- Page 1 Hz – High Resolution ® Therm-App Mobile Thermal Imaging Device Operation Manual ® Copyright © 2016 Therm-App All rights reserved Updated to Version 2.5.0 January 2017...
-
Page 2: Table Of Contents
Product Description ................... 5 Quick Start Guide ..................6 Android Device Minimum Requirements ............7 ® Contents of Therm-App Hz Box ..............7 Installation ....................7 Set Up ...................... 8 Application Operation ................9 Settings ....................11 Specifications ..................17 Troubleshooting .................. -
Page 3: Safety And Caution Notes
Read this document in full, as well as the warranty document provided with the product. Therm-App ® Hz is a Class B digital product. This product has been tested and found to comply with the limits for a Class B digital product, pursuant to Part 15 of the U.S. FCC Rules. - Page 4 Therm-App device. Removing this label or the S/N label will void the warranty. As with most electronic products, the Therm-App ® Hz device must be disposed of in an environmentally friendly manner and in accordance with existing regulations for electronic waste. Please contact our support team at support@therm-app.com...
-
Page 5: Product Description
Therm-App Hz device housing [2] Sizing knob [3] – adjusts to fit Android devices. Attachment bracket [4] – connects the Therm-App ® Hz device with the Android device. USB-OTG port [5] – for communication with the Android device. -
Page 6: Quick Start Guide
Therm-App Operation Manual Quick Start Guide ® Before using Therm-App Hz, make sure Android device is compatible with Quick Start Guide. Quick Start Guide 1. Verify that you have a stable internet ® connection before installing the Therm-App application on your Android device. -
Page 7: Android Device Minimum Requirements
3. Therm-App requires the use of a USB-OTG cable (male to male, micro USB). *Please note: Most off-the-shelf cables are not USB-OTG and will not operate with the Therm-App ® device. Use only the USB-OTG cables that are provided with the product. -
Page 8: Set Up
Note: For the first use of the Therm-App ® Hz device with an Android device, an initialization process must be completed. This process may take a few minutes and must not be interrupted. Make sure you... -
Page 9: Application Operation
Android device, proceed as follows: 1. Select Use by default for this USB device check ® box and tap OK. The Therm-App application will automatically start and display the Terms and conditions screen. 2. Review and accept the Terms and conditions. - Page 10 ® Therm-App Operation Manual App Screen layout Upper toolbar [1] Image display [2] Lower toolbar [3] Upper Toolbar Settings button [1] – For configuring ® Therm-App settings (for a detailed settings explanation, see page 12). ...
-
Page 11: Settings
[5] Configure Temperature Alerts: After you have turned on temperature alerts [3] you can ® set the Therm-App Hz to flash a red alert when it finds something below a certain temperature (snowflake icon) or above a certain temperature, (fire icon). The box flashes red once a subject inside it crosses the preset temperature. - Page 12 (See page 16 for full walkthrough). Maintenance – Performs bad pixel repair and resets all parameters to default. Help – Link to User Manual, Therm-App ® Support, and Terms of Use. About – General application and device ...
- Page 13 ® Therm-App Operation Manual Thermography Settings Adjusting Emissivity – Emissivity is the ability of the surface of a material to emit energy as thermal radiation. The emissivity value (0 – 1) represents the ratio of energy radiated by the observed material to the energy radiated by a black body at the same temperature.
- Page 14 Hz will take an image capture at set intervals. Once enabled, activate by holding down the snapshot icon for a few seconds. Hit the snapshot icon again once to stop the process. VR Mode – Use this mode when Therm-App ® Hz is connected to virtual reality (VR) goggles (not included, and available in full screen mode only).
- Page 15 (PC, Tablet, Smartphone) connected to The Internet. Multiple devices can view the stream from a single Therm-App Hz. A solid internet connection is ® required to obtain good video quality. To activate video streaming: ®...
- Page 16 Custom Logo – After adding your custom logo in ® .PNG format to the Therm-App folder on your device, you can check this box to add your logo at the bottom of each image captured (it will replace ®...
-
Page 17: Specifications
® Therm-App Operation Manual Specifications Smartphone Minimal Requirements Android 4.1 and above, supporting USB OTG (a.k.a USB Host) Hardware Imager 384 x 288 microbolometer LWIR 7.5 -14µm 6.8mm lens (55° x 41°) 13mm lens (29° x 22°) Optics 19mm lens (19° x 14°) - Default 35mm lens (11°... -
Page 18: Troubleshooting
® Therm-App Hz and the Android device are connected properly via a USB-OTG cable. To verify that your cable is OTG compatible: 1. Plug the USB OTG cable into the Android device USB port. 2. Verify that the USB connector connected message appears on top of the screen. - Page 19 Therm-App Hz device. Ensure that nothing is obstructing the view of ® the Therm-App Hz device and that the line of sight is not blocked by glass or other transparent materials. Check that the camera lens is clean. Unfocused Image blurred Turn the lens focus ring while pointing the ®...
