SVT-2 Outdoor Station B/C
User Manual
SVT-2 Outdoor Station B
SVT-2 Outdoor Station C
2W12120
2W12120
Please read this user manual prior to installing the system, and keep it well for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2W12120 and is the answer not in the manual?

Questions and answers

Summary of Contents for SVT 2W12120

  • Page 1 SVT-2 Outdoor Station B/C User Manual SVT-2 Outdoor Station B SVT-2 Outdoor Station C 2W12120 2W12120 Please read this user manual prior to installing the system, and keep it well for future use.
  • Page 2: Table Of Contents

    CONTENTS 1.Parts and Functions..................... 1 2.Terminal Descriptions ..................1 3.Specification ...................... 2 4.Mounting ......................2 4.1 Mounting Without Rain Guard ................2 4.2 Mounting With Rain Guard ................3 4.3 Placing Name Label ..................3 4.4 Adjusting Camera Angle ................4 5.System Wiring and Connections .................
  • Page 3: Parts And Functions

    1.Parts and Functions Camera Lens Night View LED Speaker Name Plate Call Button Microphone Rain Guard 90 mm 23 mm Note: Outdoor Station B has two call buttons. 2.Terminal Descriptions 1 2 3 Lock Control Jumper Outdoor Station Code DIP MIC adjustment SPK adjustment Main Connection Port...
  • Page 4: Specification

    • To select the lock type: see 5.2.1 , 5.2.2 Lock Control Jumper: • Total 4 outdoor stations can be supported,see 6.1 Outdoor Station Code DIP: • To connect the bus line and the electric locks. Main Connect Port: • BUS: Connect to the bus line, no polarity. •...
  • Page 5: Mounting With Rain Guard

    4.2 Mounting With Rain Guard 160-165cm 4.3 Placing the Name Label Move the plastic cover away to open the transparent name label cover, insert a name paper, then put the plastic cover back to the panel. name label...
  • Page 6: Adjusting Camera Angle

    Use a screwdriver to loose the screw and then adjust the angle of the camera ,then fix the screw back to hold the position of the camera. 5.System Wiring and Connections 5.1 Basic Connection SVT-2 PC6 L1 L2 PL S1+ S2+ S-...
  • Page 7: Electric Lock Connection

    5.2 Electric Lock Connection 5.2.1 Door Lock Controlled with Internal Power Note: Electric lock of Power-on-to-unlock type should be used. The door lock is limited to 12V, and holding current must be less than 250mA. The door lock control is not timed from Exit Button(EB). Parameter on the Indoor Monitor must be set to 0 (by default).
  • Page 8: How To Setup The Unlock Parameter In Monitor

    connect one lock connect two locks Take off the Jumper Take off the Jumper POWER POWER SUPPLY SUPPLY LOCK LOCK LOCK 5.2.3 Unlock parameter setting (set on Indoor Monitor) INSTALLER SETUP About Local Address 00.00 Video Standard AUTO System Verson 00.01.00 Display Driver Front...
  • Page 9: Multi Outdoor Stations Connection

    5.3 Multiple Outdoor Stations Connection SVT-2 SVT-2 SVT-2 DBC4 A B C D 85~260VAC 4# Camera 3# Camera 2# Camera 1# Camera ID=11 ID=01 ID=10 ID=00 L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S-...
  • Page 10: Multi Indoor Monitors Connection

    5.4 Multiple Indoor Monitors Connection 5.4.1 Basic IN-OUT Wiring Mode SVT-2 PC6...
  • Page 11: With Dbc-4 Wiring Mode

    5.4.2 Using SVT-2 DBC-4 device - Wiring Mode SVT-2 SVT-2 85~260AC ID=00...
  • Page 12: Setup

    The Bit 3 is used to configure the position of each indoor monitor in the connection line. It must be set to ON if the indoor monitor is in the end of the line, parallel connection, or connected to a SVT-2 DBC-4 module.
  • Page 13 Each indoor monitor should be assigned with an address in the system. SVT-2 Outdoor Station B (2W12120): A maximum of 16 indoor monitors can be connected to the system. Program the indoor monitors with user codes 0 - 15. SVT-2 Outdoor Station C (2W12130): 16 indoor monitors can be connected to each call button, with a maximum of 32 indoor monitors per system.
  • Page 14: Power Supply

    200 ~ 240VAC (1.5A) indoor monitors and other accessories. It SVT-PS5 Input Frequency: 50 ~ 60 Hz supports a maximum of 32 indoor monitors. It Rated Output Voltage: 24Vdc must be used along with a SVT-DPS device. Rated Output Current: 4.5A -12-...
  • Page 15: Cable Requirements

    7.Cable Requirements Using different cables may affect the maximum distance which the system can reach. The farest monitor with two or four monitors SVT-2 /DBC-4 When Monitor quantity < 20 SVT-2 SVT-2 Cable Usage 100 feet 200 feet 200 feet...
  • Page 16 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
