- Page 1 Quick Start Guide for LCD8000-70T RIoTboard-based Embest Technology www.embedinfo.com...
-
Page 2: Table Of Contents
Embest Technology Table of Contents Hardware/Software Requirements ................... 1 Hardware Requirements..................1 Software Requirements ..................1 LCD8000-70T Display Configuration ................2 Technical Support and Warranty ..................7 Copyright © 2014 Embest Technology RIoTboard LCD8000-70T Quick Start Guide... -
Page 3: Hardware/Software Requirements
Embest Technology Hardware/Software Requirements LCD8000-70T is a 7-inch LCD resistive touch screen designed by Embest Technology. To use it for the display, you need to make the following preparations: 1. Hardware Requirements RIoTboard*1 5V power adaptor*1 LCD8000-70T *1 ... -
Page 4: Lcd8000-70T Display Configuration
Embest Technology LCD8000-70T Display Configuration 1） The connection of LCD8000-70T and RIoTboard will be finished through the LCD-Ex extension board, the way of which can be seen as below: Figure 1 Hardware Connections Mote: On using 50PIN FPC cable to connect LCD and LCD-Ex, the blue side should be upward;... - Page 5 Embest Technology Figure 2 Diagram for Connection of RIoTboard and UART8000-U Hardware 3） Connect 5V power adaptor to development board, the complete hardware Connection can be seen as below: Copyright © 2014 Embest Technology RIoTboard LCD8000-70T Quick Start Guide...
- Page 6 : 132000000Hz axi clock : 198000000Hz emi_slow clock: 99000000Hz ddr clock : 396000000Hz usdhc1 clock : 198000000Hz usdhc2 clock : 198000000Hz usdhc3 clock : 198000000Hz usdhc4 clock : 198000000Hz Copyright © 2014 Embest Technology RIoTboard LCD8000-70T Quick Start Guide...
- Page 7 At the execution of this command, network needs to be connected. In additional, you can download ubuntu-touchscreen.zip from Embest website to install tslib. On unzipping, copy to U-disk and connect Copyright © 2014 Embest Technology...
- Page 8 LCD8000-43T which is used in the Android system before now will be displaced by LCD8000-70T now. After the 7-inch LCD display mode has been set, the following instructions need to be executed when you enter the system: ...
-
Page 9: Technical Support And Warranty
Embest Technology Technical Support and Warranty Technical Support Embest Technology provides its product with one-year free technical support including: Providing software and hardware resources related to the embedded products of Embest Technology; Helping customers properly compile and run the source code provided by Embest Technology;... - Page 10 4） Please contact technical support if there is any repair request. Note: Embest Technology will not take any responsibility on the products sent back without the permission of the company. Copyright © 2014 Embest Technology...
-
Page 11: Contact Information
+86-755-25635626-863/865/866/867/868 Fax: +86-755-25616057 Email: globalsales@embest-tech.com Company Information Website: http://www.embest-tech.com Address: Tower B 4/F, Shanshui Building, Nanshan Yungu Innovation Industry Park, Liuxian Ave. No. 1183, Nanshan District, Shenzhen, Guangdong, China (518055) Copyright © 2014 Embest Technology RIoTboard LCD8000-70T Quick Start Guide...
