WARRANTY
Your SENSIT®GOLD is warranted to be free from defects in
materials and workmanship for a period of two years after pur-
chase (excluding calibration and batteries). If within the war-
ranty period, your instrument should become inoperative from
such defects, the unit will be repaired or replaced at our option.
This warranty covers normal use and does not cover damage
which occurs in shipment or failure which results from alteration,
tampering, accident, misuse, abuse, neglect or improper main-
tenance. Proof of purchase may be required before warranty is
rendered. Units out of warranty will be repaired for a service
charge. Internal repair or maintenance must be completed by a
J And N authorized technician. Violation will void warranty. Units
must be returned postpaid, insured and to the attention of the
Service Dept. for warranty or repair.
This warranty gives you specific legal rights and you may have
other rights which vary from state to state.
J And N Enterprises, Inc.
851 Transport Drive
Valparaiso, IN 46383
Phone: (800) 820-6199
Fax: (219) 465-2701
(219) 465-2700
10/03 UL-V1
SENSIT®GOLD
INSTRUCTION MANUAL
For use with Combustible Gases
and optionally available
Oxygen and Toxic Gases
Read and understand
instructions before use.
7WA6
Approved UL913, For Class 1,
Division 1, Groups C & D
hazardous locations when used
with alkaline batteries.
Warning:
To prevent ignition
of flammable or
combustible
atmospheres,
disconnect power
before servicing.
J And N Enterprises, Inc.
851 Transport Drive
Valparaiso, IN 46383
Phone: (800) 820-6199
(219) 465-2700
Fax: (219) 465-2701
www.gasleaksensors.com
