MPC netframe NF1610 Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
NetFRAME
Quick Start Guide
NF1610
NF2610
NF3610
NF6600

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the netframe NF1610 and is the answer not in the manual?

Questions and answers

Related Manuals for MPC netframe NF1610

Summary of Contents for MPC netframe NF1610

  • Page 1 ® NetFRAME Quick Start Guide NF1610 NF2610 NF3610 NF6600...

  • Page 3: Table Of Contents

    Table of Contents ....Copyright Notice ................... iii NF2610 Front Control Panel LED Description .......... 16 NF2610 Top Panel................17 Trademark Notice..................iii Limitation of Liability..................iii NF2610 Top Panel View ................
  • Page 4 NF6600 Front Control Panel View ............. 49 Back Panel View..................50 NF6600 Rack Optimized Chassis ............51 NF6600 Front Panel View................51 NF6600 Front Control Panel View ............. 52 NF6600 Back Panel View ................53 NF6600 Front Control Panel Descriptions.......... 54 NF6600 System Board Features.......

  • Page 5: Copyright Notice

    In no event will the manufacturer or seller of an MPC product be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 7: Welcome

    ........Thank you for buying an MPC NetFRAME server. This Quick Start Guide provides information to help you quickly get started using your new server.

  • Page 8: Manual Conventions

    W E L C O M E Manual Conventions M A N U A L C O N V E N T I O N S ..............

  • Page 9: Nf1610 System Features

    NF1610 S YSTEM EATURES ........The following chapter provides information about the components and connectors on your server.

  • Page 10: Nf1610 Front Panel

    N F 1 6 1 0 S Y S T E M F E A T U R E S NF1610 Front Panel N F 1 6 1 0 F R O N T P A N E L ..............NF16 10 F ro nt P a nel V i ew Table 1 and Figure 1 identify the features on the front of your server.

  • Page 11: Nf1610 Back Panel

    N F 1 6 1 0 S Y S T E M F E A T U R E S NF1610 Back Panel N F 1 6 1 0 B A C K P A N E L ..............NF16 10 Ba c k Pa n el V ie w Table 2 and Figure 2 identify the connectors on the back panel of your chassis.

  • Page 12: Nf1610 Front Control Panel

    N F 1 6 1 0 S Y S T E M F E A T U R E S NF1610 Front Control Panel N F 1 6 1 0 F R O N T C O N T R O L P A N E L .

  • Page 13: Nf1610 Control Button Description

    N F 1 6 1 0 S Y S T E M F E A T U R E S NF1610 Front Control Panel NF16 10 Co nt ro l Bu tt on D es cr ip ti o n Table 4 describes the control button functions which are located on your server’s front control panel.

  • Page 14: Nf1610 Front Control Panel Led Description

    N F 1 6 1 0 S Y S T E M F E A T U R E S NF1610 Front Control Panel NF16 10 F ro nt Co nt ro l P a nel L E D D es cri p tio n Table 5 describes the LEDs located on your server’s front control panel.

  • Page 15: Nf1610 Top Panel

    N F 1 6 1 0 S Y S T E M F E A T U R E S NF1610 Top Panel N F 1 6 1 0 T O P P A N E L ..............NF16 10 T op P a nel V i ew Table 6 and Figure 4 identify the connectors on the top panel of your server chassis.
  • Page 16 N F 1 6 1 0 S Y S T E M F E A T U R E S NF1610 Top Panel 2-10...

  • Page 17: Nf2610 System Features

    NF2610 S YSTEM EATURES ........The following chapter provides information about the components and connectors on your server.

  • Page 18: Nf2610 Front Panel

    N F 2 6 1 0 S Y S T E M F E A T U R E S NF2610 Front Panel N F 2 6 1 0 F R O N T P A N E L ..............NF26 10 F ro nt P a nel V i ew Table 7 and Figure 5 identify the features on the front of your server.

