GLG Creator Basic Battery DLX User Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

Enlarged version

Technical SPECIFICATION:

GLG Creator Basic Battery DLX
Model No:
Voltage Input
100-240V AC, 50/60Hz
：
TianXin 6in1 LEDs
LED Type:
25°
Beam Angle:
Optical Lens Size:
42mm
USITT DMX-512, AirDMX System
Protocol:
DMX Channel Mode:
3/6/8/11 CH
AirDMX, DMX-512, Standalone, Master/slave, Sound
Control Mode:
Active, iOS or Android Smartphone
4 Dimming Curves
Dimmer Mode:
PWM Dimming:
16bit PWM Dimming at 5200HZ
14.8V x 8.8Ah = 131Wh
Battery Powered:
2.4G Wireless DMX Transceiver
Wireless DMX:
Body Material:
Aluminum Die-casting
IP33 Indoor Use Only
Waterproof Grade:
Product Size
138x144x188mm
Net Weight.:
3Kgs
www.goedlichtengeluid.nl
User Manual
Creator Basic Battery DLX

Getting Started

What's In The Box?
Creator Basic Battery DLX:
• 1 x
• 1 x Powercon schuko cable, powercon link cable, this User Manual
1
GLG LIGHTING EQUIPMENT
battery powered wireless LED Uplights
info@goedlichtengeluid.nl

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Creator Basic Battery DLX and is the answer not in the manual?

Questions and answers

Summary of Contents for GLG Creator Basic Battery DLX

  • Page 1: Technical Specification

    GLG LIGHTING EQUIPMENT Technical SPECIFICATION: GLG Creator Basic Battery DLX Model No: Voltage Input 100-240V AC, 50/60Hz ： TianXin 6in1 LEDs LED Type: 25° Beam Angle: Optical Lens Size: 42mm USITT DMX-512, AirDMX System Protocol: User Manual DMX Channel Mode:...
  • Page 2 Congratulations on purchasing one of the brightest, best-built led uplights anywhere! Now Creator Basic Battery DLX Creator Basic Battery DLX that you’ve got your...
  • Page 3 GLG LIGHTING EQUIPMENT You can scan the QR code on the The 7-Color Status LED will change color to indicate the current ID group: “WifiDMX Box” to download the right app for your smart phone · GROUP 1: RED Android OS ·...

  • Page 4: Easy Mode

    000-255 Master Dimmer 000-255 000-255 Green 000-255 Blue 8 Channel 000-255 Amber 000-255 White 000-255 000-255 Strobe 2. Easy Mode 000-255 000-255 Green 000-255 Blue 6 Channel 000-255 Amber 000-255 White 000-255 3. HSV Mode 000-255 3 Channel 000-255 Saturation 000-255 Value The Channel Modes...

  • Page 5: Extend Mode

    Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact GLG (Goed licht en geluid). The Safety Instructions The Menu Panel www.goedlichtengeluid.nl...

  • Page 6: The Menu Structure

    The Control Panel Address Setting A d d r e s s : 0 0 1 - 5 1 2 There are 4 control buttons below the LED display which allow you to navigate through 4 Channel Modes C h a n n e l : 6 / 8 / 1 1 / 3 the various control panel menus.
