB storage device Format Format the USB storage device...
Page 112: Table 68 Ftp Setting
Chapter 3: System planning Storage FTP Setting Table 68 FTP Setting Field Name Description FTP Server Enable/Disable FTP server FTP Server Name Set the FTP server name Anonymous Login If or not support anonymous login FTP Port Set FTP server port number Max.
Page 113: Table 69 Smb Setting
Chapter 3: System planning Storage Smb Setting Table 69 Smb setting Field Name Description SAMBA Server Enable/Disable SAMBA server Workgroup Enter the working group NetBIOS Name Network basic input/output system name Add a shared file Edit Edit a shared file Delete a shared file Add a shared file Edit...
Page 114: Administration
Chapter 3: System planning Administration Administration The user can manage the device in these webpages; you can configure the Time/Date, password, web access, system log and associated configuration TR069. Management Save config file Table 70 Save Config File Field Name Description Config file upload and Upload: click on browse, select file in the local, press the upload button...
Page 115: Table 71 Administrator Settings
Chapter 3: System planning Administration Administrator settings Table 71 Administrator settings Field Name Description User type Choose the user type from admin user and normal user and basic user. New User Name You can modify the user name, set up a new user name New Password Input the new password Confirm Password...
Page 116: Table 72 Ntp Settings
Chapter 3: System planning Administration Web Idle timeout Set the Web Idle timeout time. The webpage can be logged out after Web Idle Timeout without any operation. Allowed Remote Set the IP from which a user can login the device remotely. IP(IP1,IP2,...) Remote Telnet Enable/Disable remote telnet login...
Page 117 Chapter 3: System planning Administration Secondary NTP Server Options for NTP server's IP address or domain name NTP synchronization NTP synchronization cycle, cycle time can be 1 to 1440 minutes in any one, the default setting is 60 minutes Page 3-77...
Page 118: Table 73 Daylight Saving Time
Chapter 3: System planning Administration Daylight Saving Time Table 73 Daylight Saving Time Procedure Step 1. Enable Daylight Savings Time. Step 2. Set value of offset for Daylight Savings Time Step 3: Set starting Month/Week/Day/Hour in Start Month/Start Day of Week Last in Month/Start Day of Week/Start Hour of Day, analogously set stopping Month/Week/Day/Hour in Stop Month/Stop Day of Week Last in Month/Stop Day of Week/Stop Hour of Day.
Page 119: Table 75 Factory Defaults Setting
Chapter 3: System planning Administration Remote Syslog Enable Enable/Disable remote syslog function. Remote Syslog server Add a remote server IP address. Syslog Enable Enable/Disable syslog function Syslog Level Select the system log, there is INFO and Debug two grades, the Debug INFO can provide more information.
Page 120: Firmware Upgrade
Chapter 3: System planning Administration Firmware Upgrade Table 77 Firmware upgrade Description 1. Choose upgrade file type from Image File and Dial Rule 2. Press “Browse..” button to browser file 3. Press to start upgrading Page 3-80...
Page 121: Provision
Chapter 3: System planning Administration Provision Provisioning allows CnPilot Home R200x/R201x to auto-upgrade and auto-configure devices which support TFTP, HTTP and HTTPs .  Before testing or using TFTP, user should have tftp server and upgrading file and configuring file. ...
Page 122: Table 79 Firmware Upgrade
Chapter 3: System planning Administration Resync Random Set the maximum delay for the request of synchronization file. The Delay(sec) default is 40. Resync Periodic(sec) If the last resync was failure, CnPilot Home R200x will retry resync after the “Resync Error Retry Delay ” time, default is 3600s. Resync Error Retry Set the periodic time for resync, default is 3600s.
Page 123: Snmp
Chapter 3: System planning Administration SNMP Table 80 SNMP Field Name Description SNMP Service Enable or Disable the SNMP service Trap Server Address Enter the trap server address for sending SNMP traps Read Community Name String value that is used as a password to request information via SNMP from the device Write Community Name String value that is used as a password to write configuration...
Page 124: Table 81 Tr069
