HOW TO ASSEMBLE & OPERATE YOUR FOOD PROCESSOR
1. Hold the bowl by the handle & lower it on
the food processor side of the unit. Turn the bowl
in an clockwise direction till the bowl locks in
place. Please ensure that the lug of the bowl
precisely fits into the slot on the grinder unit.
2. Select the blade accessory as required. Fit the
blade in blade holder, by pressing the required
blade into the blade holder disc. Put the blade
holder on the stem. Then Place the stem in the
processor Bowl.
3. Cover the food processor bowl with the bowl
cover. Turn the cover in
direction, to lock with the "click" sound. Please
ensure that the bowl cover fits perfectly into the
slot provided on the grinder unit. If it is not
fitted properly the safety switch will not come on
and food processor will not start.
4. Place the safety cover of the mixer portion on
the grinder unit & lock it in clockwise direction.
This will activate another safety switch. If not
properly locked the switch will not function &
the motor will not start.
5. Plug in the food processor to a wall AC outlet
socket. Your food processor is now ready for use.
6. To open the food processor bowl, press the
locking button on top of the food processor
near the safety cover and turn the bowl cover
in a anticlock wise direction. Disassemble in the
reverse away as shown above.
a clockwise
Disc Blade Assembly
S.S. Blade Assembly
8
HOW TO ASSEMBLE & OPERATE YOUR MIXER GRINDER
Select the jar you want to use.
1. Fill the jar up to the blade level for mini
-mum quantity of grinding. Cover the jar
with the dome.
2. Place the jar in the top casing of the
grinder unit on the mixer side. Ensure that
the locking wedge provided at the base of
the jar fits snugly in the groove provided in
the top casing.
3. Lock the jar in place by turning it in a
clockwise direction. This will activate the
second safety switch of the mixer.
4. Fix the food processor bowl and cover as shown in the steps above. Do
not put any blades/discs or any attachments on the food processor side.
Ensure that the safety switch is activated on the food processor side by
locking the cover of the food processor bowl in the clockwise direction.
5. With both the grinder jar and food processor bowl locked in place,
switch on the grinder unit, first at low speed gradually increasing to the
speed required for the operation.
Grinding Jar & Chutney Jar
Before grinding all ingredients must be
thoroughly dried and if necessary, should
be put in the oven for a short while so
that all the moisture gets evaporated.
The jar should be filled at least up to blade level. For larger quantities of
dry grinding the jar should not be filled more than 3/4th of its capacity.
