- Page 1 Wide Body Cabinet - Cashline™ Seiko PSA-66 Ticket Printer Rev. 1.2 www.atronic.com June 2004...
-
Page 2: Release Info
ELEASE Wide Body Cabinet (WBC) - Cashline™ Seiko PSA-66 Ticket Printer Rev. 1.2 Rel. June 2004 © 2001 - 2005 Atronic International GmbH. All rights reserved. June 2004... - Page 3 NTRODUCTION Ticket Printer Seiko Instruments Model PSA-66-ST Caution: The printer is not hot-connect- able and any attempt to do so can permanently damage the printer! Introduction The PSA-66 thermal printing subassembly is de- signed for coinless gaming machines as well as a broad range of kiosk applications.
-
Page 4: Operator Controls And Indicators
OMPONENTS Components Front Bezel Display Error! LED Status LED FEED Button CUT Button (no function) Platen Release Lever Paper Insertion Slot Ribbon Cable Operator Controls and Indicators The printer is equipped with 2 status indicators and 2 operator controls to allow the operator to know the status of the printer at all times. -
Page 5: Paper Loading
ANDLING Paper Loading Generally, the only service required for the printer is to load new paper stacks. The automatic paper loading feature of this system simplifies this pro- cess to essentially two steps; putting the paper stack into the printer Paper Tray, and presenting paper to the Paper Feed Slot in the printer. -
Page 6: Paper Out
ANDLING Keypad LED Operation and Printer Status Conditions The keypad LEDs provide a more detailed reporting of system status. The Table below lists the status of the keypad LEDs in a variety of status which are defined following. Although there are a variety of error conditions which can occur, most printer errors are a result of the printer running out of paper or the operator lowering the Platen lever. -
Page 7: Print Head Error
ANDLING PLATEN DOWN: This condition results from lowering the head release lever (Platen Lever). To remedy the error, it is necessary to raise the blue lever on the side of the unit. TEMPERATURE ERROR: This condition results Note: when the printer is in an over temperature condi- Ambient temperature under tion. -
Page 8: Clearing A Paper Jam
ANDLING Paper Feed Operation The printer has been designed to run with black mark indexed paper. Paper feeding is accomplished by use of the feed button. Each long press (~1 sec- ond) of the feed key will result in paper being ad- vanced to the top of the next form. -
Page 9: Servicing The Printer
ANDLING Servicing the printer Should the printer require service outside of the Caution: game, the sliding module which includes the major- The printer is not hot-connect- ity of electronics may be easily removed and replaced. able and any attempt to do so can permanently damage the Removing the Inner Module printer! -
Page 10: Pin Function
ONNECTORS Seiko Printer Connections Bezel Port Pinout Bezel Port (Front View) Function Modulated +24VDC No Connection Base Printer Port Pinout Base Printer Port (Bottom View) PIN FUNCTION No Connection No Connection No Connection No Connection No Connection No Connection +24V No Connection RS232 GND RS232 RXD... - Page 11 ONNECTORS Universal Dipswitches (Bottom View) Note: Dipswitch setting for use in Atronic machines (RS-232 mode) is: Function Configuration Reserved Switches 1-6 must allways be left off Interface Select Netplex RS-232 Comm. Protocoll 8=OFF 9=OFF Illegal setting 8=ON 9=OFF serial 38400, N, 8, 1...
-
Page 12: Sensor Operations
ENSOR PERATIONS Sensor Operations Paper Out Sensor The paper out sensor is located within the pivoting printer head module and is used to terminate the print operation when paper has run completely out, and for proper form registration. The PSA-66-ST will cease printing and feeding operations once a paper out condition is detected. -
Page 13: Spare Parts
PARE ARTS Spare Parts Seiko Printer 65011225 1 Bezel Assy. 65016233 2 Control Panel (Keypad) 65018117 3 Low Paper Assy. 65018113 4 Ticket Taken Assy. 65018116 5 Bezel Port 65018115 6 Motherboard 65018111 7 Ribbon Cable 65018114 8 Daughterboard 65018112 June 2004...