  • Page 19: Nf2610 Back Panel

    N F 2 6 1 0 S Y S T E M F E A T U R E S NF2610 Back Panel N F 2 6 1 0 B A C K P A N E L ..............NF26 10 Ba c k Pa n el V ie w Table 8 and Figure 6 identify the connectors on the back panel of your chassis.

  • Page 20: Nf2610 Front Control Panel

    N F 2 6 1 0 S Y S T E M F E A T U R E S NF2610 Front Control Panel N F 2 6 1 0 F R O N T C O N T R O L P A N E L .

  • Page 21: Nf2610 Control Button Description

    N F 2 6 1 0 S Y S T E M F E A T U R E S NF2610 Front Control Panel NF26 10 Co nt ro l Bu tt on D es cr ip ti o n Table 10 describes the control button functions which are located on your server’s front control panel.

  • Page 22: Nf2610 Front Control Panel Led Description

    N F 2 6 1 0 S Y S T E M F E A T U R E S NF2610 Front Control Panel NF26 10 F ro nt Co nt ro l P a nel L E D D es cri p tio n Table 11 describes the LEDs located on your server’s front control panel.

  • Page 23: Nf2610 Top Panel

    N F 2 6 1 0 S Y S T E M F E A T U R E S NF2610 Top Panel N F 2 6 1 0 T O P P A N E L ..............NF26 10 T op P a nel V i ew Table 12 and Figure 8 identify the connectors on the top panel of your server chassis.
  • Page 24 N F 2 6 1 0 S Y S T E M F E A T U R E S NF2610 Top Panel 3-18...

  • Page 25: Nf1610/2610 System Board Features

    NF1610/2610 S YSTEM OARD EATURES ........The following chapter provides information about your server’s system board, memory, and jumpers.

  • Page 26: Nf1610/2610 System Board Components

    N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 System Board Components N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D C O M P O N E N T S .
  • Page 27 N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 System Board Components Table 13: NF1610/2610 System Board Components Letter Component Description Letter...

  • Page 28: Nf1610/2610 Memory Specifications

    N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 Memory Specifications N F 1 6 1 0 / 2 6 1 0 M E M O R Y S P E C I F I C A T I O N S .

  • Page 29: Nf1610/2610 Memory Bank Order

    N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 Memory Specifications NF16 10/ 2 610 M emo ry Ba nk O rd e r The figure below shows the location of the memory banks and how the banks are partitioned.

  • Page 30: Nf1610/2610 System Board Jumpers

    N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 System Board Jumpers N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D J U M P E R S .
  • Page 31 N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 System Board Jumpers Table 14: NF1610/2610 Configuration Jumper Options Jumper Block Description .
  • Page 32 N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 System Board Jumpers E X T E R N A L R J - 4 5 S E R I A L P O R T J U M P E R B L O C K The rear RJ-45 serial port is a fully functional serial port that supports any standard serial device and provides support for serial concentrators.
  • Page 33 N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 System Board Jumpers DCD-DTR to Pin #7 DSR-DTR to Pin #7 Figure 12.
  • Page 34 N F 1 6 1 0 / 2 6 1 0 S Y S T E M B O A R D F E A T U R E S NF1610/2610 System Board Jumpers D B 9 S E R I A L C O N N E C T O R For those server applications that require a DB9 serial connector, you must use an 8-pin RJ-45- to-DB9 adapter.

  • Page 35: Nf3610 System Features

    NF3610 S YSTEM EATURES ........The following chapter provides information about the components and connectors on your server.

  • Page 36: Nf3610 Pedestal/Rack Chassis

    N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Pedestal/Rack Chassis N F 3 6 1 0 P E D E S T A L / R A C K C H A S S I S .

  • Page 37: Nf3610 Back Panel View

    N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Pedestal/Rack Chassis NF36 10 Ba c k Pa n el V ie w Table 17 and Figure 14 identify the connectors on the back panel of your pedestal/rack chassis. Table 17: NF3610 Pedestal/Rack Chassis Back Panel Connectors...