Chapter 3: System planning Administration TR-069 TR-069 provides the possibility of auto configuration of internet access devices and reduces the cost of management. TR-069 (short for Technical Report 069) is a DSL Forum technical specification entitled CPE WAN Management Protocol (CWMP). It defines an application layer protocol for remote management of end-user devices.
Page 125 Chapter 3: System planning Administration Periodic Inform Enable Enable the function of periodic inform or not. By default it is Enabled Periodic Inform Periodic notification interval with the unit in seconds. The default value Interval is 43200s Connect Request parameters User Name The username used to connect the TR069 server to the DUT.
Page 126 Chapter 3: System planning Administration Click on the Device Info menu item, and you can see basic information about the test equipment. As shown in Figure：（Button on the bottom of the device can perform basic operations，such as reboot.） If the device is properly connected server， offline will be online. That is a successful connection：...
Page 127 Chapter 3: System planning Administration If you could not find the device in the list，please check if the device WEB page filled in correctly. Get Device Info Click on the Advanced View menu button, you can do some node. As shown in Figure: 1.
Page 128 Chapter 3: System planning Administration 4.4 Set Device Info 1. Set ProxyServer The lower end of the button "Edit" can set new values for writable nodes. After clicking edit, fill in the new value directly in the box Parameter value field after the node name. For example, if set ProxyServer of Line1, the current value is followed: Then click edit, and fill in the new ProxyServer.
Page 129 Chapter 3: System planning Administration 4.5 Firmware Upgrade Under is firmware upgrading operation on FreeACS. 1. Equipment connection configure If the connection is successful, you will see the following pages. Page 3-89...
Page 130 Chapter 3: System planning Administration 2. Upload new firmware Choose File & Script enter the appropriate documentation, select the corresponding firmware, click button of upload file to upload new firmware. Uploaded firmware information will appear at the bottom. Page 3-90...
Page 131 Chapter 3: System planning Administration 3. Firmware Upgrade Select firmware version, and then click upgrade. 3. Login web inspection equipment If the upgrade is successful, you can check the firmware version number. Here you can see the firmware has been updated to the required firmware version. 5 TR-069 Profile Under nodes base on TR098, TR104 and TR111.
Page 132 Chapter 3: System planning Administration {"Description", }, {"ProductClass", }, {"SerialNumber", }, {"HardwareVersion", }, {"SoftwareVersion", }, {"SpecVersion", }, {"ProvisioningCode", }, {"UpTime", }, {"DeviceLog", }, {"", }, {"ManagementServer", }, {"URL", }, {"Username", }, {"Password", }, {"PeriodicInformEnable", }, {"PeriodicInformInterval", }, {"PeriodicInformTime", }, {"ParameterKey", }, {"ConnectionRequestURL", }, {"ConnectionRequestUsername", }, {"ConnectionRequestPassword", },...
Page 133 Chapter 3: System planning Administration {"UPnPIGD", }, {"", }, {"", }, {"IPPingDiagnostics", }, {"DiagnosticsState", }, {"Interface", }, {"Host", }, {"NumberOfRepetitions", }, {"Timeout", }, {"DataBlockSize", }, {"DSCP", }, {"SuccessCount", }, {"FailureCount", }, {"AverageResponseTime", }, {"MinimumResponseTime", }, {"MaximumResponseTime", }, {"", }, {"DownloadDiagnostics", }, {"DiagnosticsState", }, {"Interface", }, {"DownloadURL", },...
Page 134 Chapter 3: System planning Administration {"DiagnosticsState", }, {"Interface", }, {"UploadURL", }, {"DSCP", }, {"EthernetPriority", }, {"TestFileLength", }, {"ROMTime", }, {"BOMTime", }, {"EOMTime", }, {"TotalBytesSent", }, {"TCPOpenRequestTime", }, {"TCPOpenResponseTime", }, {"", }, {"Time", }, {"NTPServer1", }, {"NTPServer2", }, {"", }, {"UserInterface", }, {"User", }, {"1", }, {"Enable", },...
Page 135 Chapter 3: System planning Administration {"ForwardNumberOfEntries", }, {"Forwarding", }, {"1", }, {"Enable", }, {"Status", }, {"Type", }, {"DestIPAddress", }, {"DestSubnetMask", }, {"SourceIPAddress", }, {"SourceSubnetMask", }, {"GatewayIPAddress", }, {"Interface", }, {"ForwardingMetric", }, {"", }, {"", }, {"", }, {"LANConfigSecurity", }, {"ConfigPassword", }, {"", }, {"LANDevice", }, {"1", },...
