CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Reminder The machine uses a parallel interface and control computer connected through the parallel port control software MACH3 controlled carving machine to run the various axes in...
Page 4
Hong Kong office of CNCDIY Routing Machine System after providing photos to show the damage part and proving the causes of the problem to our staff. It is entirely up to CNCDIY Routing Machine System to determine whether a repair is to be considered under warranty.
Chapter 1 Introduction Thank you for your selection of our product. We have provided CNCDIY routing machine system, also very honored that you have the time to read, prepared by the Walter, "Quick Start Guide" in the hope of its initial contact with routing machine will be able to help! This is not a company.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Chapter 3 Hardware Installation Installation Precaution The CNC Routing Machine system contains numerous delicate electronic circuits and components which can become damaged. Prior to installation, carefully read the user’s manual...
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System 3-2 Understanding of Your Machine System For the future use and maintenance, user should understand your routing machine system first. The major parts are shown in below figure and include a set of routing machine, a CNC control box, spindle with bracket, and an attachment box.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System 3-4 Spindle (D57 and C57) Specifications The spindle is a used of ELECTROCRAFT E240 motor installed an ER11 chuck and a Plastic Cooling Fan. The original is a DC servo motor, it is a waste and the encoder has been damaged.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Stepping Motor Specifications The stepping motors are selecting the new Chinese stepping motors or used Japanses and USA stepping motors. Specification Machine Model CNC3040 CNC3020 Unit Stepping Motor Model...
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Components Check A check listed is shown in Figure 3.6 below. Please check them with your received components and pull a tick or an across for record.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Tools and Materials Requirement In this chapter, there are discuss the major tools for the assembly work! Figure 3.7 Tools list A. Mechanical Part Tools Name Description...
Page 14
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System The nuts and crank bolts installation Spanner The small adjustment and part assemble! Hammer (Plastic) B. Electrical Parts Tools Name Description Picture To melt the solder for wire connection.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Machine Installation There are shown the assemble step for your following! The following table are shown the tips when you doing the assembling work! Tools Name ICON...
Page 16
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Stepping Motor Part 1 The flat side of Component Clearance the shaft is connecting with the bolt of knob for locking! The wires are Z Axis Part Completed! through the hold! ...
Page 17
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Gantry Part 2 17 ...
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Electrical Connection The machine and the CNC control box are separated. Therefore, you need to connect each cable. Please connect them be carefully. 3-9-1 Spindle’s Cable Connection 3-9-1-1 Pins Connecting Head of Spindle’s Cable Connection...
Page 21
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System 3-9-2 Stepping motor’s cable connection Each stepping motor is requested four wires. They are representing A+, A-, B+ and B-. The A+ and A- is the same coil, the B+ and B- is another coil. (Please refer to the related CNC control box user’s manual) Therefore, please do not connect them wrong.
Page 22
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 3 Assuming the poles for step 2 After find out the group of wires, you can assume that one group is A coil and the other group is B coil! The A+ pole and the A- pole can be exchanged.
Page 23
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System 3-9-3 Understanding the direction of the axis There are two types of axes direction setting. The major different are exchanged the X axis and Y axis. Before you connect the control box with the stepping motors, please understand and confirm the following setting.
Page 24
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System 3-9-4 Final Connection At the back of the control box, there are also requested to connect the electrical power supply cable and the computer parallel port cable.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System 3-10 Basic Testing with CNC Control Box Step 1 Interconnection Check This is a preliminary test to confirm the interconnection between the CNC control box and the engraving machine.
Page 26
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 5 Spindle Test Then, we switch off the drive power and set the spindle speed control knob to "Safe Place" position. (Please refer to the related CNC control box user’s manual) After that, you can turn on the spindle power switch and justifying the spindle speed control knob clockwise slowly.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Chapter 4 Installation of Mach 3 Software The Mach 3 is one of most common CNC control interface for Microsoft Windows’s users. The setting of the Mach 3 is very easy for your CNC control! It will help you to set up the basic settings and show the useful function in Mach 3 for you.
Page 28
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 2 Select the “Ports and Pins” menu Open the “Ports & Pins” menu under the “config” menu. Step 3 Setting the frequency of the parallel port Select “Port Setup and Axis Selection”...
Page 29
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 4 Select Units Open the “Select Native Units” menu under the “config” menu. Select the suitable units for you system and press “OK” to confirm! Step 5...
Page 30
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 6 – Input Signals Setting Select the “Intput Signals” columns and change the “Pin Number”. 30 ...
Page 31
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 7 Output Signals Setting Select the “Output Signals” columns and change the parameter as below: Step 8 Finish the setting Select “OK” to confirm 31 ...
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Stepping motor setting in Mach 3 with different coupling type The procedure of motor setting is discussed in follow: Step 1 Open the Motor setting dialog Select the “Motor Tuning” under the “Config” menu.
Page 33
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 3 Parameters of stepping motor The suggested settings for different unit are shown in the table below: A. For millimeter unit use Steps per Velocity Acceleration...
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Load a G code file After completed all setting, you can open and run a G-code file into Mach 3. Step 1 Open a G code file Select “Load G Code”...
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 3 Start running the G code You can see the red flashing “RESET” button, and click it to stop the flashing, after that please select the “Cycle Start” button or press <Alt> and <R> keys on your key board to run the G code.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Chapter 5 Installation of EMC2 Software The EMC2 is a famous CNC control interface for Linux’s users. It will guide you to complete setting the parameters for you machine and show the useful function in EMC2 for you.
Page 37
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 3 Create a new CNC Configuration Select the checkbox of the “Create a new Configuration” and Check the “Forward” button for next. Step 4 Entering the Basic Machine Information Please follow the below setting! ...
Page 38
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 5 Setting up the Parallel Port Please follow the below setting for you parallel port! You can find the related information in the “Parallel port interface definition” of the CNC Controller Specification: The invert signal checkbox next to every signal is an importance functions.
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Stepping motor setting in EMC2 different coupling type The life of coupling is affect by the stepping motor speed and the type of processing materials. We are provided two type of coupling for each user. The first type is flexible coupling and the other type is simple coupling.
Page 40
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 1 Parameters of stepping motor (continue) The suggested settings for different unit are shown in the table below: A. For millimeter unit use Seg. Description Unit Motor steps per revolution 200.0...
Page 41
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 2 Axis Test Please the “Test this axis” button at the top right hand comer. You can enter any value for each item to test the response of each axis You can check the “Run”...
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Chapter 6 Test Your System In this Chapter, we use a g code file of a word “CNC” to discuss for you! Step 1 Fixing the carving material 1.
Page 43
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 3 Find the original location Turning on the drive power switch of the CNC control box and using the software manual control function to move all axes to the start point as the below image.
Page 44
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Step 5 Start running with tooling Install a miller tool in the spindle and the chuck should have a distance between the chunk and the surface of the workpiece at least one cm or more. After that, locking the cutting tool with the spindle handles.
Page 45
CNC 6040 Router / Engraver System User’s Manual CNCDIY CNC Routing Machines System Attention Note: If any accident happening during the processing (such as a sudden out of step wrong, the spindle suddenly stop, etc.), press the e- stop button on the CNC control box immediately, or use the mouse to click "emergency stop"...