  • Page 38: Nf3610 Pedestal/Rack Chassis W/Hot-Swap Power Supply

    N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Pedestal/Rack Chassis w/Hot-Swap Power Supply ..............N F 3 6 1 0 P E D E S T A L / R A C K C H A S S I S W / H O T - S W A P P O W E R S U P P L Y NF36 10 F ro nt P a nel V i ew Table 18 and Figure 15 identify the features on the front panel of your server.

  • Page 39: Nf3610 Back Panel View

    N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Pedestal/Rack Chassis w/Hot-Swap Power Supply NF36 10 Ba c k Pa n el V ie w Table 19 and Figure 16 identify the connectors on the back panel of your server. Table 19: NF3610 Pedestal/Rack Chassis with Hot-Swap Power Supply Back Panel Connectors...

  • Page 40: Nf3610 Front Control Panel View

    N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Front Control Panel View N F 3 6 1 0 F R O N T C O N T R O L P A N E L V I E W .

  • Page 41: Nf3610 Rack Chassis Front Control Panel View

    N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Front Control Panel View NF36 10 R a ck C ha ss is Fr on t Co nt ro l Pa ne l V iew Table 21: NF3610 Rack Chassis with/without a Hot-Swap Power Supply Front Control Panel Components...

  • Page 42: Nf3610 Front Control Panel Led Description

    N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Front Control Panel View NF36 10 F ro nt Co nt ro l P a nel L E D D es cri p tio n Table 22 describes the LEDs located on your server’s front control panel.
  • Page 43 N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Front Control Panel View Table 22: NF3610 Front Control Panel LED Description (Continued) Feature Color Condition Description ... .
  • Page 44 N F 3 6 1 0 S Y S T E M F E A T U R E S NF3610 Front Control Panel View 5-38...

  • Page 45: Nf3610 System Board Features

    NF3610 S YSTEM OARD EATURES ........The following chapter provides information about your server’s system board, memory, and jumpers.

  • Page 46: Nf3610 System Board Components

    N F 3 6 1 0 S Y S T E M B O A R D F E A T U R E S NF3610 System Board Components N F 3 6 1 0 S Y S T E M B O A R D C O M P O N E N T S .
  • Page 47 N F 3 6 1 0 S Y S T E M B O A R D F E A T U R E S NF3610 System Board Components Table 23: NF3610 System Board Components ..Letter .

  • Page 48: Nf3610 Memory Specifications

    N F 3 6 1 0 S Y S T E M B O A R D F E A T U R E S NF3610 Memory Specifications N F 3 6 1 0 M E M O R Y S P E C I F I C A T I O N S .

  • Page 49: Nf3610 System Board Jumpers

    N F 3 6 1 0 S Y S T E M B O A R D F E A T U R E S NF3610 System Board Jumpers N F 3 6 1 0 S Y S T E M B O A R D J U M P E R S .
  • Page 50 N F 3 6 1 0 S Y S T E M B O A R D F E A T U R E S NF3610 System Board Jumpers ..........Caution Some jumpers have a small tab on top that you can grip with your fingertips, forceps, or with a pair of fine needle-nosed pliers.
  • Page 51 N F 3 6 1 0 S Y S T E M B O A R D F E A T U R E S NF3610 System Board Jumpers Table 24: NF3610 Jumper Configuration Jumper Jumper Name Letter Pins Description .
  • Page 52 N F 3 6 1 0 S Y S T E M B O A R D F E A T U R E S NF3610 System Board Jumpers 6-46...

  • Page 53: Nf6600 System Features

    NF6600 S YSTEM EATURES ........The following chapter provides information about the components and connectors on your server.

  • Page 54: Nf6600 Pedestal Chassis

    N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Pedestal Chassis N F 6 6 0 0 P E D E S T A L C H A S S I S .