Page 136 Chapter 3: System planning Administration {"IPInterfaceNumberOfEntries", }, {"IPInterface", }, {"1", }, {"Enable", }, {"IPInterfaceIPAddress", }, {"IPInterfaceSubnetMask", }, {"IPInterfaceAddressingType", }, {"", }, {"", }, {"", }, {"LANEthernetInterfaceConfig", }, {"1", }, {"Enable", }, {"Status", }, {"MACAddress", }, {"MACAddressControlEnabled", }, {"MaxBitRate", }, {"DuplexMode", }, {"", }, {"", }, {"WLANConfiguration", },...
Page 137 Chapter 3: System planning Administration {"WPAAuthenticationMode", }, {"IEEE11iEncryptionModes", }, {"IEEE11iAuthenticationMode", }, {"PossibleChannels", }, {"ChannelsInUse", }, {"BasicDataTransmitRates", }, {"OperationalDataTransmitRates", }, {"PossibleDataTransmitRates", }, {"RadioEnabled", }, {"AutoRateFallBackEnabled", }, {"TotalBytesSent", }, {"TotalBytesReceived", }, {"TotalPacketsSent", }, {"TotalPacketsReceived", }, {"TotalAssociations", }, {"AssociatedDevice", }, {"1", }, {"AssociatedDeviceMACAddress", }, {"AssociatedDeviceIPAddress", }, {"AssociatedDeviceAuthenticationState", }, {"X_AssociatedDeviceSignalStrength", },...
Page 138 Chapter 3: System planning Administration {"LeaseTimeRemaining", }, {"MACAddress", }, {"HostName", }, {"InterfaceType", }, {"Active", }, {"", }, {"", }, {"", }, {"", }, {"", }, {"WANDevice", }, {"1", }, {"WANConnectionNumberOfEntries", }, {"WANCommonInterfaceConfig", }, {"EnabledForInternet", }, {"WANAccessType", }, {"Layer1UpstreamMaxBitRate", }, {"Layer1DownstreamMaxBitRate", }, {"PhysicalLinkStatus", }, {"TotalBytesSent", }, {"TotalBytesReceived", },...
Page 139 Chapter 3: System planning Administration {"LastConnectionError", }, {"RSIPAvailable", }, {"NATEnabled", }, {"AddressingType", }, {"ExternalIPAddress", }, {"SubnetMask", }, {"DefaultGateway", }, {"DNSEnabled", }, {"DNSOverrideAllowed", }, {"DNSServers", }, {"MACAddress", }, {"ConnectionTrigger", }, {"RouteProtocolRx", }, {"PortMappingNumberOfEntries", }, {"PortMapping", }, {"1", }, {"PortMappingEnabled", }, {"PortMappingLeaseDuration", }, {"RemoteHost", }, {"ExternalPort", }, {"InternalPort", },...
Page 140 Chapter 3: System planning Administration {"PossibleConnectionTypes", }, {"ConnectionType", }, {"Name", }, {"Uptime", }, {"LastConnectionError", }, {"RSIPAvailable", }, {"NATEnabled", }, {"Username", }, {"Password", }, {"ExternalIPAddress", }, {"DNSEnabled", }, {"DNSOverrideAllowed", }, {"DNSServers", }, {"MACAddress", }, {"TransportType", }, {"PPPoEACName", }, {"PPPoEServiceName", }, {"ConnectionTrigger", }, {"RouteProtocolRx", }, {"PortMappingNumberOfEntries", }, {"PortMapping", },...
Page 141 Chapter 3: System planning Administration {"", }, {"", }, {"", }, {"", }, {"", }, {"", }, /*TR104 for VOIP setting*/ {"Services", }, {"VoiceService", }, {"1", }, {"VoiceProfileNumberOfEntries", }, {"Capabilities", }, {"MaxProfileCount", }, {"MaxLineCount", }, {"MaxSessionsPerLine", }, {"MaxSessionCount", }, {"SignalingProtocols", }, {"Regions", }, {"RTCP", }, {"SRTP", },...
Page 142 Chapter 3: System planning Administration {"EventSubscription", }, {"ResponseMap", }, {"", }, {"Codecs", }, {"1", }, {"EntryID", }, {"Codec", }, {"BitRate", }, {"PacketizationPeriod", }, {"SilenceSuppression", }, {"", }, {"", }, {"", }, {"VoiceProfile", }, {"1", }, {"Enable", }, {"Reset", }, {"NumberOfLines", }, {"Name", }, {"SignalingProtocol", }, {"MaxSessions", },...
Page 143 Chapter 3: System planning Administration {"UseCodecPriorityInSDPResponse", }, {"", }, {"RTP", }, {"LocalPortMin", }, {"LocalPortMax", }, {"DSCPMark", }, {"TelephoneEventPayloadType", }, {"", }, {"Line", }, {"1", }, {"Enable", }, {"Status", }, {"CallState", }, {"SIP", }, {"AuthUserName", }, {"AuthPassword", }, {"URI", }, {"", }, {"Codec", }, {"TransmitCodec", }, {"ReceiveCodec", },...
Page 144 Chapter 3: System planning Administration {"Session", }, {"1", }, {"SessionStartTime", }, {"SessionDuration", }, {"FarEndIPAddress", }, {"FarEndUDPPort", }, {"LocalUDPPort", }, {"", }, {"", }, {"Stats", }, {"ResetStatistics", }, {"PacketsSent", }, {"PacketsReceived", }, {"BytesSent", }, {"BytesReceived", }, {"PacketsLost", }, {"Overruns", }, {"Underruns", }, {"IncomingCallsReceived", }, {"IncomingCallsAnswered", }, {"IncomingCallsConnected", },...
Page 145: Diagnosis
Chapter 3: System planning Administration Diagnosis In this page, user can do packet trace, ping test and traceroute test to diagnose the device’s connection status. Table 82 Diagnosis Page 3-105...
