Battery Installation continued
Re-install the polymer section of the battery
cradle using the most convenient bolt holes
available. For a more secure fit, drill carefully
into the frame at a perpendicular angle so
you can mount additional fasteners that
secure through the frame and tighten with
a nut on the under side of the bicycle frame
down tube.
Re-install the 4 screws that secure the lower
part of the cradle cover. Now the battery
cradle installation is complete.
If drink bottle mounts aren't an option, there
are plenty of battery attachment options
other than the method above, such as:
1. Install the battery on a rear rack
(provided).
2. Drill through holes in your frame and
use high tensile steel bolts and lock nuts to
attach the cradle. If done correctly, this is a
very solid option and you will only need to
spend $2 on fasteners.
The cradle should always be secure and rigid
to avoid any vibrations or movement of the
battery.
