- Page 1 Wireless USB Phone User’s Manual Be sure to carefully read this User’s Manual for the proper use of the Wireless USB Phone and keep it for future reference. Version 2.0 , May. 2009...
-
Page 2: Safety And General Information
Safety and General Information: Your phone is designed to use AAA Ni-MH rechargeable battery only. Warning! Never attempt to charge non-rechargeable battery. The battery can be charged and discharged hundreds of times, but it will gradually wear out, when the operation time (standby time and talk time) is noticeably shorter than normal, then it is probably time to replace batteries. -
Page 3: Software Installation For Windows
® 3.1 Software Installation for Windows Step 1 Insert the driver CD, click the Install Driver button. Note: you may be asked to install the .NET Framework, please click Yes to continue the installation. Step 2 Click Next and refer to the following steps to complete the installation. Step 3 Select Allow access to allow the driver to use Skype When the installation is completed, please check the driver icon shown in the task bar at... - Page 4 ® 3.2 Software Installation for Mac OS Step 1 Insert the CD, browse to the Install Driver for MAC.dmg folder. Step 2 The “WirelessUSBPhone Driver OSX _._._” icon will appear on your desktop, please find it and click the icon. Step 3 Click the “WirelessUSBPhone Driver Install.pkg”...
-
Page 5: Install The Batteries
3.3 Install the batteries Note: Always use AAA Ni-MH rechargeable batteries only. Slide the battery cover and insert the three batteries with the correct polarity as indicated. Replace the battery cover firmly back into place. Note: The phone will automatically turn on after inserting batteries. 3.4 Insert the USB Dongle into the USB Port Note: Skype will automatically detect the phone as new audio... - Page 6 Chapter 4 How to use Wireless USB Phone...
- Page 7 Icon Name Function Press to enter History mode, you can check your call history History and loop through Incoming, Outgoing and Missed calls on the display screen. (Use scroll up/down keys to scroll lists) Press to enter Contacts mode, you can access your Skype contact list and switch between Online contacts and All Contacts contacts on the display screen.
- Page 8 Chapter 5 Indicators shown on the display 5.1 LCD Main Screen: Indictors Meaning Description Connected, vertical bars show the signal strength. Phone-to-PC Connection Disconnected, you cannot make or receive calls. Hang up Dialing/Ringing Call Status During call On hold The bar goes lower as the volume goes down. Volume Level Boost speaker volume (press volume up for 1 sec.) Speaker mute (press volume down for 1 sec.)
- Page 9 5.2 History Mode: Indictors Meaning Description History Indicate the phone is in History mode. Missed Calls Show missed calls. Incoming Calls Show incoming calls. Outgoing Calls Show outgoing calls. 5.3 Contacts Mode: Indictors Meaning Description Contacts Indicate the phone is in Contacts mode. Show all online contacts.
-
Page 10: Making Calls
Chapter 6 Using the Wireless USB Phone 6.1 Answering/Ending a Call: When you receive a call, your phone rings, the phone status icon changes from and the caller’s Skype name will be shown on the display. Note: The phone can only show English Skype name, if you add your Skype contacts in other languages, the phone will show Skype Press the Dial/Answer... -
Page 11: Putting A Call On Hold
6.2.2 Calling an Ordinary Phone Number from SkypeOut Note: You have to purchase SkypeOut credits to call landlines or mobile phone, please go to http://www.skype.com/ for more details. If you subscribe to SkypeOut , refer to the following to make a SkypeOut call. -
Page 12: Charging The Batteries
6.6 Powering the Phone on and off, Standby and Sleep Mode: Press and hold for 3 seconds until the display turn on/off. Standby mode: To extend battery life, the backlight turns off automatically when no activity is detected for 15 seconds ( shown on display ). -
Page 13: Chapter 7 Specifications
Chapter 7 Specifications Frequency 2400 ~ 2483MHz Channel Number ID Per Channel 65535 Modulation Antenna Type PIFA ANT LCD Display 128 x 64 Dot-matrix, Black/White 330 feet (100m) in open space Wireless Range 160 feet (30m) indoors Working Voltage DC 3.0V ~ 4.5V Battery Three AAA Ni-MH Rechargeable Batteries Tx Power... -
Page 14: Chapter 8 Other Information
Chapter 8 Other information ARE AND AINTENANCE Don’t leave the phone in hot or cold places. For cleaning, use a soft, slightly moistened cloth, avoid using solvents or abrasive substances. Don’t attempt to open the device, only qualified personnel may repair this product. RADEMARKS Skype, SkypeOut, the Skype Logo and the S logo are trademarks of Skype Limited. -
Page 15: Appendix: Troubleshooting
Appendix: Troubleshooting This appendix provides common problems and solutions that may occur during the operation of the phone, whenever you have problems with your phone, please check the followings first: The phone’s power is turned on and the volume control is normal. The USB dongle is properly connected to the PC. - Page 16 B. No phone ring when incoming call or dialing. ® 1. For Windows Open Skype , click “Tools → Options”. Then select “Sounds” on the left menu, make sure you have tap the check box “ringtone” and “dial tone”. You can choose which sound to play here.
- Page 17 C. Cannot send/receive calls or the keys do not function. ® 1. For Windows Step 1: Open Skype , click “Tools → Options”. Then select “Advanced settings” on the left menu, and click “ Manage other program’s access to Skype” in the related tasks: “Name: WirelessUSBPhone.exe”...
- Page 18 ® 2. For Mac OS Step 1: Open Skype , click “Account → Manage API Clients…”, select “WirelessUSBPhone”, then click “Change”: Step 2: Select “Allow this program to use Skype”, click Done and save the setting. D. The speaker too quite/loud/Cannot hear the phone rings clearly. Step 1: Your phone maybe muted, press the volume up key to unmute the phone.
- Page 19 G. Cannot make SkypeOut calls. Cannot place outgoing calls to landlines. Step 1: You have to enter “00” or “+” (press and hold the “0” key for 2 seconds) before calling ordinary phone number. Step 2: Check your Skype account credits. (Please refer to 6.2.2 Calling an Ordinary Phone Number from SkypeOut H.
- Page 20 “No Signal” message on handset LCD： Step 1: Please make sure the USB dongle has been firmly plugged in computer’s USB port. Step 2: If the USB dongle has been firmly plugged in, please conduct the pairing between handset and USB dongle to make sure they are connected. (Please refer to 3.5 Pair the Phone and USB Dongle) “No Skype”...