Page 146 Chapter 3: System planning Administration Description 1. Packet Trace Users can use the packet trace feature to intercept packets which traverse the device. Click the Start button to start home gateway tracking and keep refreshing the page until the message trace shows to stop, click the Save button to save captured packets. 2.
Page 147: Operating Mode
Chapter 3: System planning Administration Operating Mode Table 83 Operating mode Description Choose the Operation Mode as Basic Mode or Advanced Mode. Page 3-107...
Page 148: System Log
Chapter 3: System planning Administration System Log Table 84 System log Description If you enable the system log in Status/syslog webpage, you can view the system log in this webpage. Logout Table 85 Logout Description Press the logout button to logout, and then the login window will appear. Reboot Press the button to reboot CnPilot Home device.
Page 149: Chapter 4: Managing Device Via Cnmaestro
Chapter 4: Managing device via cnMaestro cnMaestro is a suite of cloud-based tools for network management: inventory management, onboarding devices, daily operations and maintenance. cnMaestro offers full visibility across the entirety of a network. This chapter covers:  Preparing the device ...
Page 150: Preparing The Device
Chapter 4: Managing device via cnMaestro Preparing the device Preparing the device The prerequisites at device side are: Power on the cnPilot.Home R200/201. Configure the IP Address using either the DHCP or Static mode. Check for the Internet connectivity. This is required, as the device needs to communicate with the cnMaestro Server hosted in the AWS.
Page 151: Login To Cnmaestro
Open a browser session and launch the URL https://cloud.cambiumnetworks.com Sign in using your Cambium support center account credentials if you already have an Account or click the link "Click Here to Register" for the registration After sign in, create the company Account (it requires Approval from the Solutions@cambiumnetworks.com to create an account)
Page 152 Chapter 4: Managing device via cnMaestro Login to cnMaestro If the user has single company account, he will be automatically redirected to that account after log in. If the user has multiple accounts, once signed in the user needs to select the company account he wants to access.
Page 153: On Boarding Using Serial Number
The device can be On Boarded using  Serial Number or  Cambium ID. On Boarding using Serial Number The devices can be On Boarded on cnMaestro using device’s Serial Number. The procedure is supported for the cnPilot R200/R201 Devices.
Page 154: Onboarding Using Cambium Id
On Boarding of cnPilot R200/R201 Onboarding using Cambium ID The Cambium ID based On Boarding can be done either from cnPilot R200/R201 GUI or CLI (not from cnMaestro). Login to cnPilot R200/R201 GUI and navigate to Administration > cnMaestro page Enter the Cambium ID and On Boarding key and click Save.
Page 155: Configuring The Devices
Chapter 4: Managing device via cnMaestro Configuring the Devices Configuring the Devices Basic Details User can update device name and comments for a device. In case, user does not enter device name, it will be read from the device after On Boarding. The device basic details can be configured later from the Configure >Devices page.
Page 156: Firmware Update
The Firmware Update page allows the user to upgrade the software to the latest available image before the device is on boarded to cnMaestro. It also shows the current version if the device is claimed via Cambium ID. User can upgrade later through Operate > Software Update page. Figure 7 Firmware update...
Page 157: Figure 8 Configure Devices
Chapter 4: Managing device via cnMaestro Configuring the Devices Figure 8 Configure devices Page...
Page 158: Approving On Boarded Devices
Chapter 4: Managing device via cnMaestro Approving On Boarded devices Approving On Boarded devices The approval procedure for On Boarded devices are: Device goes through the following states based on the device trying to connect to the CnMaestro Server : State Approval state Details...
Page 159: Unclaiming The Devices
Chapter 4: Managing device via cnMaestro Unclaiming the Devices Unclaiming the Devices The device unclaiming procedure is as follows: Figure 9 Unclaiming the devices If the user wants to delete the devices from his account he need to go to the Operate >On Board Devices>...
Page 160: Chapter 5: Troubleshooting Guide
