- Page 2 Congratulations! You have bought a great, innovative product from DMT. The DMT Media Spinner brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated DMX show, this product provides the effect you need. You can rely on DMT, for more excellent lighting products.
-
Page 3: Table Of Contents
DMT VDA-15™ Product Guide Warning.................…...……………..…………..………………….………..… Unpacking Instructions………………………………………………………………………………………………...….. Safety-instructions………………………………………………………………………………………………………..… Operating Determinations.……………………………………………………………………………………………..Return Procedure..............................Claims..................................Description..................................Features..................................Overview Front panel............................. Overview Back panel............................. Installation..................................Set up and operation..............................Maintenance................................Troubleshooting................................Product Specifications.............................. -
Page 4: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • VDA-15 • Power Cable – 2m • User manual... -
Page 5: Operating Determinations
Do not switch the system on and off in short intervals, as this would reduce the system’s life. Do not open the device and do not modify the device. Only use system indoor, avoid contact with water or other liquids. ... -
Page 6: Return Procedure
Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU (including UK) North America From April 2004 Brown Black Phase Blue White Neutral Green/Yellow... -
Page 7: Description
Description of the device Features The VDA-15 is a 1:5 Video/Audio Distributor. The VDA-15 is designed for the AV-studio or multimedia use where high quality is required for distributing signals over longer distances. Outputs are independent from each other. This way, overloading or even shorting one output will have no influence on the other outputs performance. -
Page 8: Overview Front Panel
Connect to the output of your video source. 6. Lo/Hi Impedance switch. When using a VDA-15 standalone, select “Lo” (75Ω). If you want to loop several units using the Video Loop (7) connector, select “Hi” for each unit connected to a video loop output. -
Page 9: Installation
15. Audio loop out RCA connector. Connect these outputs to the inputs of another VDA-15 if you need more than five stereo outputs. 16. Audio R gain trimmer. Use this trimmer to adjust the Left audio level if necessary. 17. Audio stereo 1 out RCA connector. -
Page 10: Maintenance
Maintenance The DMT VDA-15 requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. -
Page 11: Product Specification
Product Specification Video distribution amplifier: 1 in: 1 loop: 5 out Input Impedance: High-Z / 75 Ohm switchable Coupling: AC / DC switchable Connector: BNC Video gain: adjustable Bandwidth: -3 dB at 300 MHz Audio distribution amplifier: 1 in: 1 loop: 5 out Gain: adjustable Connector: RCA/Cinch S/N ratio: >80 dB... - Page 12 © 2010 DMT.
