OV Solutions SJ-L-DSL User Manual

User Manual
Ethernet Extender
Model Number: SJ-L-DSL
Product Description
SJ-L-DSL is a network signal extension device, which
consists of remote unit and local unit. It can transmit
network signal via two-wire such as
etc. The distance can reach
or coaxial cable,
and max bandwidth can be up to 148Mbps.
3,000m
Meanwhile, it also can transmit telephone signal
when transmitting network signal
additional splitter). This device can be widely
applied in network signal extending system, network
security system, network information distribution
system, network renovation and expansion systems,
railway, urban traffic, mining and telecommunication,
etc.
CAT5, telephone
(adding an
Connection Diagram
Terminal and Dimension
Complete Installation Guide
Product Features
◆ Long distance transmission as far as 3,000m
◆ Max transmission rate reach 148Mbps; 1,200m can reach
30Mbps
◆ Easy installation, CAT5, telephone or coaxial cable are
available
◆ Communication rate adaptive, no need to adjust
◆ Excellent real-time function, strong anti-interference
