8O - 60 RESTRAINTS
SIDE IMPACT SENSOR (Continued)
WARNING: TO AVOID PERSONAL INJURY OR
DEATH, NEVER STRIKE OR DROP THE SIDE
IMPACT SENSOR, AS IT CAN DAMAGE THE IMPACT
SENSOR OR AFFECT ITS CALIBRATION. THE SIDE
IMPACT SENSOR ENABLES THE SYSTEM TO
DEPLOY THE SIDE CURTAIN AIRBAGS. IF AN
IMPACT SENSOR IS ACCIDENTALLY DROPPED
DURING SERVICE,
SCRAPPED AND REPLACED WITH A NEW UNIT.
FAILURE TO OBSERVE THIS WARNING COULD
RESULT IN ACCIDENTAL,
IMPROPER SUPPLEMENTAL RESTRAINT DEPLOY-
MENT.
(1) Adjust the front seat to its most forward posi-
tion for easiest access to the lower B-pillar trim.
(2) Disconnect and isolate the battery negative
cable. Wait two minutes for the system capacitor to
discharge before further service.
(3) Remove the front outboard seat belt and retrac-
tor from the inside of the B-pillar. (Refer to 8 -
ELECTRICAL/RESTRAINTS/FRONT
SEAT BELT & RETRACTOR - REMOVAL - STAN-
DARD CAB).
(4) Remove the nut that secures the side impact
sensor stud to the inner B-pillar (Fig. 55).
Fig. 55 Side Impact Sensor Remove/Install -
Standard Cab
1 - SIDE IMPACT SENSOR
2 - WIRE HARNESS CONNECTOR
3 - B-PILLAR
4 - NUT
THE MODULE MUST
INCOMPLETE,
OUTBOARD
(5) Reach through the retractor mounting hole in
the inner B-pillar to access the side impact sensor
and disengage the locating pin and mounting stud
from the holes in the inner B-pillar.
(6) Pull the side impact sensor out of the B-pillar
far enough to access and disconnect the body wire
harness connector for the sensor from the sensor con-
BE nector receptacle.
(7) Remove the side impact sensor from the B-pil-
lar.
OR
REMOVAL - QUAD CAB
WARNING: TO AVOID PERSONAL INJURY OR
DEATH, ON VEHICLES EQUIPPED WITH AIRBAGS,
DISABLE THE SUPPLEMENTAL RESTRAINT SYS-
TEM BEFORE
WHEEL, STEERING COLUMN, AIRBAG, SEAT BELT
TENSIONER, IMPACT SENSOR, OR INSTRUMENT
PANEL COMPONENT DIAGNOSIS OR SERVICE.
DISCONNECT AND ISOLATE THE BATTERY NEGA-
TIVE (GROUND) CABLE, THEN WAIT TWO MINUTES
FOR THE SYSTEM CAPACITOR TO DISCHARGE
BEFORE PERFORMING FURTHER DIAGNOSIS OR
SERVICE. THIS IS THE ONLY SURE WAY TO DIS-
ABLE THE SUPPLEMENTAL RESTRAINT SYSTEM.
FAILURE TO TAKE THE PROPER PRECAUTIONS
COULD RESULT IN ACCIDENTAL AIRBAG DEPLOY-
MENT.
WARNING: TO AVOID PERSONAL INJURY OR
DEATH, NEVER STRIKE OR DROP THE SIDE
IMPACT SENSOR, AS IT CAN DAMAGE THE IMPACT
SENSOR OR AFFECT ITS CALIBRATION. THE SIDE
IMPACT SENSOR ENABLES THE SYSTEM TO
DEPLOY THE SIDE CURTAIN AIRBAGS. IF AN
IMPACT SENSOR IS ACCIDENTALLY DROPPED
DURING SERVICE,
SCRAPPED AND REPLACED WITH A NEW UNIT.
FAILURE TO OBSERVE THIS WARNING COULD
RESULT IN
IMPROPER SUPPLEMENTAL RESTRAINT DEPLOY-
MENT.
(1) Adjust the front seat to its most forward posi-
tion for easiest access to the lower B-pillar trim.
(2) Disconnect and isolate the battery negative
cable. Wait two minutes for the system capacitor to
discharge before further service.
(3) Remove the nut that secures the side impact
sensor stud to the inner B-pillar (Fig. 56).
(4) Reach through the large hole above the retrac-
tor mounting hole in the inner B-pillar to access the
side impact sensor and disengage the locating pin
and mounting stud from the holes in the inner B-pil-
lar.
ATTEMPTING ANY
THE MODULE
ACCIDENTAL, INCOMPLETE,
DR
STEERING
MUST BE
OR