  • Page 55: Nf6600 Front Control Panel View

    N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Pedestal Chassis NF66 00 F ro nt Co nt ro l P a nel V i ew Table 26 and Figure 22 identify the buttons and LEDs on the front control panel of your pedestal server.

  • Page 56: Back Panel View

    N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Pedestal Chassis Ba ck P a nel V iew Table 27 and Figure 23 identify the connectors on the back panel of your pedestal server. Table 27: Pedestal Chassis Back Panel Connectors Optional VHDCI SCSI &...

  • Page 57: Nf6600 Rack Optimized Chassis

    N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Rack Optimized Chassis ..............N F 6 6 0 0 R A C K O P T I M I Z E D C H A S S I S NF66 00 F ro nt P a nel V i ew Table 28 and Figure 24 identify the features on the front panel of your rack optimized server.

  • Page 58: Nf6600 Front Control Panel View

    N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Rack Optimized Chassis NF66 00 F ro nt Co nt ro l P a nel V i ew Table 29 and Figure 25 identify the buttons and LEDs on the front control panel of your rack optimized server.

  • Page 59: Nf6600 Back Panel View

    N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Rack Optimized Chassis NF66 00 Ba c k Pa n el V ie w Table 30 and Figure 26 identify the connectors on the back panel of your server. Table 30: Rack Optimized Chassis Back Panel Connectors Power supply AC inlet 1 &...

  • Page 60: Nf6600 Front Control Panel Descriptions

    N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Front Control Panel Descriptions N F 6 6 0 0 F R O N T C O N T R O L P A N E L D E S C R I P T I O N S .

  • Page 61: Feature Description

    N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Front Control Panel Descriptions Table 31: NF6600 Front Control Panel Feature Description (Continued) Feature Description ....
  • Page 62 N F 6 6 0 0 S Y S T E M F E A T U R E S NF6600 Front Control Panel Descriptions 7-56...

  • Page 63: Nf6600 System Board Features

    NF6600 S YSTEM OARD EATURES ........The following chapter provides information about your server’s system board, memory, processors, and jumpers.

  • Page 64: Nf6600 System Board Components

    N F 6 6 0 0 S Y S T E M B O A R D F E A T U R E S NF6600 System Board Components N F 6 6 0 0 S Y S T E M B O A R D C O M P O N E N T S .
  • Page 65 N F 6 6 0 0 S Y S T E M B O A R D F E A T U R E S NF6600 System Board Components Table 32: NF6600 System Board Components Letter Component Description Letter Component Description .
  • Page 66 N F 6 6 0 0 S Y S T E M B O A R D F E A T U R E S NF6600 System Board Components Table 32: NF6600 System Board Components (Continued) Letter Component Description Letter Component Description .

  • Page 67: Nf6600 Memory Specifications

    N F 6 6 0 0 S Y S T E M B O A R D F E A T U R E S NF6600 Memory Specifications N F 6 6 0 0 M E M O R Y S P E C I F I C A T I O N S .

  • Page 68: Memory Bank Order

    N F 6 6 0 0 S Y S T E M B O A R D F E A T U R E S NF6600 Memory Specifications Me m or y Ba nk Or d er Load the DIMMs in the following order: Bank 1: DIMMs # 1, 2, 3, and 4 Bank 2: DIMMs # 5, 6, 7, and 8 Bank 3: DIMMs # 9, 10, 11, and 12...

  • Page 69: Nf6600 Processor Specifications

    N F 6 6 0 0 S Y S T E M B O A R D F E A T U R E S NF6600 Processor Specifications N F 6 6 0 0 P R O C E S S O R S P E C I F I C A T I O N S .

  • Page 70: Nf6600 System Board Jumpers

    N F 6 6 0 0 S Y S T E M B O A R D F E A T U R E S NF6600 System Board Jumpers N F 6 6 0 0 S Y S T E M B O A R D J U M P E R S .
