Summary of Contents for genband EXPERiUS-vtech VSP735
- Page 1 EXPERiUS-vtech Terminal Configuration Guide Release: 1.0 Document revision: 01.0x www.genband.com Enterprise Professional Services Page 1...
- Page 2 Standard Document release date: October 17, 2014 Copyright © 2014 GENBAND. All rights reserved. Use of this documentation and its contents is subject to the terms and conditions of the applicable end user or software license agreement, right to use notice, and all relevant copyright protections.
-
Page 3: Table Of Contents
EXPERiUS Terminal Configuration Guide ................................2 EW IN THIS DOCUMENT .................................. 2 OCUMENT REVISION .................................... 3 NTRODUCTION SIP T ..........................4 UPPORTED ERMINALS ONFIGURATION ......................................5 VTECH Supported Features/Limitations ............................5 Web Configuration ................................6 ... -
Page 4: New In This Document
EXPERiUS Terminal Configuration Guide New in this document The following sections detail what's new in Enterprise Terminal Configuration Guide [Document Number]. Document revision Release 01.0 – October, 2014. This is the first release of this document. Modifications: Enterprise Professional Services Page 2... -
Page 5: Introduction
Introduction This document is meant as an addendum to Administration, Configuration, and User Guides from vtech. It is intended to provide instructions for the GENBAND EXPERiUS™ specific SIP configuration of each terminal device. This document assumes that the default networking option is used for each device referenced which will auto configure the IP networking of the device using DHCP. -
Page 6: Supported Sip Terminals Configuration
EXPERiUS Terminal Configuration Guide Supported SIP Terminals Configuration GENBAND EXPERiUS™ has been tested to work with several SIP Terminals; this section will detail how these SIP Terminals should be configured to operate with the features tested. The next pages describe the configuration for terminals tested with EXPERiUS. -
Page 7: Vtech
EXPERiUS Terminal Configuration Guide vtech Supported Features/Limitations Table 1 – vetch supported features. Feature Feature Auto Hold Advanced Screening Call Duration Display Authorization Codes Call Forward Always Call Park to DN Call Park to System Call Forward Busy Call Pickup Targeted Call Forward No Answer Call Hold/Resume Call Pickup Directed... -
Page 8: Web Configuration
EXPERiUS Terminal Configuration Guide Web Configuration vtech sets currently being tested are the VSP735, VSP725, and VSP600. Set firmware version: 1.23.5 and 1.26.0 To find the set IP press Menu, Status, Network. Default web GUI is http://phone ip address Username: admin Password: admin The Status tab, System Status section will display status information for the terminal. - Page 9 EXPERiUS Terminal Configuration Guide On the System tab, Account 1, General Account Settings section. The Display Name is the label you want to display for the line button Set the User identifier to the username. For Authentication name enter the username again and Authentication password is the password supplied.
- Page 10 EXPERiUS Terminal Configuration Guide Defaults are fine in these sections unless you want to make a change. In the Feature Access Codes section enter your voicemail DN for Voicemail. Enterprise Professional Services Page 8...
- Page 11 EXPERiUS Terminal Configuration Guide In the Voicemail Settings, check Enable MWI subscription and for Mailbox ID enter the username@SIP Domain. If you wish to use the Adhoc conference feature, under Network Conference check Enable Network Conference and for Conference URI enter conference@SIP Domain. Enterprise Professional Services Page 9...
- Page 12 EXPERiUS Terminal Configuration Guide On the Servicing tab in the Time and Date heading you can configure you time settings. Enterprise Professional Services Page 10...
- Page 13 EXPERiUS Terminal Configuration Guide Under the Servicing tab Provisioning heading are the parameters for setting up a provisioning server. Enterprise Professional Services Page 11...