Chapter 5: Troubleshooting Guide This chapter covers:  Configuring PC to get IP Address automatically  Cannot connect to the Web GUI  Forgotten Password  Fast Bridge Setting  cnMaestro On Boarding troubleshooting Page...
Page 161: Configuring Pc To Get Ip Address Automatically
Chapter 5: Troubleshooting Guide Configuring PC to get IP Address automatically Configuring PC to get IP Address automatically Follow the below process to set your PC to get an IP address automatically: Step 1 : Click the “Start” button Step 2 : Select “control panel”, then double click “network connections” in the “control panel” Step 3 : Right click the “network connection”...
Page 162: Forgotten Password
Chapter 5: Troubleshooting Guide Configuring PC to get IP Address automatically Forgotten Password If you have forgotten the management password, you cannot access the configuration web GUI. Solution: To factory default: press and hold reset button for 10 seconds. Fast Bridge Setting Description Step 1: Login Web GUI of the device.
Page 163 Chapter 5: Troubleshooting Guide Configuring PC to get IP Address automatically Step 3: Login from WAN port. See example page Status->Basic. Page...
Page 164: Cnmaestro On Boarding Troubleshooting
Chapter 5: Troubleshooting Guide cnMaestro On Boarding troubleshooting cnMaestro On Boarding troubleshooting The On Boarding troubleshooting procedure is described below: If during the Cambium ID on boarding if the device dashboard or home page shows the cnMaestro Connection status as Error Status Cause...
Page 165 Account ID is the Cambium ID or Account Name chosen while creating the company account which indicates that the device belongs to that account. cnMaestro Account ID will be blank when the device is not claimed and will be populated when the device is cliamed in the cnMaestro server.
Page 166: Quick Installation Procedure For Router
Chapter 5: Troubleshooting Guide Quick Installation procedure for Router Quick Installation procedure for Router 1. Power ON the wireless router using the power supply/PoE. POWER LED will glow after 5 seconds of powering ON and wait for 2 minutes to boot up device properly. 2.
Page 167: Glossary
Glossary Term Definition Advanced Technology Attachment Address Resolution Protocol defined in RFC 826 to allow a network element to correlate a Protocol host IP address to the Ethernet address of the host. See http://www.faqs.org/rfcs/rfc826.html. Bridge Network element that uses the physical address (not the logical address) of another to pass data.
Page 168 Glossary Term Definition HTTP Hypertext Transfer Protocol, used to make the Internet resources available on the World Wide Web. Defined in RFC 2068. See http://www.faqs.org/rfcs/rfc2068.html. HTTPS Hypertext Transfer Protocol Secure (HTTPS) ICMP Internet Control Message Protocols defined in RFC 792, used to identify Internet Protocol (IP)-level problems and to allow IP links to be tested.
Page 169 Glossary Term Definition NetBIOS Protocol defined in RFC 1001 and RFC 1002 to support an applications programming interface in TCP/IP. This interface allows a computer to transmit and receive data with another host computer on the network. RFC 1001 defines the concepts and methods. RFC 1002 defines the detailed specifications.
Page 170 Glossary Term Definition Static IP Address Assignment of Internet Protocol address that can be changed only Assignment manually. Thus static IP address assignment requires more configuration time and consumes more of the available IP addresses than DHCP address assignment does. RFC 2050 provides guidelines for the static allocation of IP addresses.
Page 171 Glossary Term Definition WPA2-PSK Wi-Fi Protected Access 2 - Pre-Shared Key, and also called WPA or WPA2 Personal, it is a method of securing your network using WPA2 with the use of the optional Pre-Shared Key (PSK) authentication, which was designed for home users without an enterprise authentication server.

This manual is also suitable for:

Cnpilot home r201p Cnpilot home r201w Cnpilot home r200p Cnpilot home r201

Cambium cnPilot Home R200 User Manual

Chapter 1: Product Description

Chapter 2: Configuring Basic Settings

Chapter 3: System Planning

Chapter 4: Managing Device Via Cnmaestro

Chapter 5: Troubleshooting Guide

Quick Links

User Guide

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cambium cnPilot Home R200

This manual is also suitable for:

Table of Contents
