Summary of Contents for MESIDA TECH A16

  • Page 1 A16 User Manual...

  • Page 2: Application Method

    Please read the instruction manual before use, in order to properly installed and rapid use! 1. Application method 1. Before use, please test equipment model is correct, accessories are complete. 2. In shutdown state insert support GSM network SIM card (GSM 850,900,1800,1900MHZ)and open the caller id function and monthly flow (not less than 30 m/month traffic package).
  • Page 3 9. Record the ID number of the device Around the outside of the box, you will find ID number(ten number). Please remember or record it down. Remember they will be used in the process of logining in.

  • Page 4: Product Function

    2. Product function 1. Real time tracking 2. Historical route 3. Geo-fence 4. SOS emergency call , two way talk, voice monitoring 5. Real time and timing heart rate measurement 6. Do not disturb mode 7. Clock alarm 8. Pill alarm 9.
  • Page 5 Positioning: GPS satellite positioning Beidou positioning AGPS auxiliary positioning+WIFI positioning+ LBS base station positioning Positioning accuracy: GPS+Beidou location 5-15m WIFI location 15-100m Base station location-100-1000m Device size：46X36X16mm Whole machine weight：40G Battery capacity：500mAh Standby time：5 days Platform monitoring：support android, apple mobile phone system, computer network clients, etc Universal: four frequency support GSM network, languages and time zone setting, built in global network parameters...

  • Page 6: Function Declaration

    4. Function declaration 4.1 SOS emergency call If you have set up the family number, long press power/ SOS button, watch will dial the family number, if the first number answer, will not dial the second number. If not answer, will dial the second number, circle dial twice, will not call until answer.
  • Page 7 4.5 Voice monitoring Select voice monitoring function in setting up and fill in your mobile phone number, wait for a while and after confirmation equipment will be sent a calling to your number, you can listen to the voice around locator after answering. After set up the white list, the inside of white list number will send a calling to device, press the heart rate button answer, can listen to the voice around locator.

  • Page 8: Buttons Instruction

    5、Buttons instruction Turned off condition by pressing the power button / SOS button positioning watch will turn on in case of power sufficient . Positioning watch online status can’t manually shut down, watch without SIM card can press power key/SOS key to turn it off manually. Positioning watch card when normal, if you have set up the family number, long press power key/SOS button, the watch will call family number, the first number after dialing if you have answered will not continue to dial the second number, if you do not answer will dial the second...
  • Page 9 Open APP client-side, choose device login in, equipment number please type device ID number on box(ten number)， default passwords as 123456, Finally click login to the main menu. (advice for the first time after landing please amend and remember the passwords) Landing interface Main menu...
  • Page 10 个人安全信息 请您正确安装使用本产品。为了保证产品使用的安全，请务必保证您的产品不被未经许可的人绑 定。公司承诺，依照全国人大常委《关于加强网络信息保护的决定》、《全国人大常委会关于维护互 联网安全的决定》及《互联网电子公告服务管理规定》等法律法规的规定，采取技术和管理措施保障...

  • Page 11: Chapter 1 Troubles & Shooting

    7, Setup apn for access of network SIM card in some countries need to setup apn before access to GPRS network, please contact the SIM card operator or check the website of the SIM card for the apn information. Command Example Reply SMS pw,123456,apn,a...

  • Page 12: Chapter 2 Main Sms Command Summary Sheet

    Chapter 2 Main SMS command summary sheet Command type Command type Example The expected output result Setup center number pw,123456,center,xxxx pw,123456,center,136 Central number： xxxxxxx# 40927062# 13640927062.setup sucess! Setup APN pw,123456,apn,apn pw,123456,apn,wap.t apn:wap.tmobil.cl;user: name,user name,pass mobil.cl,wap,wap,730 wap;passwork:wap;use word,MCCMNC# rdata:73002. Setup the upload time pw,123456,upload,x# pw,123456,upload,30 Upload time...
  • Page 13 062; upload:300S; workmode:2; bat level:3; language:1; zone:8.00; GPS:NO(0); GPRS:OK(90); LED:ON; pw:123456; Reset the device pw,123456,reset# pw,123456,reset# The device will reset Restore factory pw,123456,factory# pw,123456,factory# The device will reset settings Setup ip and port pw,123456,ip,x.x.x.x,y pw,123456,ip,112.95. port setup 164.119,7755# success! Setup language and pw,123456,lz,x,y# pw,123456,lz,0,8# lz,x,y#...
  • Page 14 Declare •Welcome to use the GPS Watch. GPS watch contains hardware and intelligent mobile phone client-side software two parts, device need complete set to use can realize the function. Please read the instructions and safety information in this manual before operating hardware, for ensure the safe and correct use.