-
Page 14: Configuration Files
EXPERiUS Terminal Configuration Guide Configuration Files vtech SIP phones use the following files for configuration. Files should be located on a “Provisioning” server By default the phone fetches the following two files: General file: <model>.cfg and MAC-specific file: <model>_<MAC Address>.cfg. Sample configuration file: # Model Number = VSP735 # SW Version = 1.23.5.29598-0-ENG... - Page 15 EXPERiUS Terminal Configuration Guide sip_account.1.access_code_group_call_pickup = sip_account.1.access_code_direct_call_pickup = sip_account.1.blf_list_uri = sip_account.1.blf_remote_pickup_code = sip_account.1.blf_subscription_expires = 3600 sip_account.1.nat_traversal_stun_enable = 0 sip_account.1.nat_traversal_stun_server_port = 3478 sip_account.1.nat_traversal_stun_server_address = sip_account.1.nat_traversal_udp_keep_alive_enable = 1 sip_account.1.nat_traversal_udp_keep_alive_interval = 30 sip_account.1.network_conference_enable = 1 sip_account.1.network_bridge_uri = conference@SIP Domain sip_account.1.sip_session_timer_enable = 0 sip_account.1.sip_session_timer_min = 90 sip_account.1.sip_session_timer_max = 1800 sip_account.1.dtmf_transport_method = auto sip_account.1.codec_priority.1 = g711u...
- Page 16 EXPERiUS Terminal Configuration Guide network.eapol.enable = 0 network.eapol.identity = network.eapol.password = network.vendor_class_id = Vtech Vesa VSP725 network.user_class = Vtech Vesa VSP725 provisioning.bootup_check_enable = 1 provisioning.crypto_enable = 0 provisioning.crypto_passphrase = provisioning.dhcp_option_enable = 1 provisioning.dhcp_option_priority_1 = 66 provisioning.dhcp_option_priority_2 = 159 provisioning.dhcp_option_priority_3 = 160 provisioning.firmware_url = provisioning.handset_firmware_url = provisioning.fw_server_username =...
- Page 17 EXPERiUS Terminal Configuration Guide remoteDir.ldap_user_name = remoteDir.ldap_password = remoteDir.ldap_max_hits = 200 remoteDir.ldap_work_number_attributes = remoteDir.ldap_mobile_number_attributes = remoteDir.ldap_home_number_attributes = remoteDir.ldap_protocol_version = version_3 remoteDir.ldap_search_delay = 0 remoteDir.ldap_incall_lookup_enable = 0 remoteDir.ldap_outcall_lookup_enable = 0 remoteDir.ldap_enable = 0 remoteDir.ldap_firstname_attribute = remoteDir.ldap_lastname_attribute = remoteDir.ldap_check_certificate = 0 remoteDir.broadsoft_enable = 0 remoteDir.broadsoft_display_name = remoteDir.broadsoft_server = remoteDir.broadsoft_port = 0...
- Page 18 EXPERiUS Terminal Configuration Guide web.page.servicing.manual_firmware_upgrade = admin web.page.servicing.provisioning = admin web.page.servicing.security = admin,user web.page.servicing.certificates = admin web.page.servicing.system_logs = admin tone.call_waiting_tone.num_of_elements = 1 tone.call_waiting_tone.element.1 = 1 440 -120 0 0 0 0 0 0 500 0 1 tone.call_waiting_tone.element.2 = tone.call_waiting_tone.element.3 = tone.call_waiting_tone.element.4 = tone.call_waiting_tone.element.5 = tone.hold_reminder.num_of_elements = 1...
- Page 19 EXPERiUS Terminal Configuration Guide user_pref.ringer_volume = 2 user_pref.speaker_volume = 4 user_pref.headset_volume = 5 user_pref.handset_volume = 5 user_pref.audio_mode = speaker user_pref.key_beep_enable = 1 user_pref.hold_reminder.enable = 1 user_pref.hold_reminder.interval = 30 user_pref.call_waiting.mode = enable user_pref.call_waiting.tone_enable = 1 user_pref.call_waiting.tone_interval = 30 user_pref.call_terminated.busy_tone_enable = 1 call_settings.account.1.block_anonymous_enable = 0 call_settings.account.1.outgoing_anonymous_enable = 0 call_settings.account.1.dnd_enable = 0...
-
Page 20: Provisioning Server And Dhcp
EXPERiUS Terminal Configuration Guide Provisioning Server and DHCP Example is using Pumpkin TFTP server: Under Options, Server tab specify the root directory containing your provisioning files. Example DHCP Scope Options using Windows Server 2012: If using TFTP you can configure option 150 for HTTP/HTTPS use option 160 by default. Enterprise Professional Services Page 18... - Page 21 Document release date: October 17, 2014 Copyright © 2014 GENBAND. All rights reserved. Use of this documentation and its contents is subject to the terms and conditions of the applicable end user or software license agreement, right to use notice, and all relevant copyright protections.
