Summary of Contents for Tecnolec DUO EC 3
- Page 1 DUO EC 3 DOUBLE OVEN ELECTRIC COOKER Operating Instructions Before operating this cooker, please read these instructions carefully...
- Page 2 14-15 – After sales service ” INTRODUCTION Congratulations on your purchase of this TECNOLEC electric cooker which has been carefully designed and produced to give you many years of satisfactory use. ° C °C Before using this appliance it is essential...
-
Page 3: Installation
Installation INSTALLATION TECHNICAL DATA electrical wiring must 230 Volts AC - 50 Hz compliance with the appropriate IEE regulations and carried out by a qualified Static top oven electrician. – Top element 0.7 kW – Bottom element 1.1 kW The cooker must be supplied via a –... -
Page 4: Connecting The Mains Cable
Installation CONNECTING THE MAINS CABLE – Remove the two screws securing the cover plate A behind the cooker. – Remove the screw C from the cable clamp. – Insert the mains cable (type H05 RR-F) of minimum 4 mm section into the cable pro- tector P. -
Page 5: Before Use
Installation LOCATION BEFORE USE This appliance is designed with type “X” protec- Please ensure that all packing has tion with regard to overheating of surrounding been removed from the appliance surfaces. before switching on. The adjacent cabinets must be able to withstand a temperature rise of 75 °C. -
Page 6: Control Panel
Features HOB ELEMENTS (Fig. 5) 1. 180 mm diameter (rapid) 2. 145 mm diameter (normal) 3. 180 mm diameter (normal) 4. 145 mm diameter (normal) OVENS (Fig. 5) 5. Conventional top oven 6. Fan bottom oven CONTROL PANEL (Fig. 5) Control knobs: °... -
Page 7: How To Use The Hotplates
How to use the Hotplates REMEMBER: The hob is made of steel coated with a vitreous enamel to provide a durable and Solid plates retain their heat for a consi- attractive surface. There are four solid derable time after switching off. plates clamped to the surface of the hob. -
Page 8: Choice Of Pans
How to use the Hotplates CHOICE OF PANS: DONT’S: It is uneconomical to use pans smaller Pans with a ridged or recessed base than the plate that has been selected. must not be used. The plate is made of cast-iron and is Likewise do not use an asbestos or wire heated uniformly over the whole surface, mat or anything else under the pan. -
Page 9: How To Use The Autotimer
How to use the Autotimer 8.00 Fig. 8 Auto timer (bottom oven only). DIGITAL CLOCK AND AUTOMATIC USING YOUR AUTOMATIC TIMER TIMER A This knob adjusts the time of day on SETTING THE TIME OF DAY the clock. B This knob controls the programming Gently turn the knob A until the correct - it sets the time to start cooking and hours and minutes are displayed on dial... - Page 10 How to use the Autotimer SETTING THE TIMER TO START AND The oven will operate immediately and switch off when cooking time is over. An STOP COOKING (FULLY AUTOMATIC) audible signal will be heard before the oven switches off. This can be stopped The cooking start time can be set along by turning the outer section of knob B with the length of cooking time for fully...
-
Page 11: Function Selector
How to use the Top Conventional Oven FUNCTION SELECTOR TEMPERATURE SELECTOR Cook or grill by turning the control knob The light above the function selector will (fig. 10) until the symbol on it is in line illuminate when the oven is switched on with the indicator line. -
Page 12: Cooking With A Fan Oven
How to use the Bottom Fan Oven FUNCTION/TEMPERATURE SELECTOR COOKING WITH A FAN OVEN Cook by turning the control knob (fig. 11) Fan cooking is more economical and until the indicator on it is in line with the quicker than cooking in a conventional. function/temperature required. -
Page 13: Temperature Recipe Guide
Temperature Recipe Guide OVEN COOKING TEMPERATURES APPROX. HEAT OF TYPE OF DISH TO COOK MARK TEMPERATURE OVEN 125°C Very cool Meringue cases, fruit bottling (257°F) oven slow cooking foods. 135°C - 140°C Cool or Milk puddings, very rich fruit (275°F - 285°F) slow oven cakes, i.e., Christmas cake. -
Page 14: Care And Maintenance
Care and Maintenance THE OVENS: Always switch the cooker off at the mains isolating switch before cleaning The ovens interior and the chromium or touching any electrical part. plated shelves and runners can be cleaned by a damp soapy cloth. Obstinate stains can be removed with THE HOB: scouring pads and a gentle, non-... -
Page 15: After Sales Service
If the cooker is malfunctioning and service is required. Turn off the mains supply and contact your nearest COMET Service Centre. The TECNOLEC Policy is one of continuous development and for this reason we reserve the right to change specifications without prior notice. - Page 16 The static noise interference of this appliance conforms to the EEC 87/308 Norms. Descriptions and illustrations in this booklet are given as simply indicative. The manufacturer reserves the right, considering the characteristics of the models described here, at any time and without noti- ce, to make eventual necessary modifications for their construction or for commercial needs.
